AFi KING - Bed Frame Manual

ATTENTION! If you receive a damaged or defective item, please contact afifurnishings at customerservice@afifurnishings.com or 1-800-955-3726

BED FRAME

PARTS LIST

1. FOOT RAIL 1 PC
2. LEFT LEG 1 PC
3. RIGHT LEG 1 PC
4. SIDE RAILS 2 PCS
5. SLAT KIT 2 SET
6. HB SUPPORT RAIL 1 PC
7. FB SUPPORT RAIL 1 PC
8. SUPPORT LEGS 3 PCS

HARDWARE

NOTE: WE INCLUDE SPARE HARDWARE IN CASE DAMAGE OCCURS DURING ASSEMBLY.

ASSEMBLY INSTRUCTIONS

Step 1

Attach the legs (2) and (3) to foot rail (1), using wood dowel (C) JCB M6 X 70mm (A) and barrel nut (B).
Tighten with the Allen wrench (I).
Cover holes with wood button (D) as shown.

Step 2

Attach the side rails (04) to the headboard and footboard (1) using the bed hook as shown below.

Step 3

Attach support leg (8) to support rail (6)(7) as shown below. Using JCB M8 (G) tighten with Allen wrench M5 (J).

Step 4

Attach HB support rail (6) and FB support rail (7) to the slat kit (5) as shown below using JCB M6 X 30mm (E) and cap nut (F). Tighten with Allen wrench M4 (I). Using wood screw (H) tighten with Phillips head screwdriver. (Customer supplied)

Congratulations!
Your bed is now ready for use.
We recommend that you periodically recheck that all screws are tight to ensure lasting safety.

HEADBOARD

Instructions apply for bed sizes TWIN > FULL > QUEEN > KING

PARTS LIST

1. HEADBOARD PANEL 1 PC
2. LEFT LEG 1 PC
3. RIGHT LEG 1 PC

HARDWARE

NOTE: WE INCLUDE SPARE HARDWARE IN CASE DAMAGE OCCURS DURING ASSEMBLY.

ASSEMBLY INSTRUCTIONS

Step 1

Attach the legs (2) and (3) to headboard panel (1), using wooden dowels (A) and JCB (B). Tighten with the Allen wrench (F).

WOOD BED FRAME

Your bed can be assembled using an open footrail or panel footboard. The open footrail has a choice of tall or short legs.

ATTACHING HEADBOARD TO METAL BED FRAME

Instructions apply for bed sizes TWIN > FULL > QUEEN > KING

Metal bed frames are sold separately from wood headboards. The hardware shown on this page is supplied with your wood headboard for attaching the bed frame to the headboard. The metal bed frame is supplied with its own assembly instructions and hardware.

Step 1

Attach the headboard assembly to the metal frame using JCB (C), flat washer (D), and split washer (E) then tighten with Allen wrench (F), as shown below.

Congratulations!
Your bed is now ready for use.
To ensure lasting safety, we recommend that you periodically check that all screws are tight and all parts are secure.
