- Page 1 Thermatel ® Installation and Operating Manual Thermal Dispersion Flow/Level Switch Model TDF/TDL Model TSF/TSL...
- Page 2 Magnetrol/STI will repair or replace the control at no cost a component’s mechanical integrity. Cautions are also to the purchaser (or owner) other than transportation.
-
Page 3: Table Of Contents
Thermatel Model TDF/TDL and TSF/TSL Thermal Dispersion Flow/Level Switch Table of Contents 1.0 Description 4.0 Reference Information 1.1 Principle of Operation...........1 4.1 Specifications............14 2.0 Installation 4.2 Troubleshooting...........17 2.1 Unpacking.............1 4.3 Agency Approvals ..........17 2.2 Quick Start...............2 4.3.1 FM (Factory Mutual)........17 2.3.1 Mounting Position and Location ....2 4.3.2 CSA (Canadian Standards Association)..18 2.3.2 General Mounting Requirements....2... -
Page 4: Description
Description Thermatel Flow/Level Switches use state-of-the-art thermal dispersion technology for gas flow and liquid flow/level monitoring and control. Flow/level detection is accom- plished by sensing changes in the heat transfer characteris- tics of the media. The sensor is available in 316L stainless steel, Hastelloy C, or Monel welded construction with no moving parts. -
Page 5: Quick Start
Quick Start Unless ordered with factory calibration, the Thermatel switch is adjusted for a level switch between air and water. The set point of the unit must be adjusted for your application. To calibrate for other applications, adjust the set point potentiometer, P1. -
Page 6: Installation
Installation The Thermatel Flow/Level Switch has a standard 3⁄ 4 " NPT Direction of mount designed for easy installation through a threaded Level Movement port. Optional 1" NPT thread mount or mounting flanges are also available. 1. Apply thread sealant to the sensor and insert the sensor into the tee junction. -
Page 7: Wiring
Wiring All power and control connections are made at the terminal strip within the electronics enclosure. P1 Set P2 Time delay 12-24 AWG wire is recommended for power and control circuits. JP1 Fail-safe jumper D10 Relay OBSERVE ALL APPLICABLE ELECTRICAL LED (red) CODES AND PROPER WIRING PROCEDURES. -
Page 8: Relay Connections
2.6.1 Relay Connections Relay Connections and Maximum Ratings Model Relay Type Terminal Block Maximum ratings TDF/TDL SPDT 10 amp at 120 - 250 VAC 8 amp at 30 VDC 0.5 amp at 125 VDC TSF/TSL DPDT 10 amp at 120-250 VDC 8 amp at 28 VAC 0.5 amp at 125 VDC Hermetically sealed... -
Page 9: Chart Notes And Definitions
2.6.2 Chart Notes and Definitions A. Equipment controlled by Thermatel relay is assumed to be powered from one source, while the Thermatel unit itself is assumed to be powered from a different source. B. “Fail” means a loss of power to the Thermatel unit. C. -
Page 10: Operation And Calibration
Operation and Calibration Note: Calibration should be performed using the actual fluid at the operating temperature. Note: Potentiometer (P3) is set at the factory to handle most appli- cations. The performance of the switch may be changed by adjusting P3: 1. - Page 11 Adjustment procedure VARIABLE FLOW RATE A. Adjust flow to desired switch point: 1. Rotate P2 (delay) fully counterclockwise. 2. Place JP1 (fail-safe) in the “L” position. 3. Establish the flow rate at the desired switching point. Allow 30 seconds for the sensor to stabilize. 4.
-
Page 12: Level Sensing Applications
8. If the flow can be reduced to the set point, follow pro- cedure A; if it cannot be reduced, follow procedure B. a. Switch on decreasing flow: Slowly rotate P1 (set) counterclockwise until the red LED (D10 or D11) illuminates. -
Page 13: Adjust Set Point
2.7.3 Adjust Set Point Following is a quick guide for adjusting the set point on Thermatel Flow/Level Switch. Process Adjust to detect LED status condition High flow, High level Low flow, Low level Low flow — Low level — o Turn P1 clockwise until LED is off. High flow o Turn P1 clockwise until LED is on. -
Page 14: Advanced Calibration Procedure
2.7.6 Advanced Calibration Procedure Measure and record the voltage between TP1 and TP2. This voltage will change with set point and may be used for future reference or adjustment of set point. 2.7.7 Power On Delay The TSF/TSL switch incorporates a “Power On Delay.” When power to the switch is first applied, there is no temperature difference between the two sensors, causing a high flow or high level alarm. -
Page 15: General Information
General Information Maintenance 3.1.1 Cleaning The probe may be cleaned by soaking, spraying solvents or detergent and water onto the sensor tubes, or by ultra- sonic cleaning. Lime deposits may be safely removed by soaking in 20% hydrochloric acid. Warming to +150° F is permissible to speed this process. -
Page 16: Probe Replacement-Remote Housing
3. Loosen the screws on the four position terminal block (TB1) to remove the leads from the probe. 4. Unscrew probe from enclosure. Installation of replacement probe (Refer to Figure 6 on page 6.) 1. The probe's leads have been separated at the factory. Connect leads from RTD #1, which are grouped and marked, to the two terminals on TB1 closest to the sensor label (refer to Figure 6). -
Page 17: Reference Information
Reference Information Specifications Description Specification Supply Voltage 120 VAC, +10%, -15% 50-60 Hz 240 VAC, +10%, -15% 50-60 Hz 24 VDC, ±20% Power Consumption 5 Watts maximum Output Relay TD Electronics SPDT, 10 Amp, 120 VAC, 250 VAC Gold Flash Contacts 8 Amp, 30 VDC, 0.5 Amp, 125 VDC TS Electronics DPDT, 10 Amp, 120 VAC, 250 VAC... - Page 18 Specifications (cont.) DIMENSIONAL SPECIFICATIONS INCHES (MM) 5.25 3.87 (133) (98) 9.18 9.25 3/4" NPT 6.95 (233) (235) Conduit (177) connection 1" NPT 1" NPT Conduit Conduit connection connection NPT Process 1.57 connection 2.18 (44) 1.57 NPT Process (55) (44) connection Welded BSP Thread BSP Thread...
-
Page 19: Pressure/Temperature Rating
Specifications (cont.) DIMENSIONAL SPECIFICATIONS INCHES (MM) 4.63 (118) Dia. 3.00 (76) Rotation 8.00 10.75 clearance (203) (273) Insertion 2.75 Insertion (70) length length " NPT Conduit Insertion (22) Dia. (16) Dia. connection length Figure 16 Figure 17 Figure 15 Remote Sensor Housing Spherical Tip Probe ⁄... -
Page 20: Troubleshooting
Troubleshooting Is the unit getting supply voltage? Check voltage at terminal strip. Is the yellow power LED lit? Check fuse. Turn time delay (P2) fully counter- clockwise. Move fail-safe jumper to opposite position. Does the red LED (D10 or D11) Replace PC board. -
Page 21: Csa (Canadian Standards Association)
Agency Approvals 4.3.2 CSA (Canadian Standards Association) AGENCY MODEL APPROVED APPROVAL CATEGORY APPROVAL CLASSES TXX-XXX0-E00 Explosion Proof Class I, Div 1; Groups C, D TXX-XXX0-Y00 Class II & III, Div 1; Groups E, F, G T4A Type 4X TXX-XX00-J00 Explosion Proof Class I, Div 1;... -
Page 22: Explosion Proof
4.3.5 Explosion Proof Parts 12 13 Front view Side view Thermatel Model TDF/TDL and TSF/TSL Thermal Dispersion Flow/Level Switch, 54-601... -
Page 23: Replacement Parts
4.4.2 Replacement Parts Item Description Part Number Base NEMA 4X/7/9 004-9182-003 Cover, NEMA 4X/7/9 002-6204-600 O-Ring, NEMA 4X/7/9 012-2101-345 TDF/TDL with 10 TSF/TSL with 10 Main PC Board Integral Sensor amp SPDT relay amp DPDT relay 120 VAC 30-3536-002 30-3572-001 240 VAC 30-3536-004 30-3572-003... -
Page 24: Model Numbers
Model Numbers 4.5.1 Electronics Models BASIC MODEL NUMBER Standard (TD) SPDT Relay On-demand electronic self-test (TS) DPDT relay APPLICATION Flow Level OUTPUT 10 Amp SPDT relay w/gold flashed contacts (Model TD) 10 Amp DPDT relay w/gold flashed contacts (Model TS) 5 Amp hermetically sealed DPDT relay w/gold flashed contacts (Model TS) INPUT VOLTAGE 120 VAC... -
Page 25: Probe Design
Model Numbers 4.5.2 Probe Models PROBE DESIGN Probe length in inches Probe length in centimeters TIP STYLE Twin tip Spherical tip – available in 316L stainless steel only (code 22) PROCESS CONNECTION* ⁄ " NPT 1" NPT ⁄ " sanitary flange 2"... -
Page 26: Model Numbers
Model Numbers 4.5.3 High Temperature Probe* Models High temperature probe includes 8" (20 cm) heat extension PROBE DESIGN Probe length in inches Probe length in centimeters PROCESS CONNECTION* ⁄ " NPT 1" NPT 1" 150# 1" 300# 1" 600# 1" 1500# ⁄... -
Page 27: Electronic Models
Model Numbers 4.5.4 Low Flow Body Models LOW FLOW DESIGN Standard FLOW BODY CODE ⁄ " ⁄ " PROCESS CONNECTION MOUNTING BRACELET None Provided complete order code for Thermatel Low flow body 4.5.5 Connecting Cable Models CONNECTING CABLE IN FEET Cable length in feet;... - Page 28 Prepaid transportation. through Magnetrol/STI's local representative or by Magnetrol/STI will repair or replace the control at no cost contacting the factory. Please supply the following to the purchaser (or owner) other than transportation if: information: 1. Returned within the warranty period; and 1.
