- Page 1 80V Cordless Snow Thrower (SNB402) 2605202 Owner’s Manual TOLL-FREE HELPLINE: 1-888-90WORKS (855.345.3934) www.GreenWorksTools.com Read all safety rules and instructions carefully before operating this tool.
-
Page 2: Table Of Contents
CONTENTS Contents ..........................2 Product specifications ......................2 Safety information ........................ 3 Symbols ..........................6 Know your snow thrower ...................... 8 Assembly ..........................9 Operation ........................... 15 Maintenance ........................19 Environmentally safe battery disposal ................23 Troubleshooting ......................... 24 Warranty ..........................25 Exploded View / Parts List .................... -
Page 3: Safety Information
SAFETY INFORMATION W A R N I N G Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire, and/or serious injuries. Save all warnings and instructions for future reference. The term “power tool”... - Page 4 SAFETY INFORMATION • Do not use on graveled surface unless the power tool is adjusted for such a surface in accordance with the operator’s manual. • Keep Children Away– All visitors should be kept a safe distance from work area. •...
-
Page 5: General Safety Rules
SAFETY INFORMATION GENERAL SAFETY RULES • Verify that the power tool is secure while transporting. • Store the power tool in a dry area that will prevent unauthorized use or damage. Keep out of the reach of children. • Keep handles dry, clean, and free of debris. Clean the power tool after each use. Refer to the Maintenance Section in this manual for more information. -
Page 6: Symbols
SYMBOLS Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. SYMBOL DESIGNATION/EXPLANATION Voltage Current Frequency (cycles per second) Watt Hour - Energy Storage Capacity Amp Hour - Current Capacity Direct current... - Page 7 SYMBOLS The following signal words and meanings are intended to explain the levels of risk associated with this product. SYMBOL SIGNAL MEANING DANGER Indicates an imminently hazardous situation, which, if not avoided, will result in death or serious injury. WARNING Indicates a potentially hazardous situation, which, if not avoided, could result in death or serious injury.
-
Page 8: Know Your Snow Thrower
KNOW YOUR SNOW THROWER Read this operator's manual and safety rules before operating your snow thrower. Compare the illustration in Figure 1 to your snow thrower in order to familiarize yourself with the location of various controls and adjustments. Save this manual for future reference. LED lights Handle bar Bail lever... -
Page 9: Assembly
ASSEMBLY INSTRUCTIONS PACKING LIST PART NAME FIGURE Snow thrower Upper chute control rod Lower chute control rod Middle handle Upper handle Chute deflector Bolts U Bolts Handle knobs Hitch pin Owner's Manual... - Page 10 ASSEMBLY INSTRUCTIONS UNPACKING • Carefully remove the product and any accessories from the box. Make sure that all items listed in the packing list are included. • Inspect the product carefully to make sure no breakage or damage occurred during shipping. •...
- Page 11 ASSEMBLY INSTRUCTIONS ASSEMBLING THE HANDLE (See Figure 2) • Align the holes on the middle handle (2) and the lower handle (3). Insert the bolts (4), and use the handle knobs (5) to tighten them. • Align the hole on the middle handle (2) and the upper handle (1). Insert the bolts (6) and tighten them with the handle knobs (7) provided.
- Page 12 ASSEMBLY INSTRUCTIONS ASSEMBLING THE DISCHARGE CHUTE (See Figure 3) Push the chute deflector (1) until the latching tabs (2) on both sides click into the slots (3) and the posts (4) on both sides click into the keyed holes (5). Fig.
- Page 13 ASSEMBLY INSTRUCTIONS INSTALLING THE CHUTE CONTROL ROD (See Figure 4) • Position the discharge chute (1) so that it faces forward. NOTE: Align the arrow (2) on the discharge chute with the arrow on the housing. • Align the holes (3) on the upper chute control rod (4) with the holes on the lower chute control rod (5).
- Page 14 ASSEMBLY INSTRUCTIONS TO INSTALL BATTERY PACK (See Figure 5) • Open the battery compartment cover (1). • Slide the battery (2) down to lock it into position. The battery is fully inserted into the snow thrower when you hear an audible "click". •...
-
Page 15: Operation
OPERATING INSTRUCTIONS POWERING ON AND OFF (See Figure 6) • To power on, first press the safety switch button (1). • While pressing the safety switch button with one hand, use your other hand to simultaneously pull the bail lever (2) toward you. Once the machine powers on, release the safety switch button and proceed with operation. - Page 16 OPERATING INSTRUCTIONS UTILIZING THE LED LIGHTS (See Figure 7) • To utilize the LED lights (1) for night time snow removal, press the safety switch button (2) and then pull the bail lever (3) toward you. • To turn off the LED lights, release the bail lever. NOTE: After you have finished using your snow thrower, remember to turn off the light switch.
- Page 17 OPERATING INSTRUCTIONS ADJUSTING THE DISCHARGE CHUTE AND CHUTE DEFLECTOR (See Figure 8) • To adjust the discharge chute, rotate the handle (1) on the chute control rod in the direction that you wish to direct the snow stream. • To adjust the chute deflector (and therefore the height of the snow stream), squeeze the trigger (2) and raise or lower the chute deflector.
-
Page 18: Operating Tips
OPERATING INSTRUCTIONS OPERATING TIPS W A R N I N G If the Snow Thrower hits a foreign object while it is in use, the object could be thrown in the direction of the operator or a bystander. Thrown objects could cause serious personal injury. Keep the area to be cleared free of all foreign objects that may be picked up and thrown by the impeller. -
Page 19: Maintenance
MAINTENANCE SERVICING Servicing should be performed by a qualified technician. Replacement parts for this snow thrower must be identical to the parts that they replace. If repairs are necessary, contact the toll-free helpline, at 1-855-345-3934. Note: Identify the left and right sides of the snow thrower when standing in the normal operating position. W A R N I N G If the battery pack is installed into the snow thrower, the snow thrower could start accidentally while the operator is performing maintenance on it, which could cause serious personal injury. - Page 20 MAINTENANCE COLD WEATHER OPERATION (See Figure 9) Lithium Ion batteries can be safely used from temperatures ranging from -17 degrees to 45 degrees Celsius. NOTE: Do not store or charge battery outside. Battery must be charged and stored indoors prior to use of the snow thrower. Unit may not start if its temperature is -17˚C or lower.
- Page 21 MAINTENANCE REPLACING THE SCRAPER (See Figure 10) The scraper is located at the bottom of the impeller housing. • Ensure that the battery is not installed in the tool. • Remove the screw (1) from each side plate that holds the scraper and 3 screws (2) from under the machine that secure the scraper to the machine.
- Page 22 MAINTENANCE REPLACING THE IMPELLER (See Figures 1-9) 3. Remove the 5 screws and 1. Remove the 5 screws and 2. Remove the nut. side wear pad that secure the side wear pad that secure the right side cover. left side cover. 5.
-
Page 23: Environmentally Safe Battery Disposal
ENVIRONMENTALLY SAFE BATTERY DISPOSAL The following toxic and corrosive materials are in the batteries used in this tool battery pack: Lithium-Ion, a toxic material. W A R N I N G Toxic materials must be disposed of in a specified manner in order to prevent contamination of the environment. -
Page 24: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Make sure the bolts are correctly installed through the handle bars. Check to see The handle is not in The bolts are not properly if the hand knobs are tight. Refer to position. seated. Assembling the Handle section in this manual. -
Page 25: Warranty
LIMITED FOUR-YEAR WARRANTY GREENWORKS™ hereby warranties this product, to the original purchaser with proof of purchase, for a period of four (4) years against defects in materials, parts or workmanship. GREENWORKS™, at its own discretion will repair or replace any and all parts found to be defective, through normal use, free of charge to the customer. -
Page 26: Exploded View / Parts List
EXPLODED VIEW / PARTS LIST ITEM NO. PART NO. DESCRIPTION 341041476 Left side cover 32205877 Screw 329051205 Belt 32206575AB Screw 341041214BF Front cover assembly 311021205A Rear cover assembly 361011205B Motor 332031205 Motor clamp 3410801 Wire clamp 3290135 Split pin 34103486-7 7"... - Page 27 EXPLODED VIEW / PARTS LIST ITEM NO. PART NO. DESCRIPTION 32226121 Screw 341021483 Bracket for the chute control rod 32222301A 333011483 Lower chute control rod 333032601 Upper chute control rod 311051205A Handle bar assembly 342011205 Rubber bushing 322011463 Hitch pin 3220898 Washer 341291179...
- Page 28 EXPLODED VIEW / PARTS LIST 5- 2 2 5- 1 2 5- 1 4 5- 1 1 5- 2 3 5- 1 3 5- 2 4 5- 1 0 5- 1 8 5- 1 7 5- 1 6 5- 9 5- 1 5 5- 2 5- 3...
- Page 29 EXPLODED VIEW / PARTS LIST 27-1 27-2 27-3 27-6 27- 1 7 27-4 27- 1 8 27-5 27-7 27-8 27-9 27- 1 2 27- 1 3 27- 1 0 27- 1 1 27- 1 6 27- 1 4 27- 1 5 ITEM NO.
- Page 30 Greenworks Tools PO Box 1238 Mooresville, NC 28115 TOLL-FREE HELPLINE: 1-888-90WORKS (855.345.3934) Rev: 00 (05-10-18)
