Summary of Contents for Koehler K17400
- Page 1 K17400, K17490 Abel Closed Cup Flash Point Tester service | innovation | technology REV K-A...
- Page 2 K17400, K17490 Abel Closed Cup Flash Point Tester Operation and Instruction Manual - ii -...
- Page 3 ONFORMANCE Manual Abel Closed Cup Flash Point Tester K17400, K17490 This certificate verifies that part numbers K17400, K17490, Manual Abel Closed Cup Flash Point Tester, was manufactured in conformance with the applicable standards set forth in this certification. Specifications: IP 170...
- Page 4 K17400, K17490 Abel Closed Cup Flash Point Tester Operation and Instruction Manual - iv -...
- Page 5 Responsibility for Registration and Annual Reporting: Koehler will not sell directly to end users in the EU and so has no responsibility to register within each EU state and to make annual reports. Koehler declares that this responsibility is born by the importer who is the first level of the distribution chain and is subject to producer responsibility.
- Page 6 Recycling is free of charge. Shipping is the responsibility of the end users. Whether shipping to a distributor or to Koehler directly, safe, properly declared, and labeled packaging and shipping expenses are the sole responsibility of the end user.
-
Page 7: Table Of Contents
K17400, K17490 Abel Closed Cup Flash Point Tester Operation and Instruction Manual Table of Contents 1. Introduction 1.1. Koehler’s Commitment to Our Customers 1.2. Recommended Resources and Publications 1.3. Instrument Specifications 2. Safety Information and Warnings 3. Getting Started 3.1. Packing List 3.2. -
Page 8: Introduction
Providing quality testing instrumentation and technical support services for research and testing laboratories has been our specialty for almost 100 years. At Koehler, the primary focus of our business is providing you with the full support of your laboratory testing needs. Our products are backed by our staff of technically knowledgeable, trained specialists who are experienced in both petroleum products testing and instrument service to better understand your requirements and provide you with the best solutions. -
Page 9: Instrument Specifications
K17400, K17490 Abel Closed Cup Flash Point Tester Operation and Instruction Manual 1.3. Instrument Specifications Models: K17400 K17490 Electrical Requirements: 115V 60Hz 220-240V 50/60 Hz Dimensions 10 x 17.5 x 11.5 (wxdxh,in.(cm)): (25.4 x 44.5 x 29.2) Net Weight: 25 lbs (11.34 kg) Gross Weight: 35 lbs (15.88 kg) -
Page 10: Unpacking
Equipment Placement. Make sure the instrument is placed on a firm, level table in an area with adequate ventilation or in a hood. The unit may be leveled by making minor turning adjustments to the feet located at the base of the unit. Please note that Koehler does not supply a level with this equipment. -
Page 11: Descriptions
K17400, K17490 Abel Closed Cup Flash Point Tester Operation and Instruction Manual Gas Supply. Connect the gas inlet to a regulated low pressure gas supply (0.5 to 1.0 psi). Use only propane, LPG, or natural gas. Do not use direct unregulated pressure from an LPG tank. - Page 12 K17400, K17490 Abel Closed Cup Flash Point Tester Operation and Instruction Manual 4. Flame Control ON/OFF Switch. Controls cut off valve from gas line. Turn switch to OFF position when Flame Applicator is not in use to ensure gas is not flowing.
-
Page 13: Operation
K17400, K17490 Abel Closed Cup Flash Point Tester Operation and Instruction Manual 5. Operation 5.1. Test Procedure Be sure all tests be performed in a room free of excessive drafts. The room or compartment should be darkened sufficiently to allow the flash to be readily seen. -
Page 14: Safety Features
NOTE: The application of the test flame can cause a blue halo or an enlarged flame prior to the actual flash point. This is not a flash point and shall be ignored. 6. Safety Features The Koehler K174XX Abel Closed Cup Flash Point Tester is equipped with several safety and protection features, which are described in the following sections. 6.1. Over-Power Protection The Koehler K174XX Abel Closed Cup Flash Point Tester is equipped with Over-Power Protection circuitry, which prevents the unit from unsafe electrical conditions. -
Page 15: Replacement Parts
K17400, K17490 Abel Closed Cup Flash Point Tester Operation and Instruction Manual • Do Not clean bath exterior with organic chemicals such as Acetone, Toluene, Hexane, etc. • For more difficult cleaning of finished surfaces, a dilute solution or isopropanol in water may be used. -
Page 16: Wiring Diagram
K17400, K17490 Abel Closed Cup Flash Point Tester Operation and Instruction Manual 8. Wiring Diagram - 10 -... -
Page 17: Troubleshooting
We, at Koehler, would like to thank you for your equipment purchase, which is protected by the following warranty. If within one (1) year from the date of receipt, but no longer than fifteen (15) months from the date of shipment, Koehler equipment fails to perform properly because of defects in materials or workmanship, Koehler Instrument Company, Inc. -
Page 18: Returned Goods Policy
13. Returned Goods Policy To return products for credit or replacement, please contact Koehler Customer Service with your purchase order number, our packing list/invoice number, the item(s) to be returned and the reason for the return. You will be issued a Returned Authorization (RA) number, which must be prominently displayed on the shipping container when you return the material to our plant. - Page 19 K17400, K17490 Abel Closed Cup Flash Point Tester Operation and Instruction Manual Notes - 13 -...
- Page 20 K17400, K17490 Abel Closed Cup Flash Point Tester Operation and Instruction Manual Notes - 14 -...
