User Manual
Model: DGBP3BL
Description: Floor Standing Literature Holder with LCD Screen
Note: Before using the product, please read the instructions carefully!
Do not attempt to disassemble this product. If the product does not work properly, please call our
Customer Service Department at 1-844-221-3393.
DISPLAYS2GO
Operating Instructions for Digital Signage
FCC ID: 2ASCB-DGBP3BLSCN
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
Any changes/modifications to this equipment not approved
by the party responsible for compliance could void the
user's authority to operate the equipment.
1
V20.07
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Displays2go DGBP3BL
Summary of Contents for Displays2go DGBP3BL
- Page 1 User Manual V20.07 Model: DGBP3BL Description: Floor Standing Literature Holder with LCD Screen FCC ID: 2ASCB-DGBP3BLSCN This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
-
Page 2: Table Of Contents
Slide Show APP Introduction…………………………………………………………………………………………………13 How to Upload Media Files ……………………………………………………………………………………………………13 How to Delete Media Files………………………………………………………………………………………………………18 Factory Reset……………………………………………………………………………………………………………………………20 Screen Rotate………..…………………………………………………………………………………………………………………20 Choose System Language…..…….………………………………………………………………………………………………21 Technical Specifications……………………………………………………………………………………………………………22 Troubleshooting……………………………………………………………….………………………………………………………24 Cleaning and Maintenance……………………………………………….………………………………………………………26 Names and Contents of Toxic and Hazardous Substances or Elements in the Product…….…………27 DISPLAYS2GO... -
Page 3: Features
Thank you for purchasing the high-performance multi-functional LED backlight Digital Signage from Displays2go. We have considered the factors to ensure personal safety in product design and have tested rigorously at the factory. However, improper installation and use may result in electric shock and fire. - Page 4 Do not use the Digital Signage in stormy weather, especially when there is lightning; instead, please disconnect the power and antenna plugs to avoid lightning strike. Do not disassemble the Digital Signage without permission, or else it may cause electric shock or fire. Please ask qualified technician for repair. DISPLAYS2GO...
- Page 5 The unit is class-A product, which may cause radio interference in living environment. In this case, please take feasible measures, and use power plug as the disconnection device. DISPLAYS2GO...
-
Page 6: Assembly And Connection
Assembly and Connection Packing List Picture Parts LCD Screen Mounting bar Optional Literature Shelf Pole Base Weight Remote control M6x12 M6x30 M10x30 Wrench User menu DISPLAYS2GO... -
Page 7: Description Of Parts
6 - Straight pole 7 - Power Cable 8 – Base Interfaces: 9 – USB 10 – USB 11 – HDMI 12 - RJ45 13 - ON/OFF 14 - Power Port CAUTION: Disconnect the power plug before assembling or disassembling the unit! DISPLAYS2GO... -
Page 8: Steps For Assembly
Package dimensions (W*D*H) 2020x100x100mm Material Steel Color Black Gross weight 10kgs Unit dimensions (Dia.) Dia.450mm Base Package dimensions (W*D*H) 480x480x70mm Material Steel Color Black Gross weight 7kgs Unit dimensions(W*D*H) 528x325x48mm LCD Screen Package dimensions (W*D*H) 650x450x135mm Material Steel, plastic Color Black DISPLAYS2GO... -
Page 9: Remote Control
To move the cursor down NOTE: Press the SETUP button in the main interface to call out the OSD menu. After exiting the playback mode by pressing the STOP button, the playback will start according to the schedule next time. DISPLAYS2GO... -
Page 10: Description Of Basic Operation
When powered on, enter “System Assistant” and press the “ ” button on the remote control, and the Digital Signage enters standby state. About Launch Desktop Description of Desktop Icons Icon Function Main applications Back Home page Background applications Sound - Sound + DISPLAYS2GO... -
Page 11: Description Of Wallpaper Switch
” in the Home page to enter the “APPS” menu interface (Fig. 2); 2. Click the “Explorer” icon in the “APPS” menu interface (Fig. 2) and enter “Explorer” menu (Fig. 3); 3. Click options in the “Explorer” menu to read the files from different devices. Fig. 1 Fig. 2 Fig. 3 DISPLAYS2GO... -
Page 12: Local Settings
Description of Settings Interface (shown on the right) Icon Function WIFI switch Data usage Bluetooth Sound & notification Battery saver HDMI Display Storage Apps Screenshot Setting Location Accounts Backup & reset Security Language & input Date & time Printing Accessibility About device DISPLAYS2GO... -
Page 13: Status Of Menu Bar
3. At the display setting menu unselect the display navigation check box Fig. 1 Fig. 2 Fig. 3 Slide Show APP Introduction How to Upload Media Files: Step 1: Open the Android launcher screen and click the explorer app DISPLAYS2GO... - Page 14 Step 2: Go to the USB storage menu click the USB storage button Step 3: At the USB storage menu select Multi and then highlight the media files which you want to copy to the media folder. Click the Editor button, the pop menu will show then click the Copy DISPLAYS2GO...
- Page 15 Step 4: Click HOME button and go to the NAND FLASH menu. Select MediaFolder and then open the Images Folder. DISPLAYS2GO...
- Page 16 Step 5: At the images folder click the edit button at the top of the screen, the pop menu will show. Then click the Paste command button. The files will be copied to the images folder. Step 6: Exit the Explorer app and go to the launcher screen. Run the Slide Show app to display the media files DISPLAYS2GO...
- Page 17 Step 7: Select the time you would like each picture to be on the screen for by dragging the bar to the desired time. Select how you would like the images to display. Select the desired transition effect between pictures. Step 8: Select Play and your slide show will begin playing DISPLAYS2GO...
-
Page 18: How To Delete Media Files
How to Delete the Media Files: Step 1: Open the Android launcher screen and click the explorer app Step 2: Click home button and go to the NAND FLASH menu you will see the MediaFolder open it DISPLAYS2GO... - Page 19 Step 3: At the Image or Video folder select the media files which you want to delete. Then click the edit button at the top of the screen, the pop menu will show. Then click the Delete command button and the files will be deleted. DISPLAYS2GO...
-
Page 20: Factory Reset
” in the Home page to enter the “APPS” menu interface (Fig. 1) 2. Click “System aide” into Fig. 2 3. Choose the degree you would like to Rotate screen, then click “Confirm”, after the restart, the screen will be rotated (Fig. 3) Fig. 1 Fig. 2 Fig. 3 DISPLAYS2GO... -
Page 21: Choose System Language
Choose System Language: 1. Get into Settings, then click “Language & input” (Fig. 1) 2. Click “Language”, then you can choose the system language accordingly (Fig. 2) Fig. 1 Fig. 2 Fig. 3 DISPLAYS2GO... -
Page 22: Technical Specifications
Environment Storage humidity 5~90% RH Non-condensing Operating humidity 5~90% RH Non-condensing Maximum operating time (hrs/day) 18 hours Operating system Android 7.1 Processor RK3288, quad-core Functions Built-in memory Decoding resolution 4K H264 Playback mode Support loop, inter-cut, timer, shim, etc. DISPLAYS2GO... - Page 23 Schedule power on/off System update USB compatible App installation Support download and installation Ethernet (RJ45) HDMI I/O interfaces Headset USB 2.0 Net weight 528x325x48mm Unit dimensions (W*D*H) 650x450x135mm LCD Screen Package dimensions (W*D*H) Steel/Plastic Shell material Shell color Black Language English DISPLAYS2GO...
-
Page 24: Troubleshooting
Stand within 1 foot of the front of the unit and point the remote directly at the sensor (green dot) ❖ If all of the above have been checked and the issue is not resolved, contact a customer service representative. DISPLAYS2GO... - Page 25 □ Having problems Did you purchase the If you purchased DisplayIt!Xpress software with installing DisplayIt!Xpress software from from Displays2go or from Best Wave directly, software or getting Displays2go? please contact Best Wave at ➢ content to play Did the customer purchase or support@bestwave.
-
Page 26: Cleaning And Maintenance
3. Don't place the product under direct sunlight which may shorten the service life of the screen. 4. Clean screen and product by using a glass cleaner. 5. If the product will not be used for a long time, pull out the power cord to prevent the internal short circuit or other potential dangers. DISPLAYS2GO... -
Page 27: Names And Contents Of Toxic And Hazardous Substances Or Elements In The Product
To protect the earth, if you do not need this product or its service life expires, please abide by your local Waste Electrical and Electronic Products Recycling and Disposal Regulations or send it to qualified local manufacture for recycling. This Manual is for reference only and is subject to change without prior notice. DISPLAYS2GO...
