1
Matching your TOSIBOX
1.
Connect the operating voltage of 9-50 V DC to the Node and wait for 1 minute.
2.
Insert the Key into the USB port of the Node. When the LED on the Key turns off, (after approx.
10 seconds) the matching is complete, and you can remove the Key from the USB port.
3.
Go to
3a
wireless connection. If deploying Nodes as DHCP client into existing networks, please see the
TOSIBOX
®

Set Up Router

2
1.
Connect ethernet cable into LAN port of TOSIBOX® Node and
the other end of the cable into LAN port of your computer.
2.
Visit 10.10.10.254 in your browser to set up your device.
3.
Log in using "admin" account. The password can be found from the bottom of the Node.
4.
TOSIBOX® Node needs an Internet connection to function. Go to
networks (ethernet) or
Update the device software immediately when you are connected to the Internet.
!
Go to Settings > Software update. If there is a software update available for the device, start the update by
clicking Start software update.
3a

Connect to the Internet using Ethernet connection

1.
Connect your TOSIBOX® Node from the WAN port to the Internet with a fixed Ethernet cable.
2.
When the WAN ETH LED is lit on the front plate of the Node, the Internet connection is working. If the
light is not lit, investigate possible connectivity issues.
3b

Set up wireless connection

Connect the device to the Internet using internal
LTE Modem (670 and 675)
You can connect the device to the Internet with an
internal Modem. Before inserting or removing the SIM
card, disconnect the device power supply.
1.
Install the antenna
2.
Insert a SIM card
3.
Select Network > Internal Modem and fill in
the APN according to your mobile operator
settings. Enter PIN code if necessary.
Click Save.
Position the antennas in orthogonal pattern, i.e. in such a way that they form
!
90 degrees angle between each other.
610, 650, 670, 675
Quick Start Guide
Copyright © Tosibox Oy, 2021
if you are connecting to the Internet using Ethernet connection or
user manual.
if deploying into wireless connection.
3b
Node with the Key
®
3a
if deploying into broadband
Connect the device to the Internet using wireless LAN
(650 and 675)
1.
Attach WLAN antenna to the device.
2.
Open the service connection to the device and
log in with your credentials.
3.
Configure wireless LAN settings at "Network
> WLAN".
4.
When the WAN WIFI LED is lit on the front plate
of the Device, the WLAN connection is working.
3b
if setting up
