Model No. PETL50707.0
Serial No.
Write the serial number in the space
above for future reference.
Serial Number
Decal
QUESTIONS?
As a manufacturer, we are commit-
ted to providing complete customer
satisfaction. If you have questions,
or if there are missing parts, please
contact us at the numbers or ad-
dresses listed below:
Call: 08457 089 009
Outside UK: 0 (44) 113 3877133
Fax: 0 (44) 113 3877125
E-mail: csuk@iconeurope.com
Write:
ICON Health & Fitness, Ltd.
Unit 4
Revie Road Industrial Estate
Revie Road, Beeston
Leeds, LS11 8JG
UK
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRO-FORM STYLE 4500 and is the answer not in the manual?

Questions and answers

Summary of Contents for ICON PRO-FORM STYLE 4500

  • Page 1 Call: 08457 089 009 Outside UK: 0 (44) 113 3877133 Fax: 0 (44) 113 3877125 E-mail: csuk@iconeurope.com Write: ICON Health & Fitness, Ltd. Unit 4 Revie Road Industrial Estate Revie Road, Beeston Leeds, LS11 8JG CAUTION Read all precautions and instruc- tions in this manual before using this equipment.
  • Page 2: Table Of Contents

    Apply the decal in the location shown. Note: The decals may not be shown at actual size. PROFORM is a registered trademark of ICON IP, Inc.
  • Page 3: Important Precautions

    To reduce the risk of serious injury, read all important precautions and in- structions in this manual and all warnings on your treadmill before using your treadmill. ICON as- sumes no responsibility for personal injury or property damage sustained by or through the use of this product.
  • Page 4 20. Do not attempt to raise, lower, or move the DANGER: Always unplug the power treadmill until it is properly assembled. (See cord immediately after use, before cleaning ASSEMBLY on page 6, and HOW TO FOLD the treadmill, and before performing the AND MOVE THE TREADMILL on page 17.) maintenance and adjustment procedures de- You must be able to safely lift 45 lbs.
  • Page 5: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the PROFORM ® STYLE 4500 ing this manual, please see the front cover of this man- treadmill. The STYLE 4500 treadmill combines ad- ual. To help us assist you, note the product model vanced technology with innovative design to let you number and serial number before contacting us.
  • Page 6: Assembly

    2 1/2” Bolt (56)–4 ASSEMBLY Washer (29)–4 Star Washer (81)–4 2 3/4” Bolt (47)–4 Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials; do not Handrail Washer (11)– dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant.
  • Page 7 2. Have a second person hold the Base (52) in the position shown. Identify the Left Upright (53) (the Right Upright [54] has a large hole near the lower end). Hold the Left Upright (53) so the two small holes for the latch assembly are on top as shown.
  • Page 8 5. See the left inset drawing. Identify the two Frame Spacers (11). Open the included packet of grease, and apply grease to both sides of both Frame Spacers. Then, identify the outer side of each Frame Spacer. Hold a Frame Spacer (11) between the Right Upright (54) and the Lift Frame (23), with the outer side of the Frame Spacer facing the Right Upright.
  • Page 9 7. Set the Console (91) face-down on a soft sur- face to avoid scratching the Console. Hold the Console Right Handrail (33), which has a large hole in Wire the location shown, near the Console. Bracket Next, insert the console wire and tie into the hole in the side of the Right Handrail (33).
  • Page 10 10. Have a second person raise and hold the tread- mill Frame (51). Cylinder Identify the Gas Spring (98). Note that the Gas Spring has a cylinder end and a rod end. See the two small inset drawings. Locate the Spring Clip (96) in the rod end of the Gas Spring.
  • Page 11 12. Attach the ground wire on the Wire Harness (39) to the indicated hole in the Base (52) with a 1/2" Ground Screw (84). Ground Wire Hole 13. See the lower drawing. Position the Uprights (53, 54) so that the treadmill Frame (51) is cen- tered between the Uprights.
  • Page 12: Operation And Adjustment

    OPERATION AND ADJUSTMENT THE PRE-LUBRICATED WALKING BELT Your treadmill features a walking belt coated with high-performance lubricant. IMPORTANT: Never apply sili- cone spray or other substances to the walking belt or the walking platform. Such substances will deterio- rate the walking belt and cause excessive wear. HOW TO PLUG IN THE POWER CORD This product must be earthed.
  • Page 13: Console Diagram

    CONSOLE DIAGRAM Clip Note: If there are thin sheets of plastic on the console, remove the plastic. FEATURES OF THE CONSOLE HOW TO TURN ON THE POWER IMPORTANT: If the treadmill has been exposed to The treadmill console offers a selection of features cold temperatures, allow it to warm to room tem- designed to make your workouts more effective.
  • Page 14: How To Use The Manual Mode

    HOW TO USE THE MANUAL MODE 4. Change the incline of the treadmill as desired. 1. Insert the key into the console. To change the incline of the treadmill, hold down the Incline increase or decrease button until the See HOW TO TURN ON THE POWER on page desired incline level is reached.
  • Page 15 To reset the displays, press the Stop button, re- To measure your heart rate, stand on the foot move the key, and then reinsert the key. rails and hold the metal contacts—avoid moving your hands. When your pulse is detected, the small Note: The console can heart symbol in the lower right display will flash, display speed and dis-...
  • Page 16 HOW TO USE A SPEED WORKOUT in one of the displays to alert you, and then the speed of the walking belt will change. The work- 1. Insert the key into the console. out will continue until all the segments are com- pleted.
  • Page 17: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, adjust the incline to the lowest position. If you do not do this, you may damage the treadmill when you fold it. Next, unplug the power cord.
  • Page 18 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand as shown. Using your left hand, pull the latch knob to the left and hold it. Next, lower the frame until it is past the latch pin.
  • Page 19: Troubleshooting

    TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please see the front cover of this manual. PROBLEM: The power does not turn on SOLUTION: a.
  • Page 20 PROBLEM: The walking belt slows when walked on SOLUTION: a. If an extension cord is needed, use only a 3-conductor, 1mm (14-gauge) cord that is no longer than 5 ft. (1.5 m). b. If the walking belt is overtightened, treadmill perfor- mance may decrease and the walking belt may be- 2–3 in.
  • Page 21: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning any time. During the first few minutes of exercise, your exercise program, consult your physician. body uses carbohydrate calories for energy. Only after This is especially important for persons over the first few minutes of exercise does your body begin the age of 35 or persons with pre-existing...
  • Page 22: Part List

    PART LIST—Model No. PETL50707.0 R0807A To locate the parts listed below, see the EXPLODED DRAWING near the end of the manual. Key No. Qty. Description Key No. Qty. Description M10 x 60mm Patch Bolt Hood Clip M10 x 58mm Bolt Latch Housing M4.2 x 13mm Tek Screw Grommet...
  • Page 23 Key No. Qty. Description Key No. Qty. Description Belt Guide M4 Washer 5mm Hex Key M4 Star Washer Frame Endcap Ground Wire w/Decal Gas Spring Clip Kit Plug Adapter Rear Foot, Right Outlet Plate Gas Spring Incline Motor Spacer Receptical –...
  • Page 24: Exploded Drawing

    EXPLODED DRAWING A—Model No. PETL50707.0 R0807A...
  • Page 25 EXPLODED DRAWING B—Model No. PETL50707.0 R0807A 42 21...
  • Page 26 EXPLODED DRAWING C—Model No. PETL50707.0 R0807A 43 43...
  • Page 27 EXPLODED DRAWING D—Model No. PETL50707.0 R0807A...
  • Page 28: Ordering Replacement Parts

    European standards of environmental protection. If you require more information about safe and correct disposal methods, please contact your local city office or the establishment where you purchased this product. Part No. 257860 R0807A Printed in China © 2007 ICON IP, Inc.
