FB4C(S,Q)L
NOTE: Read the entire instruction manual before starting the

installation.

TABLE OF CONTENTS

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

SAFETY CONSIDERATIONS

Improper installation, adjustment, alteration, service, maintenance,
or use can cause explosion, fire, electrical shock, or other
conditions which may cause death, personal injury or property
damage. Consult a qualified installer, service agency, or your
distributor or branch for information or assistance. The qualified
installer or agency must use factory- authorized kits or accessories
when modifying this product. Refer to the individual instructions
packaged with kits or accessories when installing.
Follow all local safety codes. Wear safety glasses, protective
clothing and work gloves. Have a fire extinguisher available. Read
these instructions thoroughly and follow all warnings or cautions
included in literature and attached to the unit. Consult local
building codes and the current editions of the National Electrical
Code (NEC) and NFPA 70.
Recognize safety information. This is the safety- alert symbol
When you see this symbol on the unit and in instruction manuals,
be alert to the potential for personal injury.
Understand the signal words DANGER, WARNING, and
CAUTION. These words are used with the safety- alert symbol.
DANGER identifies the most serious hazards which will result in
severe personal injury or death. WARNING signifies hazards
which could result in personal injury or death. CAUTION is used
Installation Instructions
. . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
FOR R- 410A REFRIGERANT
to identify unsafe practices which may result in minor personal
injury or product and property damage. NOTE is used to highlight
suggestions which will result in enhanced installation, reliability, or
operation.
PAGE
!
1
1
ELECTRICAL OPERATION HAZARD
1
Failure to follow this warning could result in personal injury
1
or death.
2
Before installing or servicing unit, always turn off all power to
unit. There may be more than one disconnect switch. Turn off
3
accessory heater power if applicable. Lock out and tag switch
4
with a suitable warning label.
. .
6
6
!
6
7
CUT HAZARD
7
Failure to follow this caution may result in personal injury.
8
Sheet metal parts may have sharp edges or burrs. Use care and
8
wear appropriate protective clothing and gloves when
9
handling parts.
10
11
FB4C models are R- 410A Fan Coils designed for installation
flexibility. These units are designed to meet the low air leak
requirements currently in effect.
A TXV is used on FB4C(S,Q)L. This valve is a bleed- through
type and adjustable (if necessary). All FB4C fan coils use a
multi- tap ECM motor for efficiency. These units have been
designed for upflow, downflow (kit required), and horizontal
orientations.
These units require a field supplied air filter, and are designed
specifically for R- 410A refrigerant 50 Hz air conditioners. These
units are available for systems of 18,000 through 60,000 BTUh
nominal cooling capacity.See Product Data literature for all
available accessory kits.

Step 1 - Check Equipment

.
Unpack unit and move to final location. Remove carton taking care
not to damage unit. Inspect equipment for damage prior to
installation. File claim with shipping company if shipment is
damaged or incomplete.
FAN COIL UNITS
SIZES 018 TO 060
WARNING
CAUTION

INTRODUCTION

INSTALLATION
50 Hz

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FB4CL and is the answer not in the manual?

Questions and answers

Summary of Contents for Carrier FB4CL

  • Page 1: Table Of Contents

    Библиотека СОК  FB4C(S,Q)L FAN COIL UNITS FOR R- 410A REFRIGERANT SIZES 018 TO 060 50 Hz Installation Instructions NOTE: Read the entire instruction manual before starting the to identify unsafe practices which may result in minor personal injury or product and property damage. NOTE is used to highlight installation.
  • Page 2: Step 2 - Mount Unit

    Locate unit rating plate which contains proper installation For slope fan coils, use kit Part No. KFADC0201SLP. For A- coils, information. Check rating plate to be sure unit matches job use kit Part No. KFADC0401ACL. Use fireproof resilient gasket, specifications. 1/8 to 1/4- in (3 to 6 mm) thick, between duct, unit, and floor.
  • Page 3: Step 3 - Air Ducts

    2. Remove coil mounting screw securing coil assembly to right side casing flange. 3. Remove coil assembly. 4. Lay fan coil unit on its right side and reinstall coil assembly with condensate pan down. (See Fig. 4.) 5. Attach coil to casing flange using coil mounting screw pre- viously removed.
  • Page 4: Step 4 - Electrical Connections

    Ductwork Acoustical Treatment B. 24- v Control System Connection To Unit Metal duct systems that do not have a 90_ elbow and 10- ft (3m) of main duct to first branch takeoff may require internal acoustical Wire low voltage in accordance with wiring label on the blower. insulation lining.
  • Page 5 terminal on transformer and connect it to the 208v terminal. (See FAN COIL HEAT PUMP THERMOSTAT (CONTROL) Fig. 13.) (CONTROL) SECONDARY ODTS PRIMARY A94061 A05182 Fig. 10 - Wiring Layout Heat Pump Unit Fig. 13 - Transformer Connections (Cooling and 2- Stage Heat with Heater Staging 1 Outdoor Thermostat) The controls are factory circuited for single- stage operation.
  • Page 6: Step 5 - Refrigerant Tubing Connection And Evacuation

    Speed-taps 1, 2, and 3 have a 90 second blower off time delay Units have sweat suction and liquid tube connections. Make pre-programmed into the motor. Speed-tap 4 is used for electric suction tube connection first. heat only (with 0 second blower time delay) and the WHITE wire 1.
  • Page 7: Step 8 - Accessories

    CAUTION CAUTION UNIT OR PROPERTY DAMAGE HAZARD PROPERTY DAMAGE HAZARD Failure to follow this caution may result in product or Failure to follow this caution may result in product or property damage. property damage. The conversion of the fan coil to downflow requires special Shallow running traps are inadequate and DO NOT allow procedures for the condensate drains on both A- coil and proper condensate drainage.
  • Page 8: Start- Up Procedures

    START- UP PROCEDURES B. Cooling Mode Thermostat energizes R to G, R to Y, and R to O (heat pump only). Refer to outdoor unit Installation Instructions for system start- up G energizes fan relay on PCB which completes circuit to indoor instructions and refrigerant charging method details.
  • Page 9: Airflow Performance Tables

    AIRFLOW PERFORMANCE TABLES Table 1 – FB4C Airflow Performance (CFM) MODEL & SIZE BLOWER SPEED 0.10 0.20 0.30 0.40 0.50 0.60 Tap 5 Tap 4 FB4C 018 Tap 3 Tap 2 Tap 1 Tap 5 Tap 4 FB4C 024 Tap 3 Tap 2 Tap 1 Tap 5...
  • Page 11: Dimensional Drawings

    Fig. 20 - FB4CSL - English Measurements...
  • Page 12 Fig. 21 - FB4CSL - English Measurements...
  • Page 13 Fig. 22 - FB4CSL - Metric Measurements...
  • Page 14 Fig. 23 - FB4CSL - Metric Measurements...
  • Page 15 Fig. 24 - FB4CQL - English Measurements...
  • Page 16 Fig. 25 - FB4CQL - English Measurements...
  • Page 17 Fig. 26 - FB4CQL - Metric Measurements...
  • Page 18 Fig. 27 - FB4CQL - Metric Measurements...
  • Page 19 R- 410A QUICK REFERENCE GUIDE S Observe all warnings, cautions, and bold text. S R- 410A refrigerant operates at 50- 70 percent higher pressures than R- 22. Be sure that servicing equipment and replacement components are designed to operate with R- 410A refrigerant. R- 410A refrigerant cylinders are rose colored.

Table of Contents
