65INCH DIGITAL
TOUCH FLRSTND BLK
ANDROID 11 OS
USER MANUAL
SKU: DF065TLB
FCC ID: 2ASCB-DF6511SP
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Any changes/modifications to this equipment not approved by the party responsible for compliance could void the user's
authority to operate the equipment.
Advertisement
Related Manuals for Displays2go DF065TLB
Summary of Contents for Displays2go DF065TLB
- Page 1 TOUCH FLRSTND BLK ANDROID 11 OS USER MANUAL SKU: DF065TLB FCC ID: 2ASCB-DF6511SP This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 2 Thank you for purchasing this product from Displays2go. It’s our mission to help you connect with the world and build your brand with products that are personalized to your needs. Your product has been manufactured with great care using only the finest quality materials and expert workmanship.
-
Page 3: Table Of Contents
TA B L E O F CONTENTS Before Use Safety Warnings and Precautions Packing List Interface Diagram Assembly Operation Power On/Off Remote Control HDMI Connection Navigation Android 11 Quick Start Guide DiViEX Reference Technical Specifications Cleaning and Maintenance Troubleshooting Guide Names and Contents of Toxic and Hazardous Substances or Elements in the Product FCC Compliance Notice... -
Page 4: Before Use
B E F O R E U S E Safety Warnings and Precautions Thank you for purchasing the high-performance multi-functional LED backlight Digital Signage from Displays2Go. We have considered the factors to ensure personal safety in product design and have tested rigorously at the factory. - Page 5 WARNING Cut off the power supply before connecting or disconnecting any cables. • Do not place the Digital Signage on any instable positions, or else it may be damaged or cause fire. • Do not place the Digital Signage in the positions such as: •...
- Page 6 Manual may be slightly different from actual operation, and the latter is applicable. Contact Displays2go if you have questions about the operation, debugging and connection of the unit, if the unit doesn’t work normally, please cut off the power immediately and consult the dealer. The unit is class-A product, which may cause radio interference in living environment.
-
Page 7: Packing List
Cleaning Kit Towel and Glove Cross Screwdriver User Manual M6x12Cross head pad screw Touch Pen Interface Diagram Name Quantity HDMI Input Socket Switch If you have any questions regarding our products, please visit us at www.displays2go.com or contact Displays2go customer service at 844-221-3388. -
Page 8: Assembly
Assembly NOTE: Two people required for safe assembly of product. Always unplug power cord before installing or disassembling the unit! UNPACKING Open the top cover. Remove base from package Have 2 people carefully remove unit from the package. and carefully set aside. Set it down on the shipping box to avoid scratches. -
Page 9: Operation
OPERATION Power On/Off NOTE : We recommend using a surge protector or power strip with internal circuit breaker to prevent potential damages to the product. • Power on by inserting the power cord into unit and connecting to outlet. Flip I/O switch to “I” position. •... -
Page 10: Navigation
Navigation Once turned on, the unit automatically displays the home screen, which includes the navigation bar and the App Drawer. NOTE: The Navigation bar can be minimized. To restore the navigation bar, go into Display settings and enable Display Navigation. App Drawer Background Applications Back... -
Page 11: Supported File Formats
Our DiViEX Slideshow App comes pre-installed on this digital product to provide convenience for your business content management. Easily upload your videos and images to a USB and insert into the unit. Then, open the app to launch a slideshow or adjust picture settings, add filters and stickers, queue music and more! Add Media to USB 1. -
Page 12: Playlist Settings
PLAYLIST SETTINGS Settings PLAY Edit the overall playlist settings in the tab. Once settings are adjusted, click or adjust further in the Edit or Music tab. Enable or disable automatic settings. A. AUTOMATIC SETTINGS Auto-Boot: Automatically launch DiViEX when unit is powered on Auto-Play: Automatically play slideshow when DiViEX opens B. -
Page 13: Edit Tools
EDIT Edit Tweak each photo individually in the tab. A. PHOTOS Images/Video thumbnails in sequential order. Drag to rearrange. B. EDIT TOOLS Crop, Add Text, Add Filter, Add Sticker, Add Frame This white bar shows tool options for each of the Edit tools. Choose aspect ratios C. -
Page 14: Reference
R EFE R ENC E Technical Specifications LCD Size 65” Light Source LED backlight Resolution 3840*2160 (pixels) Brightness 500cd/m2 Contrast 1200: 1 Response 10ms PANEL Pixel Pitch 0.37 (H) * 0.37 (V) mm Refresh Rate 60Hz Viewing Angle 178° (H)/178° (V) Color Saturation Viewable Area 1428.5 (H) * 803.5(V) mm... -
Page 15: Cleaning And Maintenance
App Installation Support download and installation Ethernet (RJ45) HDMI 3.5mm headphone INTERFACES Wi-Fi Type-C OTG Net Weight 192lbs (87kg) Gross Weight 232lbs (105kg) Unit Dimensions 35”x 4.1”x 79” (900x105x2000mm) STRUCTURE Package Dimensions 40”x 11”x 82” (≈1020x280x2090mm) Shell Material Aluminum profile/sheet metal Shell Color Black/White LANGUAGE... -
Page 16: Troubleshooting Guide
Troubleshooting Guide ISSUE PROBABLE CAUSE SOLUTION • Check that the unit is plugged into wall outlet. • Unit not plugged into wall • Confirm that the power cord is connected to outlet the terminal on the back of the unit. •... - Page 17 WORKING • Android board is defective • Contact Displays2go support. NOTE: Do not attempt to replace or repair circuitry yourself. Contact customer service to schedule a professional maintenance appointment. If all the potential solutions have been tested for a particular issue and problems have not been resolved, contact a customer service representative for guidance.
-
Page 18: Names And Contents Of Toxic And Hazardous
Names and Contents of Toxic and Hazardous Substances or Elements in the Product The table shows that the machine contains harmful substances inside. The data is provided by material suppliers and verified by the company according to the material type. Some materials contain harmful substances that can’t be replaced in present technology. -
Page 19: Fcc Statement
FCC Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
