Quick Installation Manual
APX 86~200H-S1-US
Growatt USA, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the APX 86H-S1-US and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Growatt APX 86H-S1-US

  • Page 1 Quick Installation Manual APX 86~200H-S1-US Growatt USA, Inc.
  • Page 2: Environment Requirements

    Environment requirements Max. +50℃ Min. -10℃ +5%~+95% Installation tools #8 #10 Electric screwdriver Socket wrench Allen key Cross-head screwdriver (PH2) (PH2, crosshead) Marker Knife Measuring tape T type socket wrench Auxiliary tool Hammer Multimeter Electric drill Forklift Crane Lifting platform System size 920mm(36.22in) Front view of APX 1000140-C1-US...
  • Page 3: Checking Before Installation

    1. Checking before installation Checking the scope of delivery APX 1000140-C1-US (entire unit) APX 14.3P-B1-US (entire unit) APX 14.3P-B1-US Base & the Cable set connecting the Cable set connecting two connecting piece and the M6 hybrid inverter with the CM columns of batteries screw to secure the base Hybrid inverter model Battery System Capacity...
  • Page 4: Installation

    Checking the package of APX 14.3P-B1-US Please check if the contents are complete and intact Cables connecting two battery modules OUT1 OUT2 Power cable connecting to BMs *1 Communication cable 1 connecting to BMs *1 APX 14.3P-B1-US Communication cable 2 connecting to BMs *1 Anti-tip &...
  • Page 5 ≥300mm(11.81in) ≥300mm(11.81in) 800mm≤d≤1000mm ≥300mm 300±50mm (31.50in≤d≤39.37in) ≥600mm(23.62in) (11.81in) (11.81±1.97in) Wall 90° 90° 90° Ground Note: 1. The system requires installation assistance from at least two adults capable of heavy lifting. It is recommended to use a forklift during the installation. 3.
  • Page 6 Step 2: Move the auxiliary tool onto the fork of the forklift. Step 3: Place the battery module onto the base, ensure the locating pins of the BM align with the locating points of the base. Step 4: Install the 4 anti-tip & grounding connecting pieces between the BM and the base to avoid tip-overs during installation.
  • Page 7: Cable Connection

    Step 6: Connect the 4 anti-tip & grounding connecting pieces between the BM and the CM. Please note that it is necessary to install the anti-tip components properly. Rear View Rear View 2N·m 2N·m Note: 1. Remove the front cover of the CM before installing the connecting pieces. 2.
  • Page 8 4 5 6 Number Name Description Ventilation valve Exhaust air and keep water out CM positive terminal connected to the PCS positive PCS+ terminal CM negative terminal connected to the PCS negative PCS- terminal Communication terminal connected to the ShineMaster AC INPUT AC INPUT terminal Communication terminal connected to the hybrid inverter...
  • Page 9 Step 2: Connect external cables of the battery system. BM 1 BM 2 OUT1 OUT2 (click sound) Fully insert the OUT1 OUT2 terminal to the port Bend the power cable outward when wiring it as OUT1 OUT2 Cable tie it is relatively long. Bundle cables OUT1 OUT2...
  • Page 10 5. The cable color is for demonstration purpose only. The actual cable color prevails. colors of the cables. Follow all instructions for system wiring specified in the manual strictly. Growatt shall not be liable for any system damage or other safety accidents caused by failure to follow the instructions.
  • Page 11 BMS-COM COM 2 COM 1 NOTE: 1. Remove the panel from the back of the CM. 2. Remove the rubber sealing plugs, then install two conduit fittings with a diameter of 2 inches (prepared by users). 3. Connect the power cables and communication cables between the PCS and CM through separate conduits.
  • Page 12: Terminal Connection

    Note: When powering off the system, ensure the isolation switch is turned off after pressing the button. Do not disconnect the isolation switch with power on, as this risks damaging the switch. 7. Service and contact Growatt USA, Inc. 9227 Reseda Blvd, #435 Northridge, CA 91324, USA. +1-866-686-0298 usaservice@ginverter.com us.growatt.com...
