Single Channel EEG Test System | User Manual
WHALETEQ
Single Channel EEG Test System
(SEEG 100E)
User Manual
Version 2024-11-24
PC Software Version 1.0.10.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SEEG 100E and is the answer not in the manual?

Questions and answers

Summary of Contents for WHALETEQ SEEG 100E

  • Page 1 Single Channel EEG Test System | User Manual WHALETEQ Single Channel EEG Test System (SEEG 100E) User Manual Version 2024-11-24 PC Software Version 1.0.10.1...
  • Page 2 This document could contain technical inaccuracies or typographical errors. Changes are periodically made to the information herein; these changes will be incorporated in future revisions of this document. WhaleTeq Co. LTD. is under no obligation to notify any person of the changes.
  • Page 3: Table Of Contents

    Contents Introduction ..................5 1.1 Basic Concept ..................... 5 1.2 Standards/Application ................6 1.3 Block Diagram/SEEG 100E Module Overview ..........7 1.4 Main Specifications ..................8 1.5 Cautions ....................10 PC Software Mode ................11 2.1 Installation and Environment ..............11 2.1.1 System Requirements ....................
  • Page 4 Table 5: Waveform Settings .................. 16 Table 6: Calibration Procedure ................25 Table 7: Troubleshooting ..................27 Table 8: SEEG 100E Standard Package ..............28 Table 9: Optional Accessories ................28 Table 10: Optional Calibration Service and Warranty Extension ......29...
  • Page 5 List of Figure Figure 1: Single-channel Concept ................5 Figure 2: Simplified Block Diagram ................. 7 Figure 3: SEEG 100E Hardware Overview ............... 7 Figure 4: Execute SEEG 100E Software ..............12 Figure 5: EEG Breakout Box .................. 13 Figure 6: Low-noise Test Environment Setup ............14 Figure 7: Main Screen ...................
  • Page 6: Introduction

    Ch10~Ch22 Figure 1: Single-channel Concept Via a SEEG 100E, the system produces arbitrary waveforms (streamed from the PC with digital to analogue conversion) at up to ±1V, which is then applied to a precision 500:1 divider to produce the voltages at up to ±1mV level (2mVpp). The SEEG 100E contains resistor/capacitor networks, dc offset, and relay switching to provide the full range of single channel performance tests in IEC standard.
  • Page 7: Standards/Application

    Single Channel EEG Test System | User Manual 1.2 Standards/Application The following table shows the standards for which this system has been designed for, and includes any limitations: Table 1: Supported Medical Standards Standard Clause(s) Limitations/Notes 201.12.1 all performance tests except IEC 80601-2-26:2012 201.12.1 201.12.1.104 input noise and...
  • Page 8: Block Diagram/Seeg 100E Module Overview

    Single Channel EEG Test System | User Manual 1.3 Block Diagram/SEEG 100E Module Overview The following is a simplified block diagram of the system inside the SEEG 100E module: Precision dc offset ±150mV 500:1 Divider (50KΩ 0.1%) 500:1 Divider (50KΩ...
  • Page 9: Main Specifications

    Single Channel EEG Test System | User Manual Main Specifications In general, the system has been designed in accordance with IEC 80601-2-26:2019 standard. The SEEG 100E specifications are listed below. • Technical Specifications Table 2: Technical Specifications Parameters Specifications Main output voltage accuracy ±1% for amplitudes of 50µVpp or higher...
  • Page 10: Table 3: Signal Specifications

    Single Channel EEG Test System | User Manual • Signal Type Table 3: Signal Specifications Default Minimum Parameters Setting Range Values Step Size 0.05-500Hz Frequency (Hz) 10Hz 0.01 Sine (-2000)-2000µV Amplitude 100µV 0.05-500Hz Frequency (Hz) 10Hz 0.01 Triangle (-2000)-2000µV Amplitude 100µV Frequency (Hz) 0.05-500Hz...
  • Page 11: Cautions

    • WhaleTeq does not recommend to connect test equipment with DUT to conduct Electrostatic Discharge (ESD) test. This may cause unexpected damages to test equipment. Please contact WhaleTeq for alternatives before ESD test.
  • Page 12: Pc Software Mode

    • When the installation is completed, SEEG software would be executed automatically. User can also execute SEEG software via selecting “All Programs” → “WhaleTeq” → “WhaleTeq SEEG” in Windows startup program manager. Relative to normal PC processing, there is no special use of PC speed. However, there has been noted a slow increase in system RAM usage over long periods of time up to 30-40MB (related to MS Windows “garbage collection”).
  • Page 13: First Time Using Whaleteq Product-Usb Driver Installation

    Single Channel EEG Test System | User Manual Figure 4: Execute SEEG 100E Software If SEEG software can’t be executed properly or this is the first time using WhaleTeq product, please refer to section 2.1.3 and 2.1.4 to confirm that USB driver and Microsoft .Net Framework 4.5.2 are all installed.
  • Page 14: First Time Using Whaleteq Product - Microsoft .Net Framework 4.5.2 Installation

    4.5.2. 2.2 Connecting to the EEG For connecting the EEG device to the SEEG 100E and use the provided 22 channels “EEG breakout box”. There are only 9 terminals (Ch1~Ch9) could output waveforms, and the rest 13 terminals (Ch10~Ch22) are connected to ground.
  • Page 15: Reduce Environmental Noise

    Single Channel EEG Test System | User Manual Alternately the EEG device under test can be directly connected to the SEEG 100E module using a male D15 connector. The pin outs are: 1–Ch1 4–GND 7–Ch6 10–Ch9 2–Ch2 5–Ch4 8–Ch7 3–Ch3 6–Ch5...
  • Page 16: Main Screen

    Single Channel EEG Test System | User Manual 2.4 Main Screen Figure 7: Main Screen Select the main function (waveform) type, such as sine, triangle and square wave Select the pulse function (waveform) type, such as rectangle pulse, triangle pulse and Hysteresis Parameter setting Select the pulse width for rectangle and triangle pulse only, time constant for hysteresis only...
  • Page 17: Description Of Functional Groups

    Single Channel EEG Test System | User Manual 2.5 Description of Functional Groups 2.5.1 Main Function (Main Waveform) This group allows the operator to select the main waveform to be used in the test, from the following: Table 5: Waveform Settings Waveform Description Sample Waveform...
  • Page 18 Single Channel EEG Test System | User Manual Waveform Description Sample Waveform Type A range of stored waveforms including: (1) load waveform and (2) load EDF File PhysioNet database Manager, through internet, then Load play. Waveforms For these waveforms, the amplitude and frequency settings have no effect.
  • Page 19: Main Parameters

    Single Channel EEG Test System | User Manual 2.5.2 Main Parameters Figure 8: Amplitude, Frequency, and Pulse Width Settings Amplitude: Can be set in either mV or µV, changing one will automatically change the other to match. The waveform amplitude from -2mV to +2mV at a 0.001mV (1µV) resolution. For all waveforms the amplitude represents the peak to peak value.
  • Page 20: Dc Offset Setting

    Single Channel EEG Test System | User Manual 2.5.3 DC Offset Setting Figure 9: DC Offset Settings This function allows the operator to switch in a dc offset. In the default condition (not variable), only +150mV, 0 or -150mV can be set. In this mode, the dc offset is sourced from an internal “super capacitor”...
  • Page 21: Output Lead Electrode

    Single Channel EEG Test System | User Manual 2.5.5 Output Lead Electrode Figure 11: Output Lead Electrode Settings This section allows the user to select which lead electrode the output is connected to (i.e. terminal P1 in the IEC 80601-2-26:2019, Figure 201.104). Unselected electrodes are connected to the system ground (terminal P2 in Figure 201.104).
  • Page 22: Special Functions

    Single Channel EEG Test System | User Manual 2.5.7 Special Functions Figure 13: Special Functions Baseline reset test (sine wave only): When checked the parameters are ignored and a large signal of 1Vpp (0.354Vrms) is applied. It is intended to test the EEG’s response to overload, in particular automated resetting of baseline (due to high pass filtering).
  • Page 23: Figure 14: Special Waveforms

    Single Channel EEG Test System | User Manual Special Waveforms: WhaleTeq SEEG 100E can play PhysioNet waveforms with 1 electrode at each time. This feature will download waveforms from PhysioNet directly. Please check your internet status before use this feature.
  • Page 24: Iec 80601-2-26 Helper

    Single Channel EEG Test System | User Manual 2.6 IEC 80601-2-26 Helper It is a companion software add-on to enhance the function of SEEG 100E. It supports the latest EEG standards IEC 80601-2-26:2019 with detailed preset parameter settings and actual test sequence for testing needs.
  • Page 25: Figure 16: Seeg 100E Calibration Items

    Single Channel EEG Test System | User Manual Figure 16: SEEG 100E Calibration Items The user then enters the results into the form provided, and the software checks if the results are within allowable limits. When complete, the results of calibration are automatically copied to the notepad and stored in a text file at: C:\WhaleTeq\SEEG_Cal_yyyymmdd.txt...
  • Page 26: Calibration Procedure

    Single Channel EEG Test System | User Manual 2.7.1 Calibration Procedure Table 6: Calibration Procedure Nominal value, Parameter Method tolerance This can be measured as follows: • Set Main function to “Off” Input • Set output to ch1 impedance 620kΩ±1% resistor •...
  • Page 27 Single Channel EEG Test System | User Manual Nominal value, Parameter Method tolerance • Confirm all values are within 1% or 5µV of the set value Note: The Fluke 8845A has suitable accuracy at 10mVpp but has borderline accuracy at 1mVpp and lower.
  • Page 28: Software Development Kit (Sdk)

    Single Channel EEG Test System | User Manual 3 Software Development Kit (SDK) WhaleTeq provides SEEG 100E software development kit. All operating parameters and options have corresponding commands in the software development kit. The software development kit contains DLL (Dynamic-link library), which will provide highly efficient program binding and version upgrade, supports C/C++ header and C# interface, and can also be integrated with third-party tools and script languages.
  • Page 29: Ordering Information

    Single Channel EEG Test System | User Manual 5 Ordering Information 5.1 Standard Package Table 8: SEEG 100E Standard Package Part No. Description Quantity Model No.: SEEG 100E Single Channel EEG Test System with one EEG Breakout Box and Assistant Software for IEC 80601-2-26:2019 performance tests.
  • Page 30: Revision History

    Description Model No.: C3 Provides (3) years of calibration service coverage. YY0007 WhaleTeq equipment can be calibrated to original performance on the basis of (1) year interval. Model No.: R3 YY0008 Extends the limited warranty from (1) year to (3) years.
