- Page 1 BOX BLADE TRACTOR ATTACHMENT 426010, 426015, 426110, 426115, 426120 Operator’s Manual Read the Operator’s Manual entirely. When you see this symbol, the subsequent instructions and warnings are serious follow without exception. Your life and the lives of others depend on it!
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION THESE ARE STANDARD PRACTICES THAT MAY NOT APPLY TO THE PRODUCTS DESCRIBED IN THIS MANUAL. SAFETY AT ALL TIMES Thoroughly read and understand the instructions given in this manual before operation. Refer to the “Safety Label” section, read all instructions noted on them. Do not allow anyone to operate this equipment who has not thoroughly read and comprehended this manual. - Page 3 BE AWARE OF SAFETY ALERT WORDS DANGER: Indicates an imminently hazardous situation which, if not avoids, will result in death or serious injury. This signal word is limited to the most extreme situations, typically for machine components that, for functional purpose, cannot be guarded. WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury, and includes hazards that are exposed when grads are removed.
- Page 4 Remove all tools and unused parts from implement before operation. • Prepare for emergencies Be prepared if a fire starts. • Keep a first aid kit and fire extinguisher handy. • Keep emergency numbers for doctor, ambulance, hospital, and fire department near phone. •...
-
Page 5: Safety Labels
2. Replace all damaged or missing labels. To order new labels go to your nearest dealer. 3. Some new equipment installed during repair requires safety labels to be affixed to the replaced component as specified by Blue Diamond. When ordering new components make sure the correct safety labels are included in the request. -
Page 6: Section 1: Assembly And Set-Up
INTRODUCTION APPLICATION Box Blades are designed for Category 1 - three-point hitch or Quick-Hitch System mounting. These Fixed Bar Box blades are ideal for ripping, leveling, finish grading, and backfilling applications at feedlots, outdoor arenas, building sites, and maintenance operations on farm and ranch lanes or roadways. -
Page 7: Section 2: Adjustments
SECTION 2: ADJUSTMENTS SHANK SETTINGS Shank settings are based on the vertical distance from the bottom edge of Box Blade side plates to the bottom of the shank tips. CAUTION Adjust the shank setting after the scraper has been properly attached to a tractor and supported with blocks to prevent injury! CAUTION Keep feet clear when lowering the shanks! - Page 8 Make sure all safety labels are in their proper location and in good condition before • operation. Never work under the unit without properly blocking the unit up. • Before working the soil contact your local utility services, so that they mark the location •...
-
Page 9: Section 4: Maintenance
Section 4: MAINTENANCE MAINTENANCE Proper servicing and adjustment are the key to the long life of any farm implement. With careful and systematic inspection, you can avoid costly maintenance, time, and repair. GENERAL After using your scraper for several hours, check all bolts to be sure they are tight. •... -
Page 10: Section 5: Appendix
SECTION 5: APPENDIX BOLT TORQUE The table shown below give correct torque values for various bolts and caps crews. Tighten all bolts to the torques specified unless otherwise noted. Check tightness of bolts periodically, using bolt torque chart as a guide. Replace hardware with the same strength bolt. ENGLISH TORQUE SPECIFICATIONS METRIC TORQUE SPECIFICATIONS Torque figures indicated above are valid for non-greased or non-oiled threads and heads... - Page 11 Item Description Frame Standard Bolt & Locknut Kit 3/4” x 4” – for A-Frame Spacer 2 1/4” – for A-Frame Lift Pin CAT-I – Handle Type Lynch Pin 3/8” Box Shank with Point Pin, L Type – for Box Shank Cutting Edge 3/8”...
- Page 12 Item Description Frame Standard A-Frame, Heavy Duty 1/2” x 4” x 26” Bolt & Locknut Kit 5/8” x 4 1/2” – for Top A-Frame Bolt & Locknut Kit 5/8” x 2” – for Bottom A-Frame Spacer 2” – for A-Frame Back Brace 1/2”...
- Page 13 Blue Diamond, its insurers, employees, officers, directors, associates, and agents from any and all claims, demands, damages, rights of action, or causes of action, present or future, whether the same be known or unknown, anticipated, or unanticipated, resulting from or arising out of the use of said equipment.
-
Page 14: Manufacturer's Limited Warranty
ATTACHMENTS before work is performed. ® The BLUE DIAMOND® PRODUCT SUPPORT TEAM will advise repairs and applicable parts exchanges. Tampering with the failed part may void the warranty. This warranty does not include freight or delivery charges incurred when returning machinery for servicing. Dealer mileage, service calls, and pickup/delivery charges are the customers’... - Page 15 QUALITY | DEPENDABILITY | INTEGRITY Blue Diamond® Attachments 4512 Anderson Road, Knoxville, TN 37918 888-376-7027...
