60" DVLED
Outdoor
Portable
Digital Signage
with Cover
U S E R M A N U A L
SKU: DW060VBC
FCC ID: 2ASCB- DW060VBC
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Any changes/modifications to this equipment not approved by the party responsible for compliance could void the user's
authority to operate the equipment.
V1.2
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Displays2go DW060VBC
Summary of Contents for Displays2go DW060VBC
- Page 1 U S E R M A N U A L SKU: DW060VBC V1.2 FCC ID: 2ASCB- DW060VBC This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 2 Thank you for purchasing this product from Displays2go. It’s our mission to help you connect with the world and build your brand with products that are personalized to your needs. Your product has been manufactured with great care using only the finest quality materials and expert workmanship.
-
Page 3: Table Of Contents
TA B L E O F C O N T E N TS Before Use Safety and Warnings Packing List Description of Parts Assembly Operation Power On/Off Displaying Content with ViPlex Express Create New Solution Publish Solution Unit Connection Methods Reference Technical Specifications Cleaning and Maintenance... -
Page 4: Before Use
B E F O R E U S E Safety Warnings and Precautions Thank you for purchasing the high-performance Digital Signage from Displays2Go. We have considered the factors to ensure personal safety in product design and have tested rigorously at the factory. However, improper installation and use may result in electric shock and fire. - Page 5 WARNING • Cut off the power supply before connecting or disconnecting any cables. • Do not place the Digital Signage on any instable positions, or else it may be damaged or cause fire. • Do not place the Digital Signage in the positions such as: •...
- Page 6 Manual may be slightly different from actual operation, and the latter is applicable. Contact Displays2go if you have questions about the operation, debugging and connection of the unit, if the unit doesn’t work normally, please cut off the power immediately and consult the dealer. The unit is class-A product, which may cause radio interference in living environment.
-
Page 7: Packing List
Description of Parts Description LED Screen Body Base Locking Caster Wheels Cooling Vents Handles Interface Panel Speakers Antenna Power Cord If you have any questions regarding our products, please visit us at www.displays2go.com or contact Displays2go customer service at 844-221-3388. -
Page 8: Assembly
Assembly NOTE: Three people required to safely assembly the product. Always unplug power cord before assembly or disassembly! 1. Lay pull-straps on a soft and non-abrasive surface, then gently lay down LED screen. 2. Attach LED screen and base using M8x20 screws and washers. 3. -
Page 9: Operation
O P E R AT I O N Power On/Off • Power on by inserting the power cord into unit and connecting to outlet. Turn screen on with I/O switch. • To turn the screen on or off, use I/O switch on unit. •... -
Page 10: Displaying Content With Viplex Express
Display Media with ViPlex Express To display content, you first need to create and publish a content playlist, known as a ‘solution’ in Viplex Express software. ViPlex Express is a program for creating, editing, and displaying content on your LED video wall. NOTE : The ViPlex software appearance may vary from the screenshots included in this manual. -
Page 11: Create New Solution 1
Log Into ViPlex Express 1. Open ViPlex Express application after powering the LED poster on. The IP addresses of all units appear listed in the Screen Management tab. Choose an available unit from the list, then click Connect. 2. Enter the username and password then click OK. Initial Username: admin Initial Password: 123456 Create New Solution... -
Page 12: Publish Solution
Publish Solution Publish your solution by clicking the green Publish icon. Once published, playlists can be shared to the unit via USB or network connection. Connect via PC Connect via Phone IP Address, Ethernet, or USB ViPlex Handy mobile app Create, edit, and publish playlists Display playlists only P U B L I S H V I A U S B... -
Page 13: Unit Connection Methods
Unit Connection Methods C O N N E C T W I R E L E SS LY 1. Open Wi-Fi settings on your PC and find the unit IP address. The unit’s IP address is “AP” followed by the product ID number, which can be found on the inside of the unit access door. -
Page 14: Reference
R E F E R E N C E Technical Specifications LED Size 160 x 320 (px) Light Source NationStar 1415 Resolution 320(W) x 512(H) Brightness ~4500nits Contrast 3000:1 Response 12ms PANEL Pixel Pitch P2.5 Refresh Rate >1920 Viewing Angle 140°/120°... -
Page 15: Cleaning And Maintenance
Ethernet (RJ45) HDMI Wi-Fi Type-C OTG IP Rating IP56 Net Weight ~185 lbs. (84 Kgs.) Gross Weight ~352lbs (160kgs) Unit Dimensions 36.8” x 34.7” x 70.9” (936x882x1802mm) STRUCTURE Screen Package Dimensions 77.5” x 44.5” x 21” (1967 x 1 131 x 540mm) Base Package Dimensions 43”... -
Page 16: Troubleshooting Guide
Do not attempt to replace or repair circuitry yourself. Contact customer service to schedule a professional maintenance appointment. If all the potential solutions have been tested for a particular issue and problems have not been resolved, contact a customer service representative for guidance. 844-221-3388 info@displays2go.com... -
Page 17: Names And Contents Of Toxic And Hazardous
Names and Contents of Toxic and Hazardous Substances or Elements in the Product The table shows that the machine contains harmful substances inside. The data is provided by material suppliers and verified by the company according to the material type. Some materials contain harmful substances that can’t be replaced in present technology. -
Page 18: Fcc Statement
FCC Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
