紙箱線條圖(無緩衝座)
TRX1400
TREADMILL
Online Support
If you require assistance or are
experiencing issues with your
XTERRA Machine, please contact
customer care for additional help.
1-800-258-8511
questions@xterrafitness.com
Warranty Registration
Scan to quickly and easily
register your new XTERRA
Fitness machine.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TRX1400 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Xterra TRX1400

  • Page 1 紙箱線條圖(無緩衝座) Online Support If you require assistance or are experiencing issues with your XTERRA Machine, please contact customer care for additional help. 1-800-258-8511 questions@xterrafitness.com Warranty Registration Scan to quickly and easily register your new XTERRA Fitness machine. TRX1400 TREADMILL...
  • Page 3: Table Of Contents

    Warranty ................35 Setting Up Your Unit ............14 Troubleshooting ............... 38 Safety Key ................16 Technology and Features About Your Machine ............17 Console Screen - Overview ..........18 Features ................19 Using the XTERRA+ App ..........20 Programs Programs Intro ..............21...
  • Page 4: Product Registration

    Congratulations on your new treadmill, and welcome to the XTERRA WARRANTY REGISTRATION Fitness family! Thank you for your purchase of this quality unit from XTERRA Fitness. Your new unit was manufactured by one of the leading fitness manufacturers in the world and is backed by one of the most comprehensive warranties available.
  • Page 5: Product Labels

    PRODUCT LABELS SERIAL NUMBER STICKER SERIAL NUMBER This sticker will be found on the rear of the motor cover. Please record the number below the barcode for the purpose of registering your treadmill’s warranty. X XXXXXXXXX X (870) 336-4286 PROPOSITION 65 WARNING This sticker will be found on the rear of the motor cover.
  • Page 6: Safety Instructions

    SAFETY INSTRUCTIONS When using an electrical appliance, basic precautions should always be 10. Do not use outdoors. followed, including the following: 11. Do not operate where aerosol (spray) products are being use or Read all instructions before using this appliance. where oxygen is being administered.
  • Page 7: Electrical Safety

    ELECTRICAL SAFETY WARNING! Route the power cord away from any moving part of the unit Optimally the unit should be the only device plugged into the including the elevation mechanism and transport wheels. circuit. Our units have surge suppressors built in to help avoid nuisance tripping.
  • Page 8: Grounding & Location Requirements

    GROUNDING & LOCATION REQUIREMENTS This product must be grounded. If the unit should malfunction or Location Requirements breakdown, grounding provides a path of least resistance for electric current, reducing the risk of electric shock. This product is equipped with a After assembling your treadmill, you’ll need to make sure you’ve cord having an equipment-grounding plug.
  • Page 9: Parts Included

    PARTS INCLUDED TOOLS INCLUDED: ‰ Combination M5 Allen Wrench & Phillips Head Screwdriver PARTS INCLUDED: 5/16" × UNC18 × 1/2" #94. ‰ 1 Main Frame Ø8 × Ø23 × 1.5T Ø8 × Ø18 × 1.5m/m #95. #79. Curved Washer Button Head Socket Bolt (10pcs (6pcs) Flat Washer(4pcs) ‰...
  • Page 10: Pre-Assembly

    PRE-ASSEMBLY WARNING: There is a Velcro strap installed around the treadmill base that prevents the unit from unfolding accidentally during shipping. If this strap is not removed properly the treadmill could spring open unexpectedly and cause injury if someone is standing near the unit when the strap is removed.
  • Page 11: Assembly

    ■ ASSEMBLY Take out the treadmill from the carton and lay it aside on the smooth ground. Connect the Computer Cable (Middle) (47) with the Computer Cable (Lower)(45). ■...
  • Page 12 ASSEMBLY - CONTINUED Insert the Uprights (L, R)(3,4) into the Frame Base (2) with the 6pcs of 5/16” × 1/2” Button Head Socket Bolts (94),4pcs of Ø5/16” × Ø18 × 1.5T Flat Washers (79) and 2pcs of Ø8 × Ø23 × 1.5T Curved Washers (95)by using the Combination M5 Allen Wrench &...
  • Page 13 ASSEMBLY - CONTINUED Connect the Computer Cable (Upper) (46) with the Computer Cable (Middle)(47).
  • Page 14 ASSEMBLY - CONTINUED Install the Console Support (5) into the Uprights (L,R)(3,4) with the 4pcs of 5/16” × 1/2” Button Head Socket Bolts (94) and 4pcs of Ø8 × Ø23 × 1.5T Curved Washers (95) by using the Combination M5 Allen Wrench & Phillips Head Screw Driver (104).
  • Page 15: Setting Up Your Unit

    SETTING UP YOUR TREAD Plugging in and Powering On Leveling Power the unit on by plugging it into an appropriate wall Use a M14 Wrench to adjust the height of the Leveling Feet. outlet, then turn on the power switch located at the front of the treadmill below the motor hood, Ensure that the Safety Key is installed, as the treadmill will not power on without it.
  • Page 16: Moving The Treadmill

    SETTING UP YOUR TREAD - CONTINUED Folding Your Treadmill Moving The Treadmill Step: Pull up the deck until it is locked at a fixed position. The treadmill is equipped with four transport wheels that are Lift the deck until the latch engaged when folded.
  • Page 17: Safety Key

    SAFETY KEY A safety tether cord is provided with this unit. It is a simple magnetic design that should be used at all times. It is for your safety should you fall or move too far back on the tread-belt. Pulling this safety tether cord will stop tread-belt movement.
  • Page 18: About Your Machine

    Downloading the XTERRA+ app will help unlock more fea- tures - such as tracking workouts and sharing data via Goo- gle Fit and Apple Fitness. Simply search for “XTERRA+” in Be sure to follow XTERRA Fitness on your favorite social...
  • Page 19: Console Screen - Overview

    CONSOLE SCREEN - OVERVIEW LCD Window Safety Direct Incline Direct Speed Accessory Buttons Buttons Holder Program Button...
  • Page 20: Features

    FEATURES Program Speed Down Program Mode selection: In ready mode, scroll to select During operation, press the speed decrease button to (P01---P24- -HRC—P01) in sequence. decrease the speed in increments of 0.1 MPH. Press and hold for continuous decrease in speed. Enter Direct Speed In manual mode, scroll to select count down time, count...
  • Page 21: Using The Xterra+ App

    2. Open the App on your device (phone or tablet) and make sure Bluetooth® is enabled on your device (phone or tablet). 3. In the App click the Bluetooth® icon to search for your XTERRA + equipment. 4. Under the Bluetooth® scan result list, select the machine for connect. When the App and equipment are synced, the Bluetooth®...
  • Page 22: Programs

    PROGRAMS - TO SELECT AND START A PROGRAM Press PROGRAM after turning power on and enter program mode with the window displaying P01. There are 24 built-in programs. Press PROGRAM to select one program through P01-P24 and enter time setting with the preset time 30 minutes. Press SPEED Up/Down , INCLINE Up / Down to change the value of time within the range 5-99 minutes.
  • Page 23 USER DEFINED MODE OPERATION 1. Selecting the count-down training mode: In ready mode, press ENTER to enter count-down time mode. Press ENTER again to enter count-down distance mode and press ENTER the third time to enter count-down calorie mode. 2. Count-down time training mode: In ready mode, press ENTER to enter setting mode.
  • Page 24 PROGRAMS HRC Mode Operation 1. Press PROGRAM to select H-1 and press ENTER to enter HRC mode. 2. Enter the time setting, use the Speed Up / Down key to adjust, and press ENTER. 3. Enter the heart rate setting, use the Speed Up / Down key to adjust, and press the START button to start.
  • Page 25: Heart Rate Exertion

    HEART RATE EXERTION The old motto, “no pain, no gain”, is a myth that has been The two most popular reasons for, or goals, of exercise are cardiovascular overpowered by the benefits of exercising comfortably. A great deal fitness (training for the heart and lungs) and weight control. The black of this success has been promoted by the use of heart rate monitors.
  • Page 26 HEART RATE - PERCEIVED EXERTION Heart rate is important but listening to your body also has a lot You can get an approximate heart rate level for each rating by of advantages. There are more variables involved in how hard simply adding a zero to each rating.
  • Page 27: General Cleaning

    MAINTENANCE & CARE Post-Workout Machine Care Sanitizing Your XTERRA Fitness Equipment 1. Store your machine according to the folding instructions • Unupholstered high-contact surfaces (hard plastics) can be sanitized using a 75% isopropyl alcohol solution and a clean, dry when not in use.
  • Page 28: Treadbelt Tracking Adjustment

    MAINTENANCE & CARE - CONTINUED Treadbelt Tracking Adjustment Damage to the running belt resulting from improper The treadmill is designed so that the tread-belt remains tracking / tension adjustments is not covered under reasonably centered while in use. It is normal for some belts the Spirit Fitness warranty.
  • Page 29: Belt Adjustments

    MAINTENANCE & CARE - CONTINUED Belt Adjustments Tread-belt Tension Adjustment - Belt tension is not critical for most users. It is very important though for joggers and runners DO NOT OVERTIGHTEN – Over tightening will cause belt in order to provide a smooth, steady running surface. damage and premature bearing failure.
  • Page 30: Deck Lubrication

    1. Ensure that your machine is off, and that the power cord is before first use. unplugged to minimize risk of injury. Do not lubricate with anything other than XTERRA Fitness 2. Reach between the running belt and the top of the treadmill approved lubricant. Your treadmill comes with one tube of base to verify that lubrication is present.
  • Page 31: Belt & Deck Cleaning

    BELT AND DECK CLEANING Belt & Deck Cleaning To clean your treadmill belt: 1. Ensure that your machine is off, and that the power cord is unplugged to minimize risk of injury. 2. Grab one edge of the treadmill belt, and lift slightly to expose the area between the top of the treadmill base and the running belt.
  • Page 32: Engineering Mode

    ENGINEERING MODE MENU After removing the safety key, press PROGRAM and put on the safety key again to enter the engineering mode. The sequence of the setting is: 1. Wheel size (Default: 42) 2. Unit of speed (Default: metric 0, English 1) 3.
  • Page 33: Exploded View Diagram

    EXPLODED VIEW DIAGRAM T3-NT053-01 SPIRIT 美國 20-1 20-10 20-2 20-8 20-9 20-9 20-11 20-13 20-9 20-9 20-3 20-9 20-4 20-12 20-5 20-20 20-7 79 90 1120424AM0932...
  • Page 34: Parts List

    PARTS LIST Main Frame Motor Top Cover Frame Base Rear Adjustment Base (L) Left Upright Rear Adjustment Base (R) Right Upright Frame Base Cover (L) Console Support Frame Base Cover (R) Incline Bracket 15 × 30mm_Square End Cap Belt Guide Adjustment Foot Pad Motor Bracket Rubber Foot Pad...
  • Page 35 PARTS LIST 1200m/m_Speed/Hand Pulse Complex 4 × 12m/m_Sheet Metal Screw 1200m/m_Incline/Hand Pulse Complex Ø5 × 16m/m_Tapping Screw Console Bracket Anchor Ø5 × 1.5T_Split Washer 3.5 × 20m/m_Sheet Metal Screw M5_Star Washer Frame Cover 3 × 25m/m_Sheet Metal Screw 3/8" × 1-1/4"_Hex Head Bolt M8 ×...
  • Page 36: Warranty

    Effective March 08, 2023- TRX1400 Treadmill LIMITED WARRANTY XTERRA Fitness Inc. warrants all its home use treadmill parts for a period of time listed below, from the date of retail sale, as deter- mined by a sales receipt or in the absence of a sales receipt, eighteen (18) months from the original factory shipping date. XTERRA Fitness’s responsibilities include providing new or remanufactured parts, at XTERRA Fitness’s option, and technical support to our in-...
  • Page 37 9. Warranties outside of the United States may vary. Please contact your local dealer for details. Product features or specifications as described or illustrated are subject to change without notice. All warranties are made by XTERRA Fitness, Inc. This warranty...
  • Page 38 4. XTERRA Fitness’ obligation under this warranty is limited to repairing or replacing, at XTERRA Fitness’ option, the product through one of our authorized service centers. All repairs must be preauthorized by XTERRA Fitness. If the product is shipped to a service center freight charges to and from the service center will be the customer’s responsibility.
  • Page 39: Troubleshooting

    TROUBLESHOOTING Error Code Guide ERROR NUMBER Solution/ Cause Safety switch is open. Put on the safety key to eliminate the error. Speed signal is not received during calibration. Treadmill stops automatically after 10 seconds. E2 Overload error. Controller detected over rated current for 6 seconds. Abnormal motor voltage or motor disconnected.
  • Page 40: Service Checklist - Diagnosis Guide

    TROUBLESHOOTING - CONTINUED Service Checklist Diagnosis Guide Problem Solution/ Cause Display does not light 1. Tether cord not in position. 2. Circuit breaker on front grill tripped. Push circuit breaker in until it locks. 3. Plug is disconnected. Make sure plug is firmly pushed into AC wall outlet. 4.
  • Page 44 3000 Nestle Road Jonesboro, AR 72401 | Phone: 800-258-8511 | Fax: 870-935-7611 www.xterrafitness.com ©2023 All Rights Reserved. TRX1400 Owner’s Manual...
