- Page 1 ASSEMBLY INSTRUCTIONS Tagfahrlicht TECHART daytime running lights Part no. 070.180.182.009CHR TECHART "chrome" multifunctional daytime running lights Part no. 070.180.182.009BLK TECHART "black" multifunctional daytime running lights Version 03 – 02/2019 Assembly Instructions 070.180.182.099...
-
Page 2: Table Of Contents
Prepare vehicle ..........................6 Switching off level control system ..................6 Detach original front panel .....................7 Assembly of TECHART multifunctional daytime running lights ............9 Assembly of TECHART combination lamp ..............9 Install TECHART control unit ..................12 Install TECHART wiring harness ................13 Fit original front apron .................... -
Page 3: Important Safety Information
Do not eat, drink or smoke when handling windshield cleaning agents/antifreeze. Do not breathe in vapors and ensure adequate ventilation. Keep windshield cleaning agents/antifreeze only store them in sealable original containers. TECHART Version 03 dated February 19, 2019 Page 3 of 17... -
Page 4: Preparation
Preparation People required A minimum of two people are required for installation of this product. Help and support If you have any technical queries, please contact us immediately: support@techart.de TECHART Version 03 dated February 19, 2019 Page 4 of 17... - Page 5 ASSEMBLY INSTRUCTIONS TECHART Multifunctional daytime running lights Check TECHART multifunctional daytime running lights parts kit 070.180.182.009___ TECHART multifunctional daytime running lights Consisting of: 000.180.120.100 Combination lamp with daytime DRL right, chrome 000.180.120.101 Combination lamp with DRL left, chrome 000.180.121.100 Combination lamp with daytime DRL right, black 000.180.121.101...
-
Page 6: Installation
Set the vehicle to normal level. Switch on the ignition. Press the switch for 10-20 seconds. The following message is displayed on the multifunction display of the instrument panel: "Control switched off". TECHART Version 03 dated February 19, 2019 Page 6 of 17... -
Page 7: Detach Original Front Panel
Detach polyurethane cover around hood lock. Remove 4 top fastening bolts (see arrows) Detach retaining clips (1) at right and left between headlight and front flap towards the flap. TECHART Version 03 dated February 19, 2019 Page 7 of 17... - Page 8 Water may run out when the water hose is disconnected. Collect the water in a suitable container. 10 Detach original front panel by pulling to the front. Fig. 03 TECHART Version 03 dated February 19, 2019 Page 8 of 17...
-
Page 9: Assembly Of Techart Multifunctional Daytime Running Lights
Assembly of TECHART multifunctional daytime running lights 2.1 Assembly of TECHART combination lamp The bonding surfaces of the TECHART panels, the original front apron and the grille must be dry and free of dust. Use cleaning agent to thoroughly degrease bonding surfaces on the TECHART panels, the original front apron and the grille. - Page 10 TECHART panel. • Section 2 (S2) both bars at the rim. • Hold the TECHART panel 070.100.188.10_ (10) on trial. Fig. 05 Fit grille (6) back into original front panel. TECHART Version 03 dated February 19, 2019 Page 10 of 17...
- Page 11 (8) on the top at the original fixing points. Fig. 08 Press on the parts firmly in the bonding area. Ensure an accurate fit and remove any escaping adhesive with cleaning agent. TECHART Version 03 dated February 19, 2019 Page 11 of 17...
-
Page 12: Install Techart Control Unit
TECHART outer panel (9) with the screw 4.8x25. Fig. 09 Tighten the TECHART control unit 000.180.120.000-02 (12) with the screws 4.8x32 to the holder control unit (11). Fig. 10 TECHART Version 03 dated February 19, 2019 Page 12 of 17... -
Page 13: Install Techart Wiring Harness
After crimping, heat up all crimp connectors using a hot air gun so that they form a watertight seal. Fig. 11 Connect the TECHART wiring harness 000.180.182.500 (13) with the plug (14) as follows: • Pin 1 at the plug = gray (position light). - Page 14 ASSEMBLY INSTRUCTIONS TECHART Multifunctional daytime running lights Connect the short red cable from the TECHART wiring harness (13) incl. fuse holder with the original wiring harness. On the headlight combination connector in the fender: • Cut off the Pin 4 yellow/green (right) yellow/blue (left) 20 mm behind the connector.
- Page 15 9a = TECHART multifunctional lamp right 000.180.120.100 9b = TECHART multifunctional lamp left 000.180.120.101 12 = TECHART control unit 000.180.120.200 21 = TECHART cable set new 000.180.182.009 OE = Original wiring harness TECHART Version 03 dated February 19, 2019 Page 15 of 17...
-
Page 16: Fit Original Front Apron
Connect the electrical connections and the water hose for the headlight washing system at the right wheel arch. Connect the TECHART wiring harness left and right in the wheel arch. Tighten the wheel house shells again. Reconnect the high-beam headlights. - Page 17 TEL +49 7152 / 9339- 0 FAX +49 7152 / 9339-33 info@techart.de www.techart.de Subject to change at any time without prior notice. Copyright 2019 by TECHART Automobildesign GmbH Part No. 070.180.182.099 TECHART Version 03 dated February 19, 2019 Page 17 of 17...
