RF-Lambda REMC13G16GD Manual

Wideband 200W EMC Solid State Power Amplifier
Note: Photo is for illustration purposes only.
Please refer to outline drawing.
Typical Applications
•
Wireless Infrastructure
•
Military and Aerospace Applications
•
Test Instrumentation
•
Radar Systems
•
5G Wireless Communications
•
Microwave Radio Systems
•
TR Modules
•
Research and Development
•
Cellular Base Stations
Electrical Specifications (T
Frequency Range
Small Signal Gain
Gain Variation Over Temperature (0⁰C to +50⁰C)
Input Return Loss
Saturated Output Power (Psat)
Supply Current (single phase 208VAC)
RF ON and OFF Speed.
(Gate/Drian control through d-sub connector)
Power Added Efficiency (PAE)
Time Division Duplexing (TDD) Blanking
(RF switch control through d-sub connector)
Input / Output Connectors
Rev 1. 03-13-2025 | Subject to change without notice
B5.0
=+25⁰C)
A
Parameter
Gain Variance
IM3
Weight
Impedance
Package
13-15.5GHz
Product Description
REMC13G16GD is a wideband EMC power amplifier with wide frequency
range of 13 to 15.5GHz.
Features
1. Small Signal Gain 68.5dB Typical
2. Digital Control Attenuator 0.5db step
3. Psat 53.5dBm Typical
4. Power supply: single phase VAC. Compatible for USA
and EU standard.
5. 50 Ohm Matched Input/Output
6. Protection Functions:
•
•
•
•
•
7. Amplifier Automatic Calibration Function
8. RF Output Power Display
9. RF Output Enable Function
10. High Maximum RF Input Power Handling, 20W max
11. Ethernet Remote Control
12. LCD Front Panel Display Screen
Min
ON
OFF
SMA-Female (Input) / WR62 (Output)
4U Rack-mount/Tabletop Chassis
sales@rflambda.com
Sales: sales@rflambda.com
REMC13G16GD
Over temperature
Over current
Current imbalance
RF input over drive protection
VSWR protection
Typ Max
13 - 15.5
68.5
+/-5
+/-3
-15
53.5
/
-40
10
20
100
100
60
50
RF-LAMBDA USA LLC:
support@rflambda.com
Technical: support@rflambda.com
Units
GHz
dB
dB
dB
dB
dBm
A
dBc
ms
%
ns
ns
lbs.
Ohms
