- Page 1 LEFT ( 1 : 4 ) BACK ( 1 : 4 ) Connection manual FX3.15 FX3.15 ISO 2768 - mK 15" SUBWOOFER 18MM PLYWOO CABINET 700 X 456 X 58 audac.eu...
- Page 2 Precautions READ FOLLOWING INSTRUCTIONS FOR YOUR OWN SAFETY ALWAYS KEEP THESE INSTRUCTIONS. NEVER THROW THEM AWAY ALWAYS HANDLE THIS UNIT WITH CARE HEED ALL WARNINGS FOLLOW ALL INSTRUCTIONS NEVER EXPOSE THIS EQUIPMENT TO RAIN, MOISTURE, ANY DRIPPING OR SPLASHING LIQUID. AND NEVER PLACE AN OBJECT FILLED WITH LIQUID ON TOP OF THIS DEVICE NO NAKED FLAME SOURCES, SUCH AS LIGHTED CANDLES, SHOULD BE PLACED ON THE APPARATUS THIS UNIT IS DEVELOPED FOR INDOOR USE ONLY.
- Page 3 Connection Diagram The FX3.15 has no passive internal crossover., instead the speaker has low frequency tweeter overload protection that consists of 2 capacitors in parallel. The FX3.15 is active filtered. A recommended typical connection diagram shown below. It is highly recommended the installation of the system is done by a professional.
- Page 4 Discover more on audac.eu...
