PROBLEM
Computer does not come on
nothing shows in either display
Computer heat light comes on
but elements do not heat
Computer display shows
"OFF" and cannot be turned
"ON".
RED return valve is open no
pump sound can be heard
Drain valve is closed and
the computer has been
reset but still shows
"DRAINING" or
"TURN OFF"
Drain valve is open, the oil is
draining slowly or not at all.
L20-246 Rev 1 (11/09)

TROUBLESHOOTING

PROBABLE CAUSE
A. Main circuit breaker is
turned off
B. Fryer fuse is blown
A. If the oil is hot the
Hi - Limit may be tripped
A. Bad computer
A. RED return valve not fully
open
B. Filter circuit breaker may be
tripped
C. Filter motor Thermal Over-
load may be tripped
D. Sensor switch may be loose
A. GREEN drain valve is not
fully closed
B. Sensor switch may be loose
A. GREEN drain valve is not
fully open
B. Drain is plugged with debris
CORRECTIVE ACTION
A. Locate the correct building circuit breaker
and turn OFF and back ON again.
B. Call an Authorized Service Technician
A. Allow the oil to cool, reset the Hi Limit and
turn the computer OFF and back ON
again.
A. Locate the correct building circuit breaker and
turn OFF and back ON again. If this does not
reset the computer call an Authorized Service
Technician.
A. Pull slightly on the RED return valve handle
B. Locate the filter circuit breaker behind the door
of the left hand fryer and reset it.
C. Push RED reset button located on end of filter
motor, behind the door of left hand fryer.
D. If the mounting screws are loose try to tighten
them, if this is not possible call an Authorized
Service Agency.
A. Apply a little more pressure to close the valve
B. If the mounting screws are loose try to tighten
them, if this is not possible call an Authorized
Service Agency.
A. Apply a little more pressure to open the valve
B. Use the clean out rod to clear the drain valve
from inside the fry vat. If this does not clear the
blockage, CLOSE the GREEN drain valve and
follow the instructions for clearing the main
drain line.
Some HOT oil may come out when the cap is
removed.
Remove the two wing nuts from the end cap
(do NOT lose these.) Use the clean out rod to
clear the main drain tube. Install the end cap
along with its gasket and four screws. Do not
overtighten these screws or remove drain "T"
cleanout access covers, by removing thumb
screws (do not loose screws). Then clean drain,
replace access cover and thumb screws.
9
CAUTION:
