  • Page 1 WHALETEQ DFS360 / DFS360D User Manual PC Software Version 1.0.0.28 Revision 2021-10-22...
  • Page 2 This document could contain technical inaccuracies or typographical errors. Changes are periodically made to the information herein; these changes will be incorporated in future revisions of this document. WhaleTeq Co. LTD. is under no obligation to notify any person of the changes.
  • Page 3: Table Of Contents

    DFS360|User Manual Contents Introduction ..................6 1.1 Concept .................... 6 1.2 Applications ..................6 Specification ..................7 2.1 General Specifications ..............7 2.2 Compliance Specifications ..............7 2.3 Energy Measurement Specifications ..........8 2.4 ECG Signal Specifications..............8 Instrument Familiarization ..............9 3.1 Top ....................
  • Page 4 5.4.1 Command Function ..............26 Standalone Operation ..............28 Calibration and Validation ............... 28 Troubleshooting ................29 Cautions ..................29 10 Ordering Information ............... 30 11 Package Contents ................32 12 Revision History ................32 13 Contact WhaleTeq ................33...
  • Page 5 Table 10: Ordering info. for DFS360 ..........30 Table 11: Ordering info. for DFS360D ..........30 Table 12: Optional DFS360/DFS360D Paddle Box Set ..... 31 Table 13: Optional Software Add-On Pack ........31 Table 14: Optional Calibration Service and Warranty Extension ..31 Table 15: Package Contents for DFS360 ..........
  • Page 6 Figure 2: Front Side of DFS360 / DFS360D ........10 Figure 3: Rear Side of DFS360 / DFS360D ........10 Figure 4: Left and Right Side of DFS360 / DFS360D ......11 Figure 5: Wiring Diagram ..............12 Figure 6: Correct Wiring Diagram of the AED Cable ......12 Figure 7: Correct Wiring Diagram of the USB Cable ......
  • Page 7: Introduction

    DFS360D is designed to withstand more intense defibrillation shocks over longer stretches; it takes shocks at 15-second intervals, meaning a boost of testing capacity. in all, DFS360 / DFS360D is a durable tester to speed up AED or defibrillator automatic production. Applications...
  • Page 8: Specification

    Remote (PC Software via API and SDK) Modes Housing: ABS Plastic Mechanical Size (L x W x H): 19.0 x 12.5 x 6.0 (cm) Weight: DFS360: 665g / DFS360D: 815g Compliance Specifications Table 2: Compliance Specifications Function Specifications IEC/EN61010-1:2010 + A1:2016; Pollution Safety...
  • Page 9: Energy Measurement Specifications

    DFS360|User Manual Energy Measurement Specifications Table 3: Energy Measurement Specifications Function Specifications Maximum Energy Up to 600 J ± 1 % of reading ± 1 J for up to 360J; Accuracy ± 1 % of reading ± 1 J, typical for 360J ~ 600J Resistance: 50Ω...
  • Page 10: Instrument Familiarization

    DFS360|User Manual Instrument Familiarization Figure 1: Top Side of DFS360 / DFS360D...
  • Page 11: Front

    Figure 3: Rear Side of DFS360 / DFS360D USB Port: Use to supply power. Also, it can be used to connect to the computer for command sending and data transferring. DFS Status LED: Indicate the working state of DFS360 / DFS360D Mode...
  • Page 12: Left And Right Side

    DFS360|User Manual Left and Right Side Figure 4: Left and Right Side of DFS360 / DFS360D Air Inlet: Allow ventilation during long hours of operation. Air Outlet: Allow ventilation during long hours of operation.
  • Page 13: Wiring Diagram

    3.5.1 Connection Diagram and Precautions Connect the AED cable to DFS360 / DFS360D. 。 Do not put the AED cable on DFS360 / DFS360D main console. 。 The AED cable should not twist together. Figure 6: Correct Wiring Diagram of the AED Cable...
  • Page 14: Figure 7: Correct Wiring Diagram Of The Usb Cable

    。 The USB cable and PC/ Laptop should not be placed near the AED cable. 。 The USB cable should not twist with the AED cable. 。 The USB cable should not be placed on DFS360 / DFS360D main console. Figure 7: Correct Wiring Diagram of the USB Cable Make sure the output voltage of the USB cable falls between 4.75V ~ 5.25V (The minimum input voltage that DFS360 /...
  • Page 15: Getting Started

    DFS360|User Manual Getting Started PC System Requirements DFS360 software uses a Windows PC to connect and control DFS360 DFS360D via USB module. PC requirements: - Windows PC (Windows 7 or later, suggest to use the genuine version) - Microsoft .NET 4.0 or higher - Administrator access (essential for installing software, driver, and Microsoft .Net Framework)
  • Page 16: Usb Driver Installation

    Device Manager to recognize and install the driver. For Microsoft Windows 8 and Windows 8.1 ⚫ If Windows 8 and Windows 8.1 can’t recognize DFS360 DFS360D unit, please download “mchpcdc.inf” from WhaleTeq’s website. This driver is provided by Microchip®, and is intended to be used with PIC microprocessors which have built-in USB functions.
  • Page 17: Microsoft .Net Framework Installation

    Microsoft’s website. Please click here to watch the tutorial video (from 2:17). PC Software and Firmware Update User can download the latest software from WhaleTeq’s website. If User cannot update the DFS software, please contact WhaleTeq’s service team (service@whaleteq.com).
  • Page 18: Pc Software Operation

    DFS360|User Manual PC Software Operation Software Function Introduction When opening DFS360 AP, User will see the figure below on the screen. Figure 8: AP Interface Table 5: AP Interface Function Introduction Item Name Description ECG Pattern (Before To set the ECG pattern before the defib.)
  • Page 19: Figure 9: Right-Click Function List

    DFS360|User Manual Item Name Description To display the joules of the Energy Joules defibrillation. The Top Icon: The shortcut to the file storage in the local computer. The Middle Icon: To display the Icons position of the characteristic points on the defibrillation waveform.
  • Page 20: 5.1.1 Customize Ecg Waveform

    DFS360|User Manual Table 6: Right-Click Function List Introduction Item Name Description To check whether the DFS360 AP is the Check for Updates latest version. Settings for customized ECG Customize ECG waveforms. (For more information, Waveform please look at sec. 5.1.1)
  • Page 21: Table 7: Customize Ecg Waveform Function Introduction

    5mV; if not, then it will remain the same. 。 The waveform automatically offsets to 0mV. 。 Support only WhaleTeq format when loaded. DFS360 AP supports text file (*.txt) only and file content describes as below: File Format: [sampling frequency]...
  • Page 22 DFS360|User Manual number of signals This number must be greater than 1. signal description The description text for the signal. sample data The raw data unit is mV. Example: 25000 ECG_70 0.324519 0.319712 0.319712 0.319712 0.320913 0.320913 0.320913 0.319712 0.314904 0.313702...
  • Page 23 DFS360|User Manual 0.271635 0.268029 0.262019 0.259615 0.254808 0.256010 0.254808 0.253606 … 0.515625 0.519231 0.521635 0.526442 0.531250 0.534856 0.539663 0.543269 0.546875 0.554087 0.560096 0.561298 0.561298 0.561298 0.560096 0.555288 0.551683 0.550481 0.546875 0.542067 0.534856 0.531250 0.524038 0.520433 0.516827 0.514423 0.509615 0.504808 0.501202...
  • Page 24: Pc Software Operation Instructions

    DFS360D will start sending the ECG pattern to the AED / defibrillator. Check the working status of DFS360 / DFS360D by seeing the AP title bar. 4. The AED will start analyzing the ECG pattern and determine whether a defibrillation shock is needed. (Step for inspecting AED only) 5.
  • Page 25: Table 8: Result Page Function Introduction

    DFS360|User Manual Figure 13: Result Page Table 8: Result Page Function Introduction Item Name Description To show the working status of DFS360 Status / DFS360D. To show the type of waveform of the The Type of Waveform defibrillation. To show the corresponding...
  • Page 26: Over Heat Warning And Function Protection

    DFS360|User Manual Over Heat Warning and Function Protection 5.3.1 AP Display Status DFS360 AP displays as Figure 14 when the heat within DFS360 / DFS360D is too high. The test functions will pause until the temperature drops. Figure 14: High-Temperature Alert When the temperature in DFS360 / DFS360D is in good control, the icon will appear as Figure 15.
  • Page 27: 5.3.2 Dfs Status Led

    DFS360 / DFS360D will start operating. When the temperature in DFS360 / DFS360D drops to normal temperature, the fan stops. Note: When DFS360 / DFS360D is turned on, the fan will start working for a short while of time (power-on self-test). 5.3.4 Over Heat Protection When the temperature in DFS360 / DFS360D is too high, the self- protection will automatically start working.
  • Page 28 DFS360|User Manual Command Description Function Ventricular Tachycardia Plus, Atrial Fibrillation, Asystole) Patient Simulator (NSR) 30 to 240 (increment by 1) BPM (optional) User defined pattern: max. 100 seconds / up to 10 sets Receive Test Energy Waveform Display (available in AP)
  • Page 29: Standalone Operation

    DFS360 AP on the USB-connected computer, the DFS360 / DFS360D device is in Standalone mode. In this mode, the ECG pattern that DFS360 / DFS360D automatically plays is NSR at 5 mV, 80 BPM. Calibration and Validation It is recommended to get DFS360 / DFS360D calibrated annually.
  • Page 30: Troubleshooting

    (by listening to the fan motor). If the red light shows frequently, it is recommended to send the DFS360 / DFS360D back to WhaleTeq for a detailed check (see section 13). Cautions (1) Please use USB 3.0 as power supply for USB type C port.
  • Page 31: Ordering Information

    DFS360|User Manual Ordering Information Standard accessories Table 10: Ordering info. for DFS360 Part No. Description DFS360 Defibrillator Production Line Tester Main Unit 300-DFS36S Compact Splicing Connector N61-0210033 USB Transfer Cable: Type A to C (M to M), 1.8 meter K27-1800304 Table 11: Ordering info.
  • Page 32: Table 12: Optional Dfs360/Dfs360D Paddle Box Set

    DFS360|User Manual USB Transfer Cable: Type A to C (M to M), 1.8 meter K27-1800304 Optional DFS360/DFS360D Paddle Box Set Table 12: Optional DFS360/DFS360D Paddle Box Set Model No. Description 300-DFPDOCK DFS Tester Docking Base for Defibrillator DFS Tester Bridge to Docking Base for...
  • Page 33: Package Contents

    。 DFS Tester Docking Base for Defibrillator 。 DFS Tester Bridge to Docking Base for Defibrillator 。 DFS Tester Defibrillation Receiving Plate 。 User-defined ECG patterns or clinical signals (10 sets) for DFS360/ DFS360D Revision History Table 17: Revision History...
  • Page 34: Contact Whaleteq

    DFS360|User Manual Contact WhaleTeq WHALETEQ Co., LTD service@whaleteq.com | (O)+886 2 2517 6255 8F., No. 125, Songjiang Rd., Zhongshan Dist., Taipei City 104474, Taiwan...
