MTX Commands User Manual
Index
Introduction
Input list
Output list
Using the commands
SVx
Set Master Volume
SVU0x
Set Master Volume Up 3dB
SVD0x
Set Master Volume Down 3dB
SRx
Set Routing
SRU0x
Set Routing Up
SRD0x
Set Routing Down
SB0x
Set Bass
ST0x
Set Treble
SM0x
Set Mute
GVALL
Get Volume info for all zones
GRALL
Get Routing info for all zones
GMALL
Get Mute info for all zones
GV0x
Get Volume info for 1 zone
GR0x
Get Routing info for 1 zone
GM0x
Get Mute info for 1 zone
GB0x
Get Bass info for 1 zone
GT0x
Get Treble info for 1 zone
GZI0x
Get Volume, Routing, Mute, Bass, Treble for 1 zone 8
SAVE
SAVE settings
DEF
Load factory settings
GSV
Get Software Version
2
2
2
3
4
4
4
4
5
5
5
6
6
6
6
7
7
7
7
7
8
8
8
8
1
Advertisement
Table of Contents
Related Manuals for AUDAC MTX
Summary of Contents for AUDAC MTX
- Page 1 MTX Commands User Manual Index Introduction Input list Output list Using the commands Set Master Volume SVU0x Set Master Volume Up 3dB SVD0x Set Master Volume Down 3dB Set Routing SRU0x Set Routing Up SRD0x Set Routing Down SB0x Set Bass...
- Page 2 Introduction Welcome to the command user manual of the AUDAC MTX48 and MTX48 . For more info about the MTX48 and MTX88 see the user manual. Input list Mic 1 Mic 2 Line 3 Line 4 Line 5 Line 6...
- Page 3 “#” Command flow 1) The client sends a command to the MTX 2) The MTX acknowledges the command by returning the same command and a ‘+’ as Argument. 3) The MTX updates all client’s with the new information All volume, routing and tone settings will be lost if the device is switched off. To keep the changes you must save them with the “SAVE”...
- Page 4 Set output volume of a zone to a level Command: SVx, with x the zone where the volume should be changed. Arguments: Volume in neg db, 0 is maximum volume, 70 is minimum volume Example Set volume in zone 2 to -40dB Command #|X001|web|SV2|40|U|return Answer...
- Page 5 SRU0x Set Routing up in a zone Command: SRU0x, with x the zone where the routing should be changed. Arguments: 0 (none) Remark The inputs that are disabled in the input selection menu on the website will be skipped. Example Increase routing for zone 1 Command #|X001|web|SRU01|0|U|return...
- Page 6 ST0x Set treble in a zone Command: ST0x, with x the zone where the treble should be changed. Arguments: from 0 to 14. (from -14dB to +14dB in 2dB steps with 7 = 0dB) Example Set treble to -4dB in zone 1 Command #|X001|web|ST01|5|U|return Answer...
- Page 7 GMALL Get Mute info for all zones Command: GMALL Arguments: 0 (none) Example Command #|X001|web|GMALL|0|U|return Answer #|web|X001| MALL|0^0^0^0^0^0^0^0|U|return GV0x Get Volume info for a zone Command: GV0x, with x the number of the zone Arguments: 0 (none) Example Get routing info for zone 1 Command #|X001|web| GV01|0|U|return Answer...
- Page 8 GT0x Get Treble info for a zone Command: GT0x, with x the number of the zone Arguments: 0 (none) Example Get treble info for zone 1 Command #|X001|web| GT01|0|U|return Answer #|web|X001| T01|07|U|return GZI0x Get volume, routing, mute, bass, treble info for 1 zone Command: GZI0x, with x the number of the zone Arguments: 0 (none) Example...
