Audient ORIA Manual

Audient ORIA Manual

Immersive audio interface & monitor controller
Hide thumbs Also See for ORIA:
Table of Contents

Advertisement

Quick Links

Download this manual
ORIA
Immersive Audio Interface
& Monitor Controller
Manual V1.5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ORIA and is the answer not in the manual?

Questions and answers

Related Manuals for Audient ORIA

Summary of Contents for Audient ORIA

  • Page 1 ORIA Immersive Audio Interface & Monitor Controller Manual V1.5...
  • Page 2 20 outputs with an efficient combination of hardware and software. Whether you are monitoring in 9.1.6 immersive, 7.1 surround sound, stereo or even Mono, ORIA is flexible and powerful enough to handle a plethora of contemporary audio standards.
  • Page 3 Installation/Setup What’s In The Box Initial Setup Mac Setup Windows Setup Mac Multichannel Setup Windows Multichannel Setup Using ORIA as a Standalone Monitor Controller Registration with Audient ARC Firmware Update Procedure Hardware Features ORIA Settings Mic Preamps Speaker Monitoring Headphone Monitoring...
  • Page 4 Software Features Profiles Monitoring Room Solo/Mute Groups Metering Menu Bar Low Latency Software Mixer System Panel Output Calibration Manual Calibration Controllers iPad App Stream Deck EUCON Keyboard Shortcuts Safety Information Rack Mounting Warranty Information...

  • Page 5: Declaration Of Conformities

    Declaration of Conformities FCC Part 15B This apparatus has been tested and found to comply with the limits of a class-A digital device, pursuant to Part 15B of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 6 CE standards and directives for an audio product designed for consumer use. We, Audient Ltd, declare that the product, the ORIA, to which this declaration relates, is in material conformity with the appropriate UKCA standards and directives for an audio product designed for consumer use.

  • Page 7: Installation And Setup

    Installation & Setup...

  • Page 8: What's In The Box

    What’s In The Box 1 x ORIA Unit 1 x Mains Power Cable 1 x USB C-C Cable 1 x Sonarworks (™) SoundID Reference Measurement Microphone...

  • Page 9: Initial Setup

    Initial Setup Unpack your ORIA, plug in the included power cable and connect it to a USB port on your computer. If your computer doesn’t have the appropriate USB port you may need to use a third party cable. Use ORIA’s Control Wheel to navigate through the front panel screen and take control of Motion UI.

  • Page 10: Mac Installation

    Application into your applications folder. Windows Installation ORIA will require drivers to work on Windows to ensure your computer and ORIA will work together correctly. You can download the drivers from the ORIA website: audient.com/ORIA/downloads. Once downloaded, run the .exe file to start the installation process.
  • Page 11 Core Audio drivers, it does allow for playback or surround sound media from supported media player or web browsers To locate this, connect the ORIA to your Mac and open “AudioMIDI utility” from the macOS Launchpad. Now, from the list of connected devices select ORIA. Click on the ‘Outputs’...
  • Page 12 Firstly, open the Control Panel from the windows search bar, and select “Sound”. Once the “Sound” pop-up opens, locate the ORIA output “Speakers” as shown in the screenshot below.
  • Page 13 When being used as a Standalone Monitor Controller, ORIA can take audio from either its ADAT input or via the Optional Dante Card using the Input source control of the ORIA software. You will still need to connect ORIA to the computer via USB initially in order to create your Profiles using the ORIA Control Application and store them on ORIA.
  • Page 14 You will then receive a verification email to your Inbox but you may need to check your Spam/Junk folders. Once you’ve verified your account, register your ORIA by entering the serial number and the unique 4-digit PIN found on the underside of ORIA.

  • Page 16: Firmware Update Procedure

    Help > Check for Updates If an update is available, the ORIA control app will notify you. Click ‘OK’ to begin the firmware update process.
  • Page 17 You can now choose to update from audient.com or from a local file. If your computer has an internet connection you would want to select ‘From audient.com’ to ensure you are installing the latest firmware version. If your computer does not have an internet connection, please contact support@audient.com...

  • Page 18: Hardware Features

    Hardware Features...
  • Page 19 Hardware Features Headphone Output Selection Buttons Profile Selection Button Volume Button Channel Select Button Control Wheel 48V Phantom Power Button Mic/Line/Inst Inputs Headphone Instrument Input Selection Button Motion UI Outputs Display Panel Function Button Down Mix Selection Button Stereo 2 Outputs Stereo 1 Optional AoIP Card...
  • Page 20 ORIA. Use the Control Wheel to cycle through the options. Control Wheel Power Choose to switch off the ORIA (press the Control Wheel to power on the ORIA). Brightness Control the overall brightness of all LED’s and the display panel.
  • Page 21 Function Change what feature is assigned to the ‘Function Button’: Status Check the current sample rate and clocking sources. If the status light is: Green • - this means that the unit has been successfully clocked • Amber - the unit has detected a clock signal but at the wrong sample rate •...

  • Page 22: Factory Reset

    AOIP Check the status of the networked audio connection (Active or Unactive) and your ORIA’s IP address. Factory Reset Restore the ORIA to its factory settings. **Be aware that this will remove any of your currently saved settings and Profiles.**...
  • Page 23 Mic Preamps The ORIA features two Audient Console Mic Preamps that can deliver up to 60db of gain, as well as receiving Line and Instrument level sources via the front-facing combi-jacks. When you press either of the 1 or 2 buttons you can then affect settings for each input independently.

  • Page 24: Phantom Power

    Phantom Power Press 48V to apply Phantom Power. The LED will turn red to indicate Phantom Power is now active on the selected Mic Preamp Channel. Phantom Power can only be applied to the XLR input, this to prevent accidental damage to external instrument sources.
  • Page 25 Speaker Monitoring You can quickly access a variety of monitoring options from the front panel. Volume Turn the Control Wheel to adjust the Volume for your chosen speaker configuration. When the Main Outputs are selected, hold down the Control Wheel to mute or un-mute the main outputs.
  • Page 26 Toggle on/off a pre-selected monitoring process via the ‘Function Button’. The function of this button can be adjusted in the ORIA Control Application and is explained later in this manual. • Polarity - to check the phase coherence of your stereo mix.
  • Page 27 Active Profile. For example if your Profiles reference level volume is -20dB, however you are currently monitoring at -15dB, you can use RTR to quickly snap back to -20dB precisely. This will be shown on ORIA’s front panel screen in the System Menu.

  • Page 28: Headphone Monitoring

    • MONO - outputs a mono-summed version of your stereo mix to check mono-compatibility. Headphone Monitoring ORIA provides two independent outputs for headphone monitoring, either whilst recording or mixing. Each output can be fed from a variety of sources via the System Panel in the ORIA Control Application.
  • Page 29 Metering You can toggle through all of ORIA’s output meters (Surround, Headphone 1, Headphone 2, Stereo, ADAT or AoIP) by pressing the Control Wheel. The display panel will default back to metering the outputs of your chosen speaker configuration after 3 seconds without hardware interaction.
  • Page 30 Connectivity...

  • Page 31: Stereo Outputs

    Stereo Outputs ORIA provides two identical, balanced* stereo outputs (ST1 and ST2) to feed your chosen stereo speakers. These outputs are relay-switched from the Stereo channels of the surround outputs. Surround Outputs The ORIA also provides a comprehensive selection of balanced* surround outputs to feed your chosen speaker configuration.
  • Page 32 AES Pinout In order to provide 16 channels of audio via a single DB25 port, ORIA uses a standard TASCAM pinout on its AES DB25 output as per the diagram below: A standard Analog DB25 to 8x XLR loom can be used to break out the DB25 to 8 XLR connectors, with each XLR carrying two channels of audio.

  • Page 33: Word Clock

    Controller in a setup or you may get clicks and pops in your audio due to clocking errors. ORIA as the Controller: Wordclock can be sent out of ORIA via the BNC Output to other devices to allow other devices to sync to ORIA’s clock.
  • Page 34 Connecting ORIA to a single device via BNC: ORIA ASP880 75 Ohm termination engaged Connecting ORIA to multiple devices via BNC: ORIA 2 x ASP880 BNC-T Connector 75 Ohm termination engaged Key: BNC Word Clock Cable Optical TOSlink Cable...
  • Page 35 ASP880 Optical TOSlink Cable Please note that ORIA cannot send the clock via ADAT as it has no ADAT outputs, if you wish to use the ORIA as a master clock for an ADAT device, then a BNC connection must be used.

  • Page 36: Setting The Clock Source

    Once you have connected your external devices to ORIA as per the example diagrams, you will need to instruct ORIA where to take its clock from. This is done in the System Panel of the ORIA software. More information regarding this can be found in the System Panel section of the manual.
  • Page 37 Now use the routing matrix to route the channels of the Transmitter device to the correct speaker outputs of ORIA. Below is an example of a 9.1.6 setup and a 7.1.4 setup. Note that the 7.1.4 setup skips the Lw, Rw, Ltm and Rtm speaker channels as these are not used in a 7.1.4 speaker configuration.
  • Page 38 Setting up the ORIA Control Application Once you have set up the ORIA as a receiving device in the Dante© Controller application, you can use the Dante card (AoIP) as an Input Source in the ORIA Control Application. Firstly, you may need to adjust your clock source. Open the System Panel of the ORIA Control Application, and in the Preferred Clock Source section, ensure that AoIP is set as your clock source.
  • Page 39 Additional Clocking Information When using the AoIP clock as your Preferred Clock Source, it is still possible to use ORIA to distribute this clock via the BNC output in order to Sync an ADAT device connected to ORIA. Please note that if using the Dante card as your Input Source, any ADAT devices connected to ORIA must be clocked via the BNC word clock output of ORIA.

  • Page 40: Technical Specifications

    Technical Specifications Mic inputs: • Gain: 60dB • Max Input Level: +18dBu • Crosstalk: <105dB • THD+N: 0.0015% / -96dB • EIN: -129dB • CMRR: -85dB • SNR: 100dB • Frequency Response: ±0.5dB 20Hz to 40kHz • Input Impedance: 1.5kΩ Balanced Line input: •...

  • Page 41: Headphone Outputs

    Headphone Outputs: • Lineup Level: +18dBu • THD+N: 0.0007% (-103dB) • Dynamic Range: 124dB • Crosstalk: -115dB • Frequency Response: ±0.25dB 10Hz to 40kHz • Output Impedance: <50 Ω Unbalanced • Max Level @ 30R: 5.47V Peak, 3.87Vrms, 997mW • Max Level @ 60R: 7.4V Peak, 5.29Vrms, 912mW •...

  • Page 42: Software Features

    Software Features...
  • Page 43 Profiles Metering The ORIA Control Application is an intuitive platform designed to monitor, calibrate and control your speaker array, with the ability to tailor the system to suit your layout and room. Audient have partnered with the groundbreaking speaker calibration company,...

  • Page 44: Creating A New Profile

    Profiles which have been created for different monitoring formats or target modes. A total of 32 Profiles can be stored on ORIA itself. It is worth noting that although Profiles are stored directly on ORIA’s hardware, they are controlled using the Profiles Panel or the Profile button on the front of the unit.

  • Page 45: Delete A Profile

    Delete a Profile To delete a Profile, right click on the Profile name in the Profile Panel and select delete. A window will appear asking you to confirm your deletion. Profile Organisation The Profiles list is split into two sections. The ‘Favourite’ Profiles (F) are the four listed above the dividing line, each with their own number.

  • Page 46: Selecting A Profile

    Profiles may be reordered at any time, simply by holding down the left mouse button on the chosen profile and dragging it to the chosen location. When reordering profiles, the following logic applies: Favourite -> Favourite: The two Profiles will swap locations. Favourite ->...
  • Page 47 If you try to change Profile or close the ORIA Control Application without saving the changes you’ll see a Dialogue Box window asking if you wish to save the changes to the current Active Profile, create a new Profile or discard the changes.

  • Page 48: Importing And Exporting Profiles

    ORIA Control Software. Importing and Exporting Profiles The ORIA Control Application allows you to export your manual Profiles so they can be backed up or shared between users. In addition, there is the option to import both Sonarworks and ORIA profiles from an external file.
  • Page 49 Exporting an ORIA Profile To export the currently active ORIA Profile, go to the menu bar and navigate to File > Export ORIA Profile. Now, give the Profile a name and select the location that you wish to export your Profile file to.
  • Page 50 Importing an ORIA Profile To import an ORIA Profile, go to the menu bar and navigate to File > Import ORIA Profile. A Finder or File Explorer Window will now open, allowing you to select a previously saved Profile. Once you have selected your File, click ‘Open’.
  • Page 51 Please note that you can have a maximum of 32 Profiles, so if you have filled every slot, the ‘Create New Profile’ will be greyed out and you will have to overwrite an existing setting or discard changes. Overwrite Existing Profile - Selecting ‘Overwrite Existing Profile’ will allow you to select which existing Profile you wish to overwrite.
  • Page 52 Sonarworks SoundID Reference Measurement application. Once you have selected your File, click ‘Open’. As per importing an ORIA profile, you can now choose whether to create a new Profile or if you wish to overwrite an existing one.
  • Page 53 Monitoring Input Source Select your audio inputs: • USB • ADAT • Software Mixer, Master Mix • Software Mixer, CUE A • Software Mixer, CUE B • Dante Output Select your audio outputs: • ANALOG • AES Volume Control the overall volume of your selected speakers. This is controlled either by clicking and dragging the control or by using the Control Wheel on the front of the unit.
  • Page 54 Sums the Left and right channels together for mono compatibility checking. Polarity Flips the Phase of the Left channel and sums the outputs to MONO. Return To Reference Returns the Output level of ORIA to the Active Profiles saved Output Level.
  • Page 55 Room This section provides a visual display of your speaker configuration. The white USER icon indicates the direction that the listener would face. The colours of the units indicate which of the speaker Groups they belong to: • HEIGHTS = Light Purple •...
  • Page 56 Solo /Mute Speakers in the Room may be Solo’d or Muted using the following keyboard shortcuts: • Mute - Left Click • Solo - Shift + Left Click Whilst a speaker is Solo’d, the Mute function will become unavailable for all other speakers and groups.
  • Page 57 Groups This monitoring function allows you to Mute or Solo predetermined groups of speakers: • HEIGHTS (Ltf, Rtf, Ltm, Rtm, Ltr & Rtr) • SIDES (Lw, Rw, Ls, Rs, Lrs & Rrs) • FRONTS (L, R & C) • SUBS (LFE/SUB) •...
  • Page 58 Metering The ORIA Control Application provides a straightforward metering solution to allow you to quickly check your levels, output routing and the impact of ORIA’s digital signal processing (DSP). Meter settings are entirely independent of your Profiles, so will not change when moving between Profiles.

  • Page 59: Muting Channels

    Muting/Soloing Channels If a speaker channel is muted, then the meter for this channel will also be greyed out. If a channel or channels are Solo’d, all other channels will be blacked out. Muting Channels Soloing Channels Down Mix Status If you have configured a renderer in the System Panel then you can quickly check the current Down Mix Status in the bottom right of the meters.
  • Page 60 More Information regarding the mixer window can be found later in this manual. Light/Dark Mode The ORIA Control Application can be viewed in Light or Dark mode, depending on your preference and your studio environment. Dark Mode Toggle...

  • Page 61: Speaker Channel

    Speaker Channel Shows the name of the Channel currently being adjusted. Mute (M) You can Mute the individual speaker selected. You can Mute a channel by pressing the ‘M’ key on your keyboard whilst in Setup Mode. Solo (S) You can Solo the individual speaker selected. You can Solo a channel by pressing the ‘S’...
  • Page 62 Reset The Reset Button sets the channel back to its default settings. A Dialogue Box will appear to confirm you wish to reset the settings to ensure settings are not reset by accident. By default, 8 EQ points will be available per channel to adjust the calibration of that speaker output.

  • Page 63: Output Controls

    Output Controls In this section you can control various options for each individual output: At the bottom of the Setup Panel, there are three further controls for speaker calibration. Trim The first control is Trim, which raises or lowers the level of this speaker by up to 12 decibels, in increments of 0.1 decibels.
  • Page 64 This is important in audio systems where the individual speakers may not be able to faithfully recreate lower bass frequencies, and so redirecting these lower frequencies to the subwoofer may provide a more optimal experience. Click and drag this control to define the crossover frequency, below which audio will be sent to the subwoofer and above which the audio will be sent to the defined speaker channel.
  • Page 65 Low Latency Software Mixer The ORIA Control Application includes a software mixer, providing the ability to directly monitor your inputs with almost zero latency. This is ideal when using the Microphone and Digital inputs for tracking. The Software Mixer allows you to make up to three stereo mixes. There is a Master Mix which is designed to feed the studio monitor for monitoring by the engineer while tracking.

  • Page 66: Channel Types

    SMUX mode with a reduced channel count (4 channels per port). DAW Channels These are the signals being played back from your DAW. The ORIA has 8 DAW Return Channels meaning you can have multiple outputs from your DAW for more complex foldback mixes.

  • Page 67: Channel Features

    Channel Name By double-clicking on the name of the channel you can rename it to help you organise your ORIA software mixer. You could name a channel ‘Kick’ or ‘Snare’ for example. Phase Flip Inverts the polarity of the signal by 180° to stop phase cancellation. This is useful if you are micing the rear of a guitar amplifier or the underside of a snare drum.
  • Page 68 Pan Control Allows you to send the audio to the left, to the right or anywhere between on your Main Monitor Mix or Cue Mixes. Stereo Grouping Allows you to group two adjacent channels together into a stereo channel with a single fader controlling the level of both channels.

  • Page 69: Mix Settings

    Mix Settings Mix Selection Mix Mute CUE Mix Name Mix Level Mix Meters Chronometer Mix Selection Clicking on one of the mixes allows you to make changes to that mix. When a mix is selected, it expands to reveal additional controls for that mix. Cue Mix Name Double-clicking on a Cue Mixes name allows you to rename the Cue Mix.

  • Page 70: Master Section

    OPT control. Master Volume The master volume control of the Mixer app allows you to control the ORIA’s overall level without having to move back to the main Control window or use the volume control on...
  • Page 71 Firstly, we would want to setup the monitoring for the Engineer. For this, we would use the Master Mix by clicking on this mix on the right-hand side of the mixer. In the ORIA Control Application, you would want to set your Input Source as “Master Mix”.
  • Page 72 CUE A mix. This can be assigned to a headphone output In the System Panel of the ORIA app. In the software mixer, select the CUE A mix by clicking on it on the right-hand side of the mixer.

  • Page 73: System Panel

    System Panel The System Panel at the top of the ORIA Control Application lets us look under the hood at the more advanced settings for connectivity and control. The System Panel is split into 3 different Pages which are selectable using the tabs on the left-hand side...

  • Page 74: Function Button

    If the indicator is amber, you will need to adjust either ORIA’s sample rate or the sample rate of your external device so that the two devices are operating on the same sample rate.

  • Page 75: Headphone Setup

    Renderer The Renderer Page is for connecting ORIA directly to the Dolby Atmos Renderer, both to use the Down Mix Button on the ORIA hardware to cycle through different down mixing format options, but also so that the Dolby Atmos Renderer can feed back information to ORIA about which Down Mix format is in use.
  • Page 76 Target Choose from the list of renderers available on your system under the type selected. If the Dolby Atmos Renderer is open and running on the same computer, the computer’s name will appear in the Target drop down list. Select the local target and the Connection Status at the top right of the panel should change from ‘Unavailable’...
  • Page 77 To alleviate this issue, we have implemented a solution in the ORIA hardware where you can connect any speaker output to any AES channel, enabling much neater cable routing than would otherwise be possible, where one AES stream can provide audio to two adjacent speakers rather than using the default routing configuration.
  • Page 78 Remote page of the System Panel. Any device that is approved will automatically connect to ORIA when used on the same network. A green tick icon is shown next to the device when a device is connected to ORIA If the request is denied, the device will not be connected to ORIA.
  • Page 79 Forgetting Approved Devices If you wish to remove a device from the Approved Devices list, click the ‘i’ icon next to the device. A pop-up notification will ask you to confirm that you’d like to ‘forget’ this device. Unblocking Blocked Devices Similarly, if you wish to remove a device from the Blocked Devices list, click the ‘i’...

  • Page 80: Output Calibration

    Automatic Calibration When you purchase an ORIA you can take advantage of a 60 day free trial version* of the industry-leading measurement and calibration software SoundID Reference for Multichannel by Sonarworks(™). This comprehensive tool measures and calibrates a multichannel setup in less than an hour so you can get up and running (almost) immediately.
  • Page 81 SoundID Reference Profile with your desired Target Mode. For more information on this process please consult Sonarworks product documentation. Once complete, you’ll be given the option to ‘Export Preset to Device’. Select ORIA from the list of devices.
  • Page 82 Now, select ‘Direct transfer to Audient ORIA Control Application’ and click ‘Next’. This will automatically open the ORIA Control Application and present you with a dialogue box asking you to choose whether you overwrite an existing Profile in the ORIA Control Application or create a new one:...
  • Page 83 If you create a new Profile, you’ll be prompted to give it a name. If you choose to overwrite an existing Profile, you’ll be given an option of which Profiles are available to overwrite. The new Profile will now appear in the Profile Panel. Please note Profiles created with SoundID Reference will be denoted by a Sonarworks ‘S’...
  • Page 84 Windows Due to software limitations, at this moment in time, Sonarworks Sound ID Reference Profiles cannot be loaded into the ORIA Control Application on Windows. This functionality will be added via a driver/firmware update imminently. Adjusting a Profile Please note that if you are using a Profile based on Sonarworks(™) measurements, the EQ in the Setup Mode section will automatically be locked to prevent alterations.

  • Page 85: Manual Calibration

    If using a third party software, it is not possible to directly import your settings into ORIA, the speaker calibration settings must be entered manually. The third party software should give you an EQ curve you can apply to each channel, as well as Trim and Delay settings.
  • Page 86 Controllers...
  • Page 87 Controllers The ORIA Control Application can be remotely controlled via a number of external devices to help ORIA fully integrate into your setup and provide maximum flexibility for your monitoring. ORIA can currently be controlled using the ORIA Remote iPad app, the ORIA Control Stream Deck Plug-in and via Avid’s EUCON Protocol.
  • Page 88 ORIA iPad App Never miss a beat with ORIA’s iPad App. The power of touch grants you remote access to all of ORIA’s control features from one centralised control hub. Adjust levels, audition speakers, switch profiles and monitor your metering - all directly from your desktop.
  • Page 89 With ORIA connected to your computer via USB and the ORIA Desktop Software App running, you are ready to connect to the ORIA iPad Remote App for complete touch control of ORIA. Firstly open the Apple App Store, search for the ORIA iPad Remote and install it onto your device.
  • Page 90 Select your host computer from the list to complete the connection setup. You will now be asked to open the ORIA Control Application on your Mac or PC and accept the connection to the iPad. On the ORIA Control Application, you will now see a pop-up notification asking whether you wish to Accept, Deny or Block Connection.
  • Page 91 Home - The Home Page is the main page of the ORIA iPad Remote and gives you an overview of all the main controls of ORIA. A quick overview of these functions can be found on the following page.
  • Page 92 Profile Selection Here you can select from the various profiles that you have created in the ORIA Control Application, including four favourite Profile slots. Simply tap a Profile to make it your currently ‘Active Profile’. Group Mute and Solo These controls let you either mute or solo a particular speaker group. You can choose from the Heights, Sides, Fronts, Subs and Stereo speakers.
  • Page 93 Room - The Room Page gives you per-speaker control of your setup with a visual representation of your speaker setup. A quick overview of these functions can be found on the following page of this manual. Profile Selection Room Section Group Mute and Solo’s Profile Selection This section is a repeat of the Profile Selection section found in the Home Page.
  • Page 94 Monitoring - The Monitor Page displays an expanded view of the Monitor section found in the Home Page. Please see the Home Page section above for an overview of these controls Profile Selection Main Volume Control Input Source Renderer Status Global Controls Group Mute and Solo’s...
  • Page 95 Pre/Post Control Pre/Post Control ‘PRE’ is selected as the default, and shows the signals entering the ORIA Desktop Software App from your DAW outputs. ‘POST’ shows the signals leaving the ORIA after speaker calibration processing. POST metering mode will also take the volume control...
  • Page 96 Profile Selection - The Profile Selection Page is simply an expanded version of the Profile Selection section found on other tabs, allowing you to select which one of your Profiles is currently active as well as any other Profiles you have outside of the Profiles assigned to the four favourite slots.
  • Page 97 Connection - The Connection Page is used should you need to re-connect the ORIA iPad app to the ORIA or wish to change the currently connected device.
  • Page 98 Volume Control Autolock App Colour Mode Here you can set the ORIA iPad Remote to display in either Dark mode or Light mode to best suit your studio environment. You can also set this to System Default so the ORIA iPad app will automatically adjust to the global iPad settings.
  • Page 100 ORIA’s Stream Deck integration allows you to control a majority of ORIA’s functions remotely using any device from the Stream Deck family. This means you can keep ORIA installed in a rack, but still have complete control over your monitoring whilst remaining in the sweet spot of your speakers.

  • Page 101: Installation

    Profiles To allow for a quick setup, the ORIA Control Plug-in includes Profiles for all of the common Stream Deck Devices. This automatically loads all the required controls onto your Stream Deck device so you can immediately begin using your Stream Deck with ORIA.
  • Page 102 Stream Deck MKII The Stream Deck MKII Profile is made up of two pages. Page One includes the Volume Controls, Monitor Controls, Input Selection and Profile Selection. Page two includes the Mute and Solo Controls for the Speaker groups. Stream Deck + The Stream Deck + Profile is made up of three pages.
  • Page 103 Stream Deck XL The Stream Deck XL Profile is made up of two pages. Page One includes the Volume Controls, Monitor Controls, Input Selection and Profile Selection. Page Two includes the Mute and Solo Controls for the Speaker groups. Stream Deck Mini The Stream Deck Mini is made up of three pages.
  • Page 104 Stream Deck Neo The Stream Deck Neo Profile is made up of four pages. Page One contains the Volume and Monitor controls and your Input selection. Page Two contains the Profile Selection. Page Three contains the Heights, Sides, Fronts and Subs Solo/Mute Controls and Page Four contains the Stereo Solo/Mute and Solo/Mute Clear.
  • Page 105 Layouts larger than 3x2 on the Mobile App. Actions If you wish to create your own custom Profile containing ORIA controls, then you can do so using the various ORIA Control Actions included in the ORIA Control Plug-in. Below is...
  • Page 106 Volume - Volume allows you to adjust the output volume of ORIA. On Stream Decks without Dial controls you will typically have two volume buttons, one to increment upwards and another to decrement downwards. The button can either be pressed once to increment/ decrement the volume, or pressed and held to make larger volume adjustments On Stream Deck +, the Volume action can also be assigned to one of the 4 dials.
  • Page 107 Mute - Mute disables/enables the Output on ORIA. Controls: Output - Sets which output the Mute Action is affecting (Please note in ORIA Control V1.2, only the Master output is available). Dim - The DIM action reduces the ORIA output by a predetermined amount, perfect for quickly talking to an artist without needing to pause or mute playback.

  • Page 108: Reference Level

    Mono - Mono will sum the stereo output of ORIA to a single Mono signal, allowing you to check the mono compatibility of your mix. There are no additional controls for the Mono action. Polarity - Polarity will inverse the phase of the left stereo channel and then sum the left and right channels together.

  • Page 109: Input Source

    Input Source - Input Source allows you to select which of the various input sources (USB, ADAT, Dante… etc) is currently being used by ORIA. Controls: Action - This control provides two options; “Step Through” or “Set To”. “Step Through”...
  • Page 110 Profile - The Profile button allows you to select which Profile is currently active on ORIA. Please note that only the top 4 ‘Favourite’ Profiles are available in the ORIA Control Stream Deck plug-in. When a Profile is active the button will display a blue gradient.
  • Page 111 Group - The Group action allows you to either Solo or Mute a specific Speaker Group (Fronts, Sides.. etc) on ORIA. Controls: Group - Here you can select which Speaker Group is being controlled by this button. Action - Either Cut or Solo can be selected as the Group action.

  • Page 112: Troubleshooting

    If a warning sign appears on the button when pressed, this indicates that Stream Deck cannot communicate with the ORIA Control Application. Firstly, check that the ORIA Control application is open. If it isn’t, open it from your Applications folder or Start Menu. If the ORIA Control Application is open, please quit the application and re-open it so that the Stream Deck Control software can re- establish its communication with ORIA.
  • Page 113 To get started with EUCON, download EuControl from Avid’s website here: www.avid.com/resource-center/latest-eucon-updates-avid-control-surfaces. It is also important to ensure that you are using the latest version of the ORIA Control from the Audient Website. Once installed and launched, open the EuControl Settings Panel from the Status Menu (MacOS) or System Tray (Windows).
  • Page 114 Click on ORIA to highlight it. At the bottom where it says ‘Lock to Application’, select the ‘Monitor and Control Room’ checkbox. This allows you to adjust the monitor level using the Monitor Control dial on the Avid Dock, S4 and S6, even if the ORIA app is not in focus.
  • Page 115 Click on ORIA to highlight it. At the bottom where it says ‘Lock to Application’, select the ‘Monitor and Control Room’ checkbox. This allows you to adjust the monitor level using the Monitor Control dial on the Avid Dock, S4 and S6, even if the ORIA app is not in focus. Important Note: It’s important to note that the Preconfigured Layouts will only be available when...

  • Page 116: Control - Centre

    At the bottom left-hand of the Page, there are three keys that open the Speaker Group, Speaker and Input Source Pages, which are explained below. Finally, In the bottom right-hand corner of the Page, there are two keys that allow you to open the ORIA Control App, or the ORIA Control App Mixer Window.
  • Page 117 The Speaker Groups page provides keys for Muting and Solo’ing the five Speaker Groups available on ORIA. There are also keys to clear all Mutes and Solos. The Home Key in the bottom right-hand corner returns you to the Home Page.
  • Page 118 Speaker Groups Page The Speaker page is similar to the Speaker Groups page but allows you to Mute and Solo individual speaker outputs on ORIA. There are also keys to clear any Mutes or Solos currently active. To cover all 16 speaker outputs, the speaker page is split over two pages. You can move between pages by swiping across the screen.
  • Page 119 Input Sources Page The Input Sources Page provides six Keys allowing you to select the Input Source being used by ORIA. As with the other pages, a Home Key is provided to return you to the Home page.

  • Page 120: Input Source Control

    Home page on the Control Centre Section. There are 4 Selection keys to select from the 4 ‘Favourite’ Profiles and a key to launch the ORIA Control Application. The Lower Row provides 6 keys, allowing you to select from the six input sources.

  • Page 121: Monitoring Screen

    Monitoring Screen The Monitoring Screen provides Keys to select from the six Input Sources and a Mute key for the five Speaker groups. The other controls on this screen are not mapped.

  • Page 122: Mixer Screen

    Mixer Screen The Mixer Screen provides control of the various faders found in the ORIA Control Application’s Software Mixer. Here you can adjust the level of each channel fader and also adjust the panning of each channel. If being used with a EUCON Controller with Faders, such as the S1, then the mixer window will be mapped to the hardware faders whilst the ORIA Control Application is in focus to allow for hardware control of the ORIA Control Application’s Software mixer.
  • Page 123 Master DIM The master Mute Key allows you to toggle Master Dim On and Off, which reduces the overall volume by a chosen level. The level of reduction can be changed in the ORIA Control Applications System Menu. Master Mono The Master Mono key toggles Master Mono ON or OFF.
  • Page 124 The Speaker Mute keys will toggle the mute ON and OFF for the selected Speaker Output. Show ORIA Control App The Show ORIA Control App Key will bring the ORIA Control app into focus and to the forefront of the Operating system’s view. Show ORIA Control Mixer The Show ORIA Control Mixer Key will bring the ORIA Control Mixer into focus and at the forefront of the Operating system’s view.
  • Page 125 I cannot access the ORIA Preconfigured Layout whilst using EUCON with my DAW. The ORIA Control Application must be in focus in order to have full access to the ORIA Preconfigured Layout. For example, if you instead have a DAW in focus, then the DAW’s preconfigured layout will be shown instead.

  • Page 126: Keyboard Shortcuts

    Keyboard Shortcuts Room Panel Buttons: Toggle Solo - Shift + Click on speaker button Clear all mutes - Option + Click on a muted speaker Clear all solos - Option + Click or Option + Shift + Click on a solo’d speaker Keyboard Shortcuts: Show/Bring up the Meter Window - Command + Shift + M Navigate EQ Bands* - Command + Left/Right arrows...

  • Page 127: Safety Information

    Safety Information Tel: 0044 1256 381944 IMPORTANT SAFETY INSTRUCTIONS • Read instructions - All the safety and operating instructions should be read before the product is operated. • Retain instructions - The safety and operating instructions should be retained for future reference. •...

  • Page 128: Rack Mounting

    Rack Mounting ORIA requires 1U of vertical rackspace and a minimum of 400mm rack depth, allowing for cables. It weighs 3.5kg and for fixed installations - such as a studio - the four front panel mounting screws will provide adequate support. The front panel depth is 8mm at the mounting positions.

  • Page 129: Warranty Information

    We accept liability to repair or replace your ORIA as described above. We do not accept any additional liability. This warranty does not affect any legal rights you may have against the person who supplied this product - it is additional to those rights.
