- Page 1 Indoor Landscape IR Touch Digital Kiosk USER MANUAL SKU: DK043TLB2 43inch Indoor Landscape IR Touch Digital Kiosk - Black SKU: DK043TLW2 43inch Indoor Landscape IR Touch Digital Kiosk - White FCC ID: 2ASCB-DK4311KSK This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 2 Thank you for purchasing this product from Displays2go. It’s our mission to help you connect with the world and build your brand with products that are personalized to your needs. Your product has been manufactured with great care using only the finest quality materials and expert workmanship.
-
Page 3: Table Of Contents
TA B L E O F CONTENTS Before Use Safety Warnings and Precautions Packing List Interface Diagram Assembly Operation Power On/Off Remote Control Navigation Android 11 Quick Start Guide DiViEX Reference Technical Specifications Cleaning and Maintenance Troubleshooting Guide Names and Contents of Toxic and Hazardous Substances or Elements in the Product FCC Compliance Notice... -
Page 4: Before Use
B E F O R E U S E Safety Warnings and Precautions Thank you for purchasing the high-performance multi-functional LED backlight Digital Signage from Displays2Go. We have considered the factors to ensure personal safety in product design and have tested rigorously at the factory. - Page 5 WARNING • Cut off the power supply before connecting or disconnecting any cables. • Do not place the Digital Signage on any instable positions, or else it may be damaged or cause fire. • Do not place the Digital Signage in the positions such as: •...
- Page 6 Manual may be slightly different from actual operation, and the latter is applicable. Contact Displays2go if you have questions about the operation, debugging and connection of the unit, if the unit doesn’t work normally, please cut off the power immediately and consult the dealer. The unit is class-A product, which may cause radio interference in living environment.
-
Page 7: Packing List
Power Cord Touch Pens Wi-Fi Antenna Trunking Remote Control Interface Diagram Name Quantity Socket Switch Type-C TF-CARD 3.5mm headphone connector WIFI If you have any questions regarding our products, please visit us at www.displays2go.com or contact Displays2go customer service at 844-221-3388. -
Page 8: Assembly
Assembly NOTE: Two people required for safe assembly of product. Always unplug power cord before installing or disassembling the unit! UNPACKING Open the top cover. Have two people carefully remove the device from the packaging and place it aside carefully to avoid scratches. Take out the cord management channel and tear off the Paste the channel on one of the leg of the table, leaving surface coating of the bottom adhesive on the back. -
Page 9: Operation
OPERATION Power On/Off NOTE : We recommend using a surge protector or power strip with internal circuit breaker to prevent potential damages to the product. • Power on by inserting the power cord into unit and connecting to outlet. Flip I/O switch to “I” position. To turn the screen on or off, press the •... -
Page 10: Navigation
Navigation Once turned on, the unit automatically displays the home screen, which includes the navigation bar and the App Drawer. NOTE: The Navigation bar can be minimized. To restore the navigation bar, go into Display settings and enable Display Navigation. App Drawer Background Applications Back... -
Page 11: Diviex
DiViEX The DiViEX Slideshow App comes pre-installed on this digital product for convenient content management. There are 2 methods for uploading media: saving media files to internal storage, or creating a specific folder on a USB, then inserting into unit. After, open the app to launch a slideshow or adjust picture settings, add filters and stickers, queue music and more! UPLOAD MEDIA METHOD 1: PLAY MEDIA VIA INTERNAL STORAGE... -
Page 12: Playlist Settings
PLAYLIST SETTINGS Edit the overall playlist settings in the Settings tab. Once settings are adjusted, click PLAY or adjust further in the Edit or Music tab. Enable or disable automatic settings. A. AUTOMATIC SETTINGS Auto-Boot: Automatically launch DiViEX when unit is powered on Auto-Play: Automatically play slideshow when DiViEX opens B. - Page 13 EDIT Edit Tweak each photo individually in the tab. A. PHOTOS Images/Video thumbnails in sequential order. Drag to rearrange. B. EDIT TOOLS Crop, Add Text, Add Filter, Add Sticker, Add Frame This white bar shows tool options for each of the Edit tools. Choose aspect ratios C.
-
Page 14: Reference
R EFE R ENC E Technical Specifications LCD Size 43” Light Source LED backlight Resolution 1920*1080 (pixels) Brightness 400cd/m2 Contrast 1200: 1 Response 10ms PANEL Pixel Pitch 0.49 (H) * 0.49 (V) mm Refresh Rate 60Hz Viewing Angle 178° (H)/178° (V) Color Saturation Viewable Area 940.9 (H) * 529.3(V) mm... -
Page 15: Cleaning And Maintenance
App Installation Support download and installation FUNCTIONS Wi-Fi Frequency 5G, 2.4G Dual Band Wi-Fi Generation Wi-Fi 6 (Compatiable with Wi-Fi 5) Ethernet (RJ45) HDMI 3.5mm headphone INTERFACES Wi-Fi Type-C OTG Net Weight 90lbs (41kg) Gross Weight 126lbs (57kg) Unit Dimensions 41”x 22”x 45”... -
Page 16: Troubleshooting Guide
Troubleshooting Guide ISSUE PROBABLE CAUSE SOLUTION • Check that the unit is plugged into wall outlet. • Unit not plugged into wall • Confirm that the power cord is connected to outlet the terminal on the back of the unit. •... - Page 17 WORKING • Android board is defective • Contact Displays2go support. NOTE: Do not attempt to replace or repair circuitry yourself. Contact customer service to schedule a professional maintenance appointment. If all the potential solutions have been tested for a particular issue and problems have not been resolved, contact a customer service representative for guidance.
-
Page 18: Names And Contents Of Toxic And Hazardous
Names and Contents of Toxic and Hazardous Substances or Elements in the Product The table shows that the machine contains harmful substances inside. The data is provided by material suppliers and verified by the company according to the material type. Some materials contain harmful substances that can’t be replaced in present technology. -
Page 19: Fcc Statement
FCC Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
