- Page 1 ASSEMBLY INSTRUCTIONS TECHART Aero-Kit I 987 Cayman from MY09 Part no. 087.100.103.009 Front spoiler I Part no. 087.100.340.009 Side skirts Part no. 087.100.801.009 Rear spoiler I Version 03 - 2012 Assembly Instructions 087.100.103.099...
-
Page 2: Table Of Contents
ASSEMBLY INSTRUCTIONS TECHART Aero-Kit I 987 Cayman from MY 09 Contents Important safety information ........................3 Preparation ...............................4 Installation ..............................6 Prepare the vehicle ........................6 Remove wheels and detachable parts ................6 Paint TECHART parts........................7 TECHART front spoiler .........................7 Preparation ........................7 Fit TECHART front spoiler.....................8 TECHART side skirt........................9... -
Page 3: Important Safety Information
ASSEMBLY INSTRUCTIONS TECHART Aero-Kit I 987 Cayman from MY 09 Important safety information All of the necessary work must be performed by qualified persons with an appropriate level of expertise. Vehicle lifts with an insufficient lifting capacity can collapse under the weight of the vehicle and crush any persons standing underneath. -
Page 4: Preparation
ASSEMBLY INSTRUCTIONS TECHART Aero-Kit I 987 Cayman from MY 09 Risk of injury from hands and arms being crushed, cut or lacerated when working with sharp-edged and bulky objects. Wear protective clothing and protective gloves. Keep limbs out of narrow and inaccessible areas of the vehicle and/or avoid dangerous situations by using special tools and suitable aids. - Page 5 TECHART drilling template Please, use the table to check whether all of the required parts are present. Please, contact us immediately if any parts should be missing: support@techart.de Once parts have been removed from their original packaging, ensure that they are properly handled and stored.
-
Page 6: Installation
ASSEMBLY INSTRUCTIONS TECHART Aero-Kit I 987 Cayman from MY 09 Installation Prepare the vehicle Before starting work, check that the vehicle is free from defects. Use the PIWIS system tester to read out all the fault memories of the individual vehicle components and first rectify any faults displayed. -
Page 7: Paint Techart Parts
Prepare and paint TECHART parts in accordance with the paint instructions. TECHART front spoiler 3.1 Preparation The bonding surfaces on the TECHART front spoiler and original front apron must be dry and free from dust and paint spray mist. Use cleaning agent to thoroughly degrease bonding surfaces on the TECHART front spoiler and original front apron. -
Page 8: Fit Techart Front Spoiler
Press on firmly in areas coated with adhesive. Check for accurate fit – remove any escaping PU adhesive with cleaning agent. Secure TECHART front spoiler with adhesive tape so that it has firm contact with the surface at all points. -
Page 9: Techart Side Skirt
TECHART Aero-Kit I 987 Cayman from MY 09 TECHART side skirt 4.1 Preparation The bonding surfaces on the TECHART side skirts and vehicle sills must be dry and free from dust or paint spray mist. Use cleaning agent to thoroughly degrease bonding surfaces on TECHART side skirts and vehicle sills. -
Page 10: Install Techart Side Skirts
Align side skirt from the front. Press on firmly in areas coated with adhesive. Check for accurate fit – remove any escaping PU adhesive with cleaning agent. Secure TECHART side skirt with adhesive tape, so that it contacts the surface firmly at all points. -
Page 11: Techart Rear Spoiler
TECHART Aero-Kit I 987 Cayman from MY 09 TECHART rear spoiler I 5.1 Preparation The bonding surfaces on the TECHART rear spoiler must be dry and free from dust and paint spray mist. Use cleaning agent to thoroughly degrease bonding surfaces on the TECHART Rear Spoiler. -
Page 12: Deactivation Of The Spoiler Control
ASSEMBLY INSTRUCTIONS TECHART Aero-Kit I 987 Cayman from MY 09 Allow to dry for at least 12 hours. Fix the TECHART rear spoiler I with the screw M5x16 through the hole for the rubber stops of the rear hatch. The screw is only used fort he fixation. -
Page 13: Perform Final Work On Vehicle
ASSEMBLY INSTRUCTIONS TECHART Aero-Kit I 987 Cayman from MY 09 Perform final work on vehicle 6.1 Finishing touches Mount wheels. Observe specified tightening torques! 6.2 Final inspection Perform a general function test of the vehicle. Carry out a test drive and check the alignment of the hot tailpipes again. - Page 14 ASSEMBLY INSTRUCTIONS TECHART Aero-Kit I 987 Cayman from MY 09 TECHART AUTOMOBILDESIGN GMBH RÖNTGENSTRASSE 47 D-71229 LEONBERG / GERMANY TEL +49 (0) 7152 / 9339- 0 FAX +49 (0) 7152 / 9339-33 info@techart.de www.techart.de E&O excepted. Subject to change at any time without prior notice.
