  • Page 1 axima Base mounted solenoid driven dosing pumps Your Choice, Our Commitment...
  • Page 2 "Five Year" working life Advanced design and manufacturing processes means SEKO's diaphragms are made of pure PTFE, ensuring compatibility with most chemicals. This also provides a superior life expectancy, which SEKO guarantees for 5 years, reducing operating costs. Steady dosing...
  • Page 3 Base mounted solenoid driven dosing pumps Model with flow rate from 0.4 to 1.5 l/h and pressures from 6 to 20 bar Model with flow rate from 2.5 to 4.2 l/h and pressures from 8 to 20 bar Model with flow rate from 4 to 8 l/h and pressures from 1 to 12 bar Model with flow rate from 7 to 18 l/h...
  • Page 4 Solutions for Water & Industry Maxima Analogue and digital version Analogue dosing pump with costant dosage Maxima MKL Analogue dosing pump with constant flow rate, with manual adjustment by control dial on the front panel 2 frequency range (0 – 20% or 0 – 100%) Power-ON led indicator and level control input Analogue dosing pump with proportional dosage...
  • Page 5 Base mounted solenoid driven dosing pumps Maxima Plus Analogue and digital version with electronic stroke length regulation Analogue dosing pump with proportional dosage Maxima Plus MGR Analogue dosing pump with constant flow rate, with manual adjustment; proportional flow rate according to an external analogue (4 –...
  • Page 6 Solutions for Water & Industry Overview Accessories Threaded water meters Flanged water meters Mixers TC1 - TH1 - TC0 Series FC Series Electric mixers, three-phases or single-phase, slow (200 rpm) or fast Single-jet water meters with pulse A high capacity helical vane (1400 rpm) and flange attachment, sender, dry dial and roller reading.
  • Page 7 Base mounted solenoid driven dosing pumps Flow Sensor Priming-aid Pump head with automatic degassing In order to assess the actual dosing Priming issues may occur with valve phase, the flow sensor can be used to dosing pumps with low flow rates detect the pump’s pulsations during and extreme suction lifts compared Where gases are metered, this...
  • Page 8 As part of a process of on going product development, SEKO reserves the right to amend and change specifications without prior notice. Published data may be subject to change. © SEKO, 850001-Maxima Layout and origin: Italy, _en, 12.2017...

  • Page 9: Table Of Contents

    MAXIMA Contents: First of all Installation Setting and operation Maintenance Troubleshooting How to contact us Maxima MPG Cod. EM00136006 rev. 1.1...

  • Page 10: First Of All

    1 FIRST OF ALL WELCOME Thank you for buying a Seko product. This dosage pump is made up of a control part that houses the electronics and the magnet and a hydraulic part that is always in contact with the liquid to be dosed.

  • Page 11: Pack Contents

    PACK CONTENTS MAXIMA MPG Complete pump Foot filter (Fig. 1) Injection fitting(Fig. 2) 4 m of PVC hose (transparent and soft) for suction and for connecting the bleeding valve up for manual priming (Fig. 3) 2 m of PE pipe (opaque and rigid) for connecting the pump’s outlet to the injection point (Fig.
  • Page 12 WARNINGS CAREFUL HANDLING, INSTALLATION AND COMMISSIONING OF THE PUMP HELPS TO PROVIDE A TROUBLE-FREE INSTALLATION. READ THE FOLLOWING WARNINGS BEFORE PROCEEDING TO INSTALL OR DO MAINTENANCE WORK ON THE PUMP. − All our pumps are tested using water. To dose chemical products that may react with the water (e.g. = Sulphuric Acid) all the internal parts of the hydraulic section must be dried.

  • Page 13: Technical Characteristics

    TECHNICAL CHARACTERISTICS Check the main characteristics of you pump on the plate. MAXIMA 240 Spm Type lit/h MPG912 2.25 230VAC 2.59 50/60 Hz 2.91 40 W Code MPG912ASC0M00 Serial N° Fuse 2 A L XXXXXX Your pump is one of the family of pumps listed in the table below: Pressure Flow Rate Connections...
  • Page 14 WARNING: When installing or carrying out maintenance on this equipment, always disconnect it from the power supply. Seko is constantly striving to perfect all its products, and we therefore reserve the right to make changes at any time without notice.

  • Page 15: Installation

    2 INSTALLATION WARNING: Before proceeding to install the pump, read all the paragraphs referring to it carefully. This pump must be installed in a position that makes connecting it to the chemical product tank and the injection point easy. This pump has a protection level of IP65 and so can be used outdoors. This pump must never be installed in positions in which it may be submerged.
  • Page 16 OVERALL DIMENSIONS AND DRILLING TEMPLATE Fig. 11: Overall dimensions – 610 series Fig. 12: Overall dimensions – 910 series Fig. 14: Drilling template for 610 series Fig. 15: Drilling template for 910 series Fig. 13: Drilling template for support Maxima MPG Cod.

  • Page 17: Plumbing Connections

    PLUMBING CONNECTIONS 1) Injection point 2) Injection fitting 3) PVDF gasket 4) Washer holder 5) Pipe clamp 6) Ring nut 7) Delivery pipe (opaque and rigid) 8) Delivery fitting 9) Pump casing 10) Manual bleeding valve 11) Suction coupling 12) Suction hose (soft and transparent) 13) Foot filter When forming the plumbing connections, follow these instructions: −...

  • Page 18: Electrical Connections

    ELECTRICAL CONNECTIONS The pump must be connected to a power supply that is as indicate don the label on the side of the pump. Failure to respect the limits indicated may result in the pump being damaged. The MAXIMA range of pumps do not need to be earthed as they are made using components and technology that ensures that all electronic components are double insulated.

  • Page 19: Setting And Operation

    SETTING AND OPERATION GENERAL DESCRIPTION Fig. 18: Display Fig. 19: Control Panel DISPLAY (icon lit) Icon Pump Functions Level The level sensor has detected that the liquid has fallen below the preset level. Flow Flow Alarm Enabled Pause Pump paused Stop Pump stopped Memory...
  • Page 20 Fig. 20: Connection Diagram POWER SUPPLY Phase Neutral ALARM REPETITION OUTPUT RELAY 3 Normally Open (NO) NO = PIN 3 + PIN 4 4 Common 5 Normally Closed (NC) NC = PIN 4 + PIN 5 PAUSE AND FLOW CONTROL 6 Pause PAUSE = PIN 6 + PIN 8 7 Flow Control...
  • Page 21 The Maxima MPG is designed to operate in various modes (C, n:1, 1:n, 1:c, 0/4…20, 20…/0/4). Passage from one to the other takes place after holding down the Prog key for three seconds, as shown in the layout shown, ▲ ▼...
  • Page 22 3.1.1 Displaying the flow rate The flow rate can be displayed in three formats: Percentage (P), Frequency (F), ml/min. To switch from one format to another hold the Mode key down for three seconds, to move from one to another as per the block diagram below.
  • Page 23 3.1.2 Factory settings A new pump from the factory is set as follows: Operating Mode Constant Flow Rate Display Percentage (100%) Working Frequency Maximum (240) Stroke Maximum Operation STOP Icons “lit” STOP C 3.1.3 Priming The priming function is useful for speeding up installation of the pump as it makes the pump work at maximum frequency, independently of the parameter settings.
  • Page 24 3.1.5 Checking the level of the liquid to be dosed A level sensor can be used to check the level of the liquid to be dosed. Two operating modes are available: 14) Level alarm with pump cut-out: Level sensor connected to pins n° 8 and 9 (see CONNECTION LAYOUT).

  • Page 25: Operating Mode

    OPERATING MODE This paragraph describes the various operating modes available on the Maxima MPG. For changing from one mode to another, see the instructions in Paragraph 3.1. 3.2.1 Constant Mode In this mode the pump provides constant, continuous dosing at the flow rate set. During operation, to select CONSTANT mode, push the Prog key and hold it down.
  • Page 26 Displaying and Operation When operating in CONSTANT mode the display shows the flow rate set. This can be displayed in three ways (P, F, ml/min) as explained in Paragraph 3.1.1. icon is lit. When displayed as a percentage the icon is also lit. The STOP icon must be off while the pump is running.
  • Page 27 − Selecting Impulses (See Fig. 24) The number n displayed represents the number of external impulses required for the pump to dose one stroke. This value can be changed between 1 and 9999 using the ▲ or ▼ keys. For Example: If I have connected my pump to a CB1 series plunger impulse counter (1 imp/l) and have selected N=8, this means that every 8 impulses on the counter my pump will give one stroke, that is, for every 8 litres of water that pass the counter the pump will dose one stroke.
  • Page 28 Displaying and Operation On exiting programming the 100% default value will be displayed icon lit). The number displayed shows the percentage flow for each stroke dosed by the pump, for every n external signals received. icons are on and the STOP icon must be off while the pump is running.
  • Page 29 3.2.3 1:n proportional mode (Multiplication mode) In this mode the pump doses n strokes for every external impulse received, where n is a number that can be set by the operator. To select 1:n MULTIPLICATION mode, push the Prog key and hold it down. appears on the screen for a few ▲...
  • Page 30 − Memory Function (see Fig. 25) The software continually monitors incoming external signals. When the frequency of the impulses is high and the pump is not able to dose all the corresponding strokes, the outstanding impulses can be recorded, up to a maximum of 65,535, so as to dose these strokes as soon as possible.
  • Page 31 3.2.4 1:c Manual Mode In this Mode the pump does a settable number of strokes, C, on receiving an input impulse. This impulse may ▲ come from the outside (plunger impulse counter) or by pressing the key on the keyboard. To select 1:c MANUAL mode, push the Prog key and hold it down.
  • Page 32 − Memory Function (see Fig. 26) The software continually monitors incoming external signals. When the frequency of the impulses is high and the pump is not able to dose all the corresponding strokes, the outstanding impulses can be recorded, up to a maximum of 65,535, so as to dose these strokes as soon as possible (for example - there is a reduction in the flow of water through the counter).
  • Page 33 3.2.5 Direct Current Proportional Mode (0/4…20) In this mode the pump doses a proportional amount based on a 0/4—20 mA input signal, connected to PIN 11 (- pole) and PIN 13 (+ pole). the current at which the pump will dose can be set to its minimum (0 imp/min) and a current value that corresponds to the pump dosing the maximum flow rate, equal to a flow rate established in the factory.
  • Page 34 − Selecting the Upper Limit (see Fig. 27) Once this mode and the lower limit (L) have been selected, when the Prog key is pressed the lower limit is stored in memory and the letter H is displayed, followed by the upper limit (expressed in mA) for the current signal (default 20.0) at which the pump runs at the maximum frequency set.
  • Page 35 3.2.6 Inverse Current Proportional Mode (20…4/0) In this mode the pump doses a inverse amount based on a 0/4—20 mA input signal, connected to PIN 11 ( pole) and PIN 13 ( pole). The current at which the pump will dose can be set to its minimum (0 imp/min) and a current value that corresponds to the pump dosing the maximum flow rate, equal to a flow rate established in the factory.
  • Page 36 − Selecting the Lower Limit (see Fig. 28) Once this mode and the lower limit (L) have been selected, when the Prog key is pressed the lower limit is stored in memory and the letter H is displayed, followed by the lower limit (expressed in mA) for the current signal (default 4.0) at which the pump runs at the maximum frequency set.

  • Page 37: Calibration Procedure

    CALIBRATION PROCEDURE The flow rates on your pumps can be calibrated in situ in order to take the specific characteristics of the installation into account, such as the actual operating pressure, the product to be dosed, the stroke setting, etc. The cc stored in memory during calibration are used for displaying the ml/min.
  • Page 38 − Manual Mode (Man) (see Fig. 29) Having selected “Man” mode push the Cal key. No strokes will be made and cc value for the previous calibration or the default setting will be displayed. ▲ ▼ Use the keys to set the quantity of product expressed in cc. Values for the various pump models can be found in Table 1.

  • Page 39: Maintenance

    4 MAINTENANCE This pump requires minimal maintenance only when products are dosed that tend to form crystals or when the pump is to be inactive for a period of time. WARNING: Before carrying out any maintenance on the pump, see to the following: −...

  • Page 40: Troubleshooting

    5 TROUBLESHOOTING DISPLAY PUMP CAUSE REMEDY STATUS Level icon + Alarm Led on Stopped The liquid has reached the Top up the jerry can of the product dosed. – STOP icon flashing preset level. Once the liquid level is corrected the Level icon and Alarm LED switch off and the pump starts working again...

  • Page 41: How To Contact Us

    6 HOW TO CONTACT US Web site: www.seko.com SEKO Asia pacific SEKO Brasil SEKO Deutschland SEKO France SEKO Iberica SEKO Southern Africa SEKO UK SEKO USA Maxima MPG Cod. EM00136006 rev. 1.1...
