- Page 1 Installation manual MEROxI audac.eu...
-
Page 2: Additional Information
This manual is put together with much care, and is as complete as could be on the publication date. However, updates on the specifications, functionality or software may have occurred since publication. To obtain the latest version of both manual and software, please visit the Audac website @ audac.eu. REV-1.1... - Page 3 Introduction High-end in-wall speaker The MERO speakers will blend beautifully into any interior, making only their extraordinary sound draw your attention with their nearly invisible design. Their slim grill with a very thin border of only 1mm and limited grill depth extrudes the surface by only 3.2 mm when installed. Their grilles are retained by neodymium magnets which enable assembly in seconds, while powerful enough to keep it fixed, even when subject to vibrations or if touched.
- Page 4 Precautions READ FOLLOWING INSTRUCTIONS FOR YOUR OWN SAFETY ALWAYS KEEP THESE INSTRUCTIONS. NEVER THROW THEM AWAY ALWAYS HANDLE THIS UNIT WITH CARE HEED ALL WARNINGS FOLLOW ALL INSTRUCTIONS NEVER EXPOSE THIS EQUIPMENT TO RAIN, MOISTURE, ANY DRIPPING OR SPLASHING LIQUID. AND NEVER PLACE AN OBJECT FILLED WITH LIQUID ON TOP OF THIS DEVICE NO NAKED FLAME SOURCES, SUCH AS LIGHTED CANDLES, SHOULD BE PLACED ON THE APPARATUS DO NOT PLACE THIS UNIT IN AN ENCLOSED ENVIRONMENT SUCH AS A BOOKSHELF OR CLOSET.
- Page 5 CAUTION USE CABLES OF THE RIGHT GAUGE TO CONNECT THE LOUDSPEAKER USE CABLES WITH CLEAR COLOUR CODING INDICATING THE POLARITY AND MAINTAIN THE SAME POLARITY THROUGHOUT THE WHOLE SYSTEM. ONLY USE THE CORRECT AMPLIFIER OUTPUT VOLTAGE AND IMPEDANCE. EXCEEDING THESE LIMITS COULD CAUSE FIRE OR OTHER FAILURES.
-
Page 6: Installation Procedure
Chapter 1 Installing the MEROxI Introduction The MERO speakers feature a quick-fixing mechanism, which allows quick and easy installation of the loudspeakers in only a few minutes. The installation of the MERO speakers requires a minimum amount of installation skills. Before the loudspeaker is installed, the location where it will be mounted should be carefully checked to make sure the surface can support the weight of the speaker and no lines for water, gas, electricity or other supplies are crossing this point. - Page 7 4) Connect the loudspeaker connection cable to the gold plated spring clamp connectors. Press the button of the corresponding terminal down and insert the connection cable. After releasing the button, the cable is connected to the loudspeaker. The Red terminal indicates positive (+) pole and the Black terminal indicates the negative (-) pole.
-
Page 8: Technical Specifications
GLM05/B GLM06/B Optional accessories Black grill (RAL9005) Black grill (RAL9005) Black grill (RAL9005) GLM02/P GLM05/P GLM06/P Paintable grill Paintable grill Paintable grill WTR06 WTR24 6W 100V line transformer 24W 100V line transformer Discover more on audac.eu MEROxI - Installation manual...
