Tosibox 610 Quick Start Manual

Matching your TOSIBOX
1
with the Key
1. Connect the operating voltage of 9-50 V DC to the endpoint device and wait for 1 minute.
2. Insert the Key into the USB port of the endpoint device. When the LED on the Key
turns off, (after approx.10 seconds) the matching is complete, and you can remove
the Key from the USB port.
3a
3. Go to
setting up wireless connection. If deploying endpoint device as DHCP client into
existing networks, please see the Tosibox user manual.
Set Up Router
2
1. Connect ethernet cable into LAN port of Tosibox Endpoint device and the other end of the
cable into LAN port of your computer.
2. Visit LAN IP address in your browser to set up your device. The LAN IP address can be
found from the bottom of the end-point device.
3. Log in using "admin" account. The password can be found from the bottom of the device.
4. Tosibox Endpoint device needs an Internet connection to function. Go to
into broadband networks (ethernet) or
Update the device software immediately when you are connected to the Internet.
!
Go to Settings > Software update. If there is a software update available for the device, start the
update by clicking Start software update.
Connect to the Internet using
3a
Ethernet connection
1. Connect your Tosibox Endpoint device from the WAN port to the Internet with a fixed
Ethernet cable.
2. When the WAN ETH LED is lit on the front plate of the Endpoint device, the Internet
connection is working. If the light is not lit, investigate possible connectivity issues.
Set up wireless connection
3b
Connect the device to the Internet using internal
Modem (675 and 695)
You can connect the device to the Internet
with an internal Modem. Before inserting or
removing the SIM card, disconnect the device
power supply.
1. Install the antenna
2. Insert a SIM card
3. Select Network > Internal Modem and
fill in the APN according to your mobile
operator settings. Enter PIN code if
necessary. Click Save.
Position the antennas in orthogonal pattern, i.e. in such a way that they form
!
90 degrees angle between each other.
610, 675, 695
Quick Start Guide
Copyright © Tosibox Oy, 2025
if you are connecting to the Internet using Ethernet connection or
Endpoint device
®
if deploying into wireless connection.
3b
Connect the device to the Internet using
wireless LAN (675 and 695)
1. Attach WLAN antenna to the device.
2. Open the service connection to the device
and log in with your credentials.
3. Configure wireless LAN settings at
"Network > WLAN".
4. When the WAN WIFI LED is lit on the front
plate of the Device, the WLAN connection
is working.
3b
if
3a
if deploying
