- Page 1 Drawing : - TPC524 Issue : - 3 Date : - 19/01/24 BD150 BD150 BD150 BD150 DEHUMIDIFIER DEHUMIDIFIER DEHUMIDIFIER DEHUMIDIFIER (SINGLE VOLTAGE) (SINGLE VOLTAGE) (SINGLE VOLTAGE) (SINGLE VOLTAGE) OWNER’S MANUAL www.eipl.co.uk Page 1 of 12...
-
Page 2: Safety Information
Drawing : - TPC524 Issue : - 3 Date : - 19/01/24 SAFETY INFORMATION Children shall not play with the appliance. This appliance can be used by children from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the application in a safe way and understand the hazards involved. - Page 3 Before disposing all refrigerant should be evacuated and disposed of as required by local environmental laws. • If there is any damage to the appliance, DO NOT USE and contact EIPL. • The appliance must not be used in a potentially explosive atmosphere.
- Page 4 Drawing : - TPC524 Issue : - 3 Date : - 19/01/24 DEHUMIDIFIER PRINCIPLE Dehumidifiers remove moisture from the air that is circulating through the appliance. The resulting reduction of relative humidity helps prevent rust, rot, mould, mildew and condensation within the room, or other enclosed spaces where the dehumidifier is used.
-
Page 5: Installation
Drawing : - TPC524 Issue : - 3 Date : - 19/01/24 INSTALLATION POSITIONING: Position the appliance in the center of the room to be conditioned if at all possible. However, if a damp patch is particularly apparent the outlet grille should be pointed towards it. - Page 6 Drawing : - TPC524 Issue : - 3 Date : - 19/01/24 DRAINAGE: Under most operating conditions water will be produced continuously and it is important that it is drained away correctly and not allowed to spill. spillage will evaporate and will, therefore, have to be recycled through the dryer again, which in effect, only prolongs the drying period.
-
Page 7: Operation
To turn the unit off, turn the rotary switch to the OFF position. Turn off the power supply and disconnect. If, after carrying out the above procedures, the appliance does not appear to function properly, refer to the Trouble Shooting section, which follows, or contact EIPL. Page 7 of 12... -
Page 8: Routine Service
1. Insufficient air flow 1. Check all of the above Little or no water 2. Compressor fault 2. Contact EIPL extraction 3. Loss of refrigerant gas 3. Contact EIPL Little or no defrost 1. Faulty Timer 1. -
Page 9: Specifications
Drawing : - TPC524 Issue : - 3 Date : - 19/01/24 SPECIFICATIONS : BD150 ODEL : 915 mm (36 in) EIGHT : 610 mm (24 in) IDTH : 692 mm (27 in) EPTH : 75 Kg (165 lb) EIGHT... - Page 10 Drawing : - TPC524 Issue : - 3 Date : - 19/01/24 APPLIANCE SPARE PARTS LIST Description Part Number Product Part Number 10219MG-GB Compressor 3944965 By-Pass Valve 3020833 Condenser Coil 3020727 Evaporator Coil 3020732 Filter Dryer 3020957 Fan Motor 3030129 Fan Blade 3040116 PCB Timer 1619519 Solenoid Coil 3030454...
- Page 11 Drawing : - TPC524 Issue : - 3 Date : - 19/01/24 Page 11 of 12...
- Page 12 Bishop Auckland Suite 109, Newport News County Durham Virginia, 23606-2575 DL14 9AD Tel: +44 (0) 1388 664400 Tel: +01 757 873 6800 Fax: +44 (0) 1388 662590 Fax: +01 757 873 3632 www.eipl.co.uk www.ebacusa.com sales@eipl.co.uk sales@ebacusa.com Page 12 of 12...
