User Guide
Contact us
www.ginverter.com
NOAH 2000
Balcony Solar Storage
User Manual
1. Keep it dry and do not place heavy objects on the NOAH 2000.
2. Do not dismantle, punch, shake, hit, or burn it.
3. Recycle and place NAOH 2000 according to local policies.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NOAH2000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Growatt NOAH2000

Summary of Contents for Growatt NOAH2000

  • Page 1 User Guide NOAH 2000 Balcony Solar Storage User Manual Contact us 1. Keep it dry and do not place heavy objects on the NOAH 2000. 2. Do not dismantle, punch, shake, hit, or burn it. 3. Recycle and place NAOH 2000 according to local policies. www.ginverter.com...

  • Page 2: Table Of Contents

    Content DISCLAIMER ................................. 3 PACKING LIST ..............................3 SPECIFICATION ..............................3 SAFETY GUIDELINES ............................4 OVERALL INTRODUCTION ..........................5 PRODUCT APPEARANCE ............................5 LED Panel and Buttons ..............................6 INSTALLATION ..............................6 Application 1: NOAH 2000（×1）+Solar Module（×2） ..................6 Application 2：NOAH 2000（×1）+Solar Module（×4） ..................7 Application 3: NOAH 2000（×2）+Solar Module（×4）...

  • Page 3: Disclaimer

    Users promise to be responsible for their actions and all consequences arising therefrom. Growatt is not responsible for any damage caused by using the product not in accordance with the document.

  • Page 4: Safety Guidelines

    If the product accidentally falls into water, place it in a safe, open area and stay away from it until it is completely dry. Do not reuse a dried product; dispose of it properly as per the instructions in this document. 10. Growatt is not responsible for accidents or malfunctions caused by parts not provided by Growatt. 11. Clean the product only with a dry cloth.

  • Page 5: Overall Introduction

    II. Storage and Maintenance Store the NOAH 2000 out of children's reach. If a child accidentally swallows any parts, seek medical assistance immediately. After using, if the machine indicates low battery, charge it before storage. Extended storage with low battery may damage the internal battery.

  • Page 6: Led Panel And Buttons

    Model Length Width Height Weight NOAH 2000 406mm 235mm 270mm ≈23kg LED PANEL AND BUTTONS Main Power Button: Short press for 1 second to turn on; long press for 3 seconds to turn off. Solar Panel Connection Indicator: The icon lights up to indicate solar panel connection. When the PV input power is below 25W, the icon flashes quickly;...

  • Page 7: Application 2：Noah 2000（×1）+Solar Module（×4

    2. Attach PV Input Extension Cable to NOAH 2000. 3. Secure all cables with Cable Locker (Torque 1.5N·m). 4. Connect micro-inverter to NOAH 2000, then plug into household socket. 5. Connect solar panels to NOAH 2000. APPLICATION 2：NOAH 2000（×1）+SOLAR MODULE（×4） Connect DC Output Cable to NOAH 2000.

  • Page 8: Application 3: Noah 2000（×2）+Solar Module（×4

    APPLICATION 3: NOAH 2000（×2）+SOLAR MODULE（×4） 1. Connect DC Output Cable to NOAH 2000. 2. Attach PV Input Extension Cable to NOAH 2000. 3. Secure all cables with Cable Locker (Torque 1.5N·m). 4. Stack 2 units together. 5. Connect micro-inverter to NOAH 2000, then plug into household socket. 6.

  • Page 9: Mounting Method

    MOUNTING METHOD FLOOR INSTALLATION NOAH 2000 supports stacked installation, with a recommended maximum of 4 units. Fix-bracket can be used to enhance stability as follows: 1. Install Fix-Bracket onto NOAH 2000 (Torque 1.5N·m). 2. Mark the wall after positioning NOAH 2000. 3.

  • Page 10: Wall-Hung Installation

    WALL-HUNG INSTALLATION NOAH 2000 supports Wall-Hung to minimize the use of balcony floor space. *This Wall-Hung bracket is sold separately. HOW TO START POWER ON/OFF Short press the main power button for 1 second to turn on; long press the main power button for 3 seconds to turn off. Note: The figures are for reference only.
  • Page 11 2. Click “Register” to create an account. 3.Create a power plant: Set the time and location according to the actual situation, and fill in the PV capacity and grid electricity price information. Configure Network 4. Connect Noah 2000 to the network 4.1 Find and enter the "Plant"...
  • Page 12 Note: 1). When stacking multiple devices, only the topmost device needs to be turned on, and the other devices will automatically turn on. 2). When stacking multiple devices, simply light up the IoT icon of the topmost device and do not light up the IoT icons of the other devices.
  • Page 13 Set Operation Mode 6. Set Operation Mode 6.1 Click "Add time", add a time period, and select a work mode for that time period. Load First Mode: It is a setting that prioritizes the use of photovoltaic power to power the load. If the photovoltaic energy generated is more than the System Output Power you have set, the excess energy will be stored in the battery.
  • Page 14 7.1 Click the settings button in the upper right corner to enter the settings page. 7.2 Click on "Associated Inverter" to associate it with your inverter. Note: This setting only applies to scenarios used in conjunction with Growatt NEO Micro Inverter. 8. Set System Output Power 8.1 Click “System Output Power”...

  • Page 15: Cold-Start

    COLD-START When the battery temperature is between -30°C and -20°C, connecting solar panels with photovoltaic input can automatically heat the battery to the working temperature, allowing the NOAH 2000 to function normally, thus enabling its use in low-temperature environments. Battery temperature Remaining heating time/min -30℃...

  • Page 16: Malfunction

    Solution Fault Code Please charge promptly. If the problem persists after 2-3 Low Battery Voltage Alarm hours of charging, contact Growatt Customer Service Center for repair. Turn off photovoltaic input and restart the product. If the High Battery Voltage Alarm issue continues after multiple attempts, contact Growatt Customer Service Center for repair.
  • Page 17 Battery Overdischarge Restart the product. If the problem persists after multiple Current Alarm attempts, contact Growatt Customer Service Center for repair. Communication Failure with Restart the product. If the problem persists after multiple attempts, contact Growatt Customer Service Center for repair.

  • Page 18: Main Troubleshooting

    Recheck if the PV connection indicator on the LED screen is lit. LED screen is lit. All above are fine, but still no PV input in Contact Growatt Customer Service Center for NOAH 2000. repair. Check if the DC output cable is properly Recheck if the DC output interface is in good connected.
