USER MANUAL
SMARTEC Lead Free Brass Electronic
Sensor Taps and Sensor Kits
•
STSLF1000(M, B, BM) - Lead Free
DZR Brass Hob Mounted Right Angle
Electronic Tap w/ Infrared Sensor
•
STSLF2500(M, B, BM) - Lead Free DZR
Brass Wall Mounted Electronic Tap w/
Infrared Sensor
•
STS3500(M, B, BM) - Zero Lead Stainless
Steel 304 Wall Mounted Electronic
Sensor Plate w/ No Spout Infrared Sensor
•
STS4500(M, B, BM) - Zero Lead Stainless
Steel 304 Wall Mounted Electronic
Sensor Plate w/ No Spout - Magnetized
Concealed Fixing Infrared Sensor
M: Mains Powered
B: Proprietary Battery Powered
BM: Battery & Mains Powered
MAR-IM-STSLF01-JT-20250203
The more
stars the more
water ef cient
WATER RATING
www.waterrating.gov.au
6.0
litres per
minute
In accordance with AS/NZS 6400
Licence No. 1334
GENTEC AUSTRALIA
gentecaustralia.com.au
Last updated in February 2025
AS 3718
Lic WMKA25617
SAI Global
Advertisement
Table of Contents
Related Manuals for Gentec SMARTEC STSLF1000
Summary of Contents for Gentec SMARTEC STSLF1000
- Page 1 BM: Battery & Mains Powered The more stars the more water ef cient WATER RATING www.waterrating.gov.au litres per minute AS 3718 In accordance with AS/NZS 6400 Lic WMKA25617 Licence No. 1334 SAI Global GENTEC AUSTRALIA gentecaustralia.com.au MAR-IM-STSLF01-JT-20250203 Last updated in February 2025...
-
Page 2: Table Of Contents
USER MANUAL Table of Contents Scope of Use Technical Information Product Images & Technical Drawings Exploded Drawings Installation Steps Remote Operation General Connection Cleaning & Maintenance Troubleshooting Water Quality Responsibly Sourced Scope of Use Installation of all products should adhere to the manufacturer's guidelines, as well as comply with PCA, AS/NZS3500 standards, and any other relevant regulatory provisions. -
Page 3: Technical Information
Technical Information Electronic Sensor Taps and Sensor Kits Body (STSLF1000 & STSLF2500) : Lead Free Brass Sensor Plate (STSLF3000 & STSLF4000) : Stainless Steel (SS304) Material Spout (STSLF3000 & STSLF4000): Lead Free Brass Solenoid Valve: Engineering Grade Plastic Cartridge Solenoid Valve Cartridge Size 15 mm STSLF1000, STSLF2500 : 15 mm Female Flexible... -
Page 4: Product Images & Technical Drawings
BM - Lead Free DZR Brass Wall Mounted Electronic Tap w/ Infrared Sensor Battery & Mains PRODUCT CODE AND DESCRIPTION Powered STSLF2500 - GENTEC SMARTEC Wall Mounted Electronic Tap W/ Infrared Sensor Lead Free DZR Brass Chrome Plated 6Star 6lpm 6,20-28 Ricketty St www.gentecaustralia.com.au... - Page 5 This drawing is property of PRODUCT RANGE LAST UPDATE APPROVED BY All dimensions are in mm B - Zero Lead Stainless Steel 304 Wall Mounted Electronic Sensor Plate w/ No Spout Gentec Australia Pty Ltd Steven unless specified. 02/03/20 Penson MAR-LD-STS01-MB-020320...
-
Page 6: Exploded Drawings
USER MANUAL Exploded Drawings Installation Steps BEFORE SETUP, MAKE SURE: • Installation must be done by a qualified and licenced plumber and adhere to AS/NZS3500 and manufacturer's recommendations. • Lines must be flushed before installation and the strainer provided must be installed to prevent debris damaging the cartridges. - Page 7 STSLF1000 (M, B, BM) INSTALLATION STEPS Step 1. Flush the new pipe prior to Step 5. From underneath the sink or installation. basin, fix rubber seal, fixing plate and fixing nut with a spanner. Step 2. Remove rubber seal, fixing plate Make sure the screws are well and fixing nut.
- Page 8 USER MANUAL STSLF2500 (M, B, BM) INSTALLATION STEPS Step 1. Mark the centre line for the main Step 6. Replace the 1/2" BSP Nut to flexi hole, from the centre line go up hose. 19mm and drill a 5mm hole. Then, drill a 28 - 30mm hole from the Step 7.
- Page 9 STS3500 (M, B, BM) INSTALLATION STEPS Step 3. Install the sensor plate (2) by tightening the screws provided (3) equally. The screws have up to 7mm adjustment. Wall Bracket Installation Step 1. Allow a straight line cut 96mm (width)x 50mm (height) in the wall 70mm to 110mm deep.
- Page 10 USER MANUAL STS4500 (M, B, BM) INSTALLATION STEPS Before Installation Description Qty. Before connecting water to the valve, ensure to flush the line and remove all Solenoid Box debris. Backing Plate All fixtures must be installed using slim compression fittings. Sensor Plate Working pressure must be between 150 and 450kPa.
- Page 11 Step 4. Connect all plumbing before mounting the solenoid box to the wall using the screws provided. Step 5. Use the screws provided to mount the backing plate (2) onto the solenoid box (1). Front of Wall Installation Step 6. Install the sensor plate (3) by tightening the screws provided Important Information...
-
Page 12: Remote Operation
USER MANUAL Remote Operation Remote Operation BEFORE SET UP MAKE SURE: BEFORE SETUP, MAKE SURE: • To use good quality AAA batteries. • Every time you press a button on Fit the batteries into the remote and the Remote controller, the indicator replace the cover. - Page 13 Remote Operation GREY REMOTE GREY REMOTE NOTE: For each of the following, “ • ” represents a light signal of short duration, while “ – ” represents a light signal of noticeably longer duration. A long space “ ” represents a pause.
- Page 14 USER MANUAL Remote Operation BLACK REMOTE BLACK REMOTE Button 1: Activates sensor in Automatic mode. Can switch from Wave mode. Sensor will flash based on the run timing and Hygiene Flush. Button 2: Activates sensor in Wave mode. Can switch from Automatic mode. Sensor will flash based on the run timing and Hygiene Flush.
-
Page 15: Automatic On/Off
Remote Operation AUTOMATIC ON/OFF Figure 1 Figure 1 AUTOMATIC ON/OFF When hands are in the sensor’s range, program turns ON. Removing hands from the sensor’s range will switch the sensor OFF. See Figure 1 Default is for Sensor to switch OFF after 2 seconds RUN;... -
Page 16: General Connection
USER MANUAL General Connection FOR STSLF1000 (M, B, BM), STSLF2500 (M, B, BM) Screw the solenoid box to the wall by using the screws provided. Ensure there is sufficient space between the wall and the taps mounting point for easier installation. BM: Battery and Mains Operated B: Battery Operated M: Mains Operated... - Page 17 Please refer fo the diagram on page 16. When using the unit for first time • Make sure to turn on the power first Step 1. Connect the tap flexible hose and then the water. to the solenoid box outlet. Make sure the connections are firm and •...
-
Page 18: Cleaning & Maintenance
USER MANUAL Cleaning & Maintenance To minimise downtime and maximise the functional life of the product, GENTEC recommends servicing your product at least every 12 months, under heavy use may need to be checked and serviced more often. • The product must be handled carefully to avoid causing any physical damage. -
Page 19: Troubleshooting
Troubleshooting Problem Cause How to Fix • Is the power connected • Did you turn the power on then the water, if you didn’t do that, then start the process again, turn the power and water off • Have you flushed the water line for a minimum of 1 minute before connecting the water •... -
Page 20: Water Quality
USER MANUAL Problem Cause How to Fix • Check for blockage • Is the isolating valve fully open • Have got these in a bank, if so, is the inlet • Not enough pipes been sized correctly water Issue with water •... -
Page 21: Responsibly Sourced
GENTEC is rejuvenating the product- no power, less maintenance and longer life. Rejuvenation Program To learn more about the rejuvenation program, please contact our customer service at info@gentecaustralia.com.au for more information. Ethically and Environmentally Sourced Please refer to GENTEC Business Ethics & Ethical Sourcing Policy at https:// gentecaustralia.com.au/terms-and-conditions/ gentecaustralia.com.au... - Page 22 Note: The information provided is only a guide, actual product may differ. The information here should not be relied on without clarification with Gentec. Gentec reserves the right to make design changes at any time without notification.
