Summary of Contents for Hach US900 Series
Page 1
US9001 ULTRASONIC SENSOR QUICK START GUIDE...
Page 2
AS950 and US900X Quickstart Guide Step 1 – Configure Sensor Port Assignment and Logging From the Main Menu, choose “Programming”...
Page 3
Choose Datalog Programming...
Page 4
Choose “Change Port Assignments”...
Page 5
Select the sensor Port the sensor is connected to...
Page 6
Choose Sensor type (US900X)
Page 7
Return to the Datalog Programming menu and choose “Channels Logging”...
Page 8
Select “Sensor 1 (US900X)
Page 9
Choose preferred channels (choose Level and Flow at a minimum) and click save...
Page 10
Choose Logging Intervals...
Page 11
Select each option and choose preferred measurement and logging interval.
Page 12
Step 2 – Configure Preferred Units From the Main Menu choose “General Settings”...
Page 13
Choose “Unit Preferences”...
Page 14
Configure “Preferred Units” Under “Select Units”...
Page 15
Step 3 – Configure Sensor Port From the Main Menu, choose “Hardware Setup”...
Page 16
Select “Configure Sensors”...
Page 17
Choose “Setup Port 1 (US900X)”...
Page 18
Select Setup Wizard...
Page 19
Choose “Downlooking” and press “Enter”...
Page 20
Choose your Primary Device type (Flume, Weir, etc)
Page 21
Select the device type (for a complete list of options refer to the AS950 Controller user manual)
Page 22
Enter the required Channel dimensions requested...
Page 23
Enter the Depth of Water at the specific monitoring point. If using a Flume/Weir, only enter the depth of water down to the 0 flow point.
Page 24
The sensor will take a reading and give a Summary if the calibration is successful. Choose Finish...
Page 25
If you want a verification measurement, choose Yes, if not No...
Page 26
Verification Page...
Page 27
Step 4- Configure Flow Pacing From the Main Menu choose “Programming”...
Page 28
Choose Sample Programming...
Page 29
Configure Total Bottles, Bottle Volume and Tubing as required, then select “Pacing”...
Page 30
Choose “Flow Weighted”...
Page 31
Choose “Flow Source” then Select Flow 1 or 2 depending on sensor location...
Page 32
From the Pacing Menu, choose “Target” and select how many gallons need to pass for the AS950 to pull a sample.
