SAFETY INFORMATION FOLLOW THESE RULES WHILE OPERATING (THE POWER TOOL) W A R N I N G READ AND UNDERSTAND ALL INSTRUCTIONS. Failure to follow all instructions listed below may result in electric shock, fire, and/or serious personal injury. • Walk. Do not run. •...
Page 4
SAFETY INFORMATION • Do not use on graveled surface unless the power tool is adjusted for such a surface in accordance with the operator’s manual. • Keep Children Away– All visitors should be kept a safe distance from work area. •...
Page 5
CONTENTS SAFETY INFORMATION GENERAL SAFETY RULES • Verify that the power tool is secure while transporting. • Store the power tool in a dry area that will prevent unauthorized use or damage. Keep out of the reach of children. • Keep handles dry, clean, and free of debris. Clean the power tool after each use. Refer to the Maintenance Section in this manual for more information.
SYMBOLS Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. SYMBOL DESIGNATION/EXPLANATION Voltage Current Frequency (cycles per second) Watt Hour - Energy Storage Capacity Amp Hour - Current Capacity Direct current...
Page 7
SYMBOLS The following signal words and meanings are intended to explain the levels of risk associated with this product. SYMBOLS SIGNAL MEANING Indicates an imminently hazardous situation, which, if not avoided, DANGER will result in death or serious injury. Indicates a potentially hazardous situation, which, if not avoided, WARNING could result in death or serious injury.
KNOW YOUR SNOW SHOVEL Read this operator's manual and safety rules before operating your snow shovel. Compare the illustration in Figure 1 to your snow shovel in order to familiarize yourself with the location of various controls and adjustments. Save this manual for future reference. Battery compartment Auxiliary handle Lock knob...
ASSEMBLY INSTRUCTIONS PACKING LIST PART NAME FIGURE Snow shovel Auxiliary handle Owner's manual...
Page 10
ASSEMBLY INSTRUCTIONS UNPACKING • Carefully remove the product and any accessories from the box. Make sure that all items listed in the packing list are included. • Inspect the product carefully to make sure no breakage or damage occurred during shipping. •...
Page 11
ASSEMBLY INSTRUCTIONS CONNECTING THE SHAFTS (See Figures 2-3) • Align the pin on the handle shaft and the hole on the lower shaft. (Fig. 2) • Once the two shafts are secured, turn the lock knob clockwise until it is fully tightened. (Fig. 3) Handle shaft Lock knob Lower shaft...
Page 12
ASSEMBLY INSTRUCTIONS TO INSTALL BATTERY PACK (See Figure 4) • Slide the battery (1) down to lock it into position. The battery is fully inserted into the snow shovel when you hear an audible “click”. Fig. 4 Fig. 5 TO REMOVE BATTERY PACK (See Figure 5) •...
Page 13
CONTENTS ASSEMBLY INSTRUCTIONS ATTACHING THE AUXILIARY HANDLE (See Figure 6) • Press the auxiliary handle (1) onto the upper shaft so that the handle is angled toward the rear handle that allows for comfortable operation. • Slide the auxiliary handle over the metal ring (2) and ensure the metal ring fits between the slot on the auxiliary handle.
Page 14
OPERATING INSTRUCTIONS CONTENTS STARTING THE SNOW SHOVEL (See Figures 7-8) In order to avoid serious injury, the operator and unit must be in a stable position when starting the snow shovel. Follow this sequence exactly in order to start the snow shovel. •...
Page 15
OPERATING INSTRUCTIONS USING THE SNOW SHOVEL (See Figure 9) • Start the snow shovel by following the Starting Instructions. The depth and weight of the snow will determine the forward speed. • Push the snow shovel forward so that it rides on the scraper. scraper Fig.
MAINTENANCE REPLACING THE SCRAPER (See Figures 10-11) W A R N I N G IN ORDER TO AVOID SERIOUS PERSONAL INJURY, TURN THE SNOW SHOVEL OFF AND REMOVE BATTERY BEFORE PERFORMING ANY MAINTENANCE. Use only the manufacturer's original replacement parts. •...
Page 17
MAINTENANCE STORAGE • Allow the motor to cool down before storing. • Store the snow shovel in a locked location in order to prevent unauthorized use or damage. • Store the snow shovel in a dry, well-ventilated area. • Store the snow shovel out of the reach of children. CLEANING In order to avoid serious personal injury, turn the snow shovel off and remove battery before cleaning or servicing.
Page 18
MAINTENANCE TRANSPORTING THE SNOW SHOVEL (See Figure 12) • Allow the motor to cool down before transporting. • Secure the snow shovel while transporting. • When moving the snow shovel, grasp it by the top handle and auxiliary handle (Fig. 12) Fig.
Page 19
MAINTENANCE IMPELLOR REPLACEMENT screw Washer • Remove the right side • Pull the belt tensioner (idler • Remove the belt. cover by removing 6 arm) away from the drive screws. pulley. Be sure not to lose the washer and screw left. •...
Page 20
MAINTENANCE IMPELLOR REPLACEMENT • Replace and tighten the • Replace and tighten the • Replace and tighten the remaining nut to secure the remaining screws to secure remaining screws to secure left side plate assembly. the left side cover. the pulley assembly. •...
ENVIRONMENTALLY SAFE BATTERY DISPOSAL The following toxic and corrosive materials are in the batteries used in this tool battery pack: Lithium-Ion, a toxic material. W A R N I N G All toxic materials must be disposed of in a specified manner to prevent contamination of the environment.
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Charge the battery by following the The battery is not charged. procedures in the battery and charger manual. Press and hold the lock-out button, The lock-out button or trigger while holding the lock-out button, press switch were not used properly.
LIMITED FOUR-YEAR WARRANTY GREENWORKS™ hereby warranties this product, to the original purchaser with proof of purchase, for a period of four (4) years against defects in materials, parts or workmanship. GREENWORKS™, at its own discretion will repair or replace any and all parts found to be defective, through normal use, free of charge to the customer.
EXPLODED VIEW/PARTS LIST ITEM NO. PART NO. DESCRIPTION 311051484 Snow Shovel Main Body 311061484 Motor Assembly 329011468 Belt 341031468 Impeller 341041468 Scraper 362011482AB PCB Board 311041429 Auxiliary Handle Assembly 34116884-5 Knob...
Page 25
Greenworks Tools PO Box 1238 Mooresville, NC 28115 TOLL-FREE HELPLINE: 1(855)345-3934 Rev: 00 (07-04-17) Printed in China...
Page 26
Pala de nieve Inalámbrica de 12" 60V SS60L00 Manual Del Propietario LÍNEA GRATUITA LÍNEA DE AYUDA: 1(855)345-3934 www.GreenWorksTools.com Leer todas las normas de seguridad y las instrucciones cuidadosaantes de utilizar esta herramienta.
Page 27
CONTENIDOS Contenidos........................... 2 Especificaciones ........................2 Reglas de seguridad ......................3 Símbolos ..........................6 Diagrama y ubicación de piezas ..................8 Ensamblado ......................... 9 Funcionamiento ......................... 14 Mantenimiento ........................16 Eliminación de la batería que no daña el medio ambiente ..........21 Corrección De Problemas ....................
REGLAS DE SEGURIDAD LEA TODAS LAS INSTRUCC IONES ANTES DEL PRIMER USO (DEL APARATO) A D V E R T E N C I A LEA Y COMPRENDA TODAS LAS INSTRUCCIONES ANTES DE USAR ESTE PRODUCTO. El ncumplimiento de las instrucciones siguientes puede ser causa de descargas eléctricas, incendios y lesiones personales graves.
Page 29
REGLAS DE SEGURIDAD propulsor y antes de proceder a cualquier tipo de reparación, ajuste o comprobación. • No utilice la máquina en una superficie con grava, a menos que esté ajustada para este tipo de superficies según el manual del usuario. •...
Page 30
CONTENTS REGLAS DE SEGURIDAD REGLAS GENE RALES DE SEGURIDAD • Verifique que la herramienta eléctrica esté segura durante el traslado. • Almacene la herramienta eléctrica en un lugar seco para evitar el uso no autorizado o daños. Manténgala alejada del alcance de los niños. •...
SÍMBOLOS Algunos de los siguientes símbolos pueden ser usados en este producto. Obsérvelos y aprenda su signifi cado. Una correcta interpretación de estos símbolos le permitirá utilizar el producto mejor y de una forma más segura. SÍMBOLO DENOMINACIÓN/EXPLICACIÓN Voltaje Corriente Frecuencia (ciclos por segundo) Vatio/hora –...
Page 32
SÍMBOLOS Las siguientes palabras de señalización y sus significados tienen el objeto de explicar los niveles de riesgo relacionados con este producto. SÍMBOLO SEÑAL SIGNIFICADO Indica una situación peligrosa inminente, la cual, si no se evita, PELIGRO causará la muerte o lesiones serias. Indica una situación peligrosa posible, la cual, si no se evita, ADVERTENCIA podría causar la muerte o lesiones serias.
DIAGRAMA Y UBICACIÓN DE PIEZAS Lea el manual del operador y las normas de seguridad antes de manejar la pala de nieve. Compare la ilustración en Fig. 1 con la podadora para familiarizarse con la ubicación de los diferentes controles y ajustes. Guarde este manual para referencia futura. Compartimiento de batería Manija auxiliar...
INSTRUCCIONES DE ENSAMBLADO LISTA DE PIEZAS NOMBRE DE LAS FIGURA CDAD. PIEZAS Pala de nieve Manija auxiliar Manual...
Page 35
INSTRUCCIONES DE ENSAMBLADO DESEMPAQUETADO • Extraiga cuidadosamente de la caja la herramienta y los accesorios. Asegúrese de que estén presentes todos los artículos enumerados en la lista de empaquetado. • Inspeccione cuidadosamente la herramienta para asegurarse de que no haya sufrido ninguna rotura o daño durante el transporte.
Page 36
INSTRUCCIONES DE ENSAMBLADO CONECTAR LAS ASTAS (Consulte la figuras 2-3) • Alinee el perno del tubo de la empuñadura y el agujero del tubo inferior. (Fig. 2) • Gire la palanca de bloqueo hacia la derecha hasta que quede completamente apretada. (Fig. 3) Asta de asidero Perilla de la manija...
Page 37
INSTRUCCIONES DE ENSAMBLADO INSTALACIÓN DEL PAQUETE DE BATERÍAS (Consulte la figura 4) • Deslice la batería (1) hacia abajo para trabarla en su posición correcta. La batería está completamente insertada en el quitanieve cuando se escucha un “clic”. Fig. 4 Fig.
Page 38
CONTENTS INSTRUCCIONES DE ENSAMBLADO FIJACIÓN DEL MANGO DELANTERO (Vea la figura 6) • Presione el mango (1) delantero en el eje de la cabeza motriz de manera que el mango está inclinado hacia el mango trasero. • Deslice el mango auxiliar en la anilla metálica (2) y asegúrese de que la anilla encaja entre la ranura del mango auxiliar.
Page 39
CONTENTS INSTRUCCIONES DE USO CÓMO ARRANCAR LA PALA DE NIEVE (Consulte la figuras 7-8) Para evitar lesiones graves, el operador y la unidad deben estar en una posición estable al arrancar la pala de nieve. Siga exactamente la siguiente secuencia para arrancar la pala de nieve. •...
Page 40
INSTRUCCIONES DE USO CÓMO USAR LA PALA DE NIEVE (Consulte la figura 9) • Arranque la pala de nieve siguiendo las instrucciones de arranque. La velocidad hacia adelante se determina por la profundidad y peso de la nieve. • Empuje la pala de nieve hacia delante de manera que se apoye en el raspador. Raspador Fig.
MANTENIMIENTO CÓMO REEMPLAZAR EL RASPADOR (Consulte la figuras 10-11) A D V E R T E N C I A PARA EVITAR LESIONES PERSONALES GRAVES, APAGUE LA PALA Y RETIRE LA BATERÍA ANTES DE HACER EL MANTENIMIENTO. Use solamente repuestos originales del fabricante. •...
Page 42
MANTENIMIENTO ALMACENAMIENTO • Deje que el motor se enfríe antes de almacenarlo. • Almacene la pala de nieve en un lugar bajo llave para evitar el uso no autorizado y los daños. • Almacene la pala de nieve en un área seca y bien ventilada. •...
Page 43
MANTENIMIENTO CÓMO TRANSPORTAR EL PALA DE NIEVE (Consulte la figura 12) • Deje que el motor se enfríe antes de transportarlo. • Asegure la pala de nieve al transportarlo. • Para transportar la pala de nieve, sujétela por la empuñadura y por la empuñadura auxiliar. (Fig.
Page 44
MANTENIMIENTO CÓMO REEMPLAZAR EL IMPULSOR Tornillos Arandela • Retire la cubierta derecha • Tire del tensor de la correa • Retire la correa. desatornillando los 6 (brazo tensor) hacia fuera tornillos. del rodillo motriz. Asegúrese de no perder la arandela ni el tornillo izquierdo.
Page 45
MANTENIMIENTO CÓMO REEMPLAZAR EL IMPULSOR • Coloque y apriete la tuerca • Coloque y apriete los • Coloque y apriete los restante para ensamblar la tornillos restantes para tornillos restantes para placa izquierda. ensamblar la cubierta ensamblar el rodillo. izquierda. •...
Page 46
ELIMINACIÓN DE BATERÍAS SIN DAÑO PARA EL AMBIENTE Las baterías utilizadas en esta herramienta contienen los siguientes materiales tóxicos y corrosivos: Litio-ión, un material tóxico. A D V E R T E N C I A Todos los materiales tóxicos deben ser desechados de forma específica para evitar contaminar el medio ambiente.
Page 47
SOLUCIÓN DE PROBLEMAS PROBLEMA CAUSA POSIBLE SOLUCIÓN Cargue la batería siguiendo los La batería no tiene carga. procedimientos del manual de la batería y el cargador. El botón para bloqueo por Pulse y mantenga pulsado el botón desconexión o el interruptor de bloqueo.
GARANTÍA LIMITADA DE 4 AÑOS Por este medio y por un período de cuatro años GREENWORKS™ garantiza este producto contra defectos en materiales, piezas o mano de obra al comprador original que cuente con una prueba de compra. GREENWORKS™, a su sola discreción reparará o reemplazará, sin costo alguno para el cliente, cualquier pieza defectuosa, siempre y cuando se haya hecho uso normal de ella.
VISTA DESARROLLADA ARTÍCULO PARTE NO. DESCRIPCIÓN CDAD. 311051484 Cuerpo principal 311061484 Conjunto del motor 329011468 Correa 341031468 Impulsor 341041468 Raspador 362011482AB Placa PCB 311041429 Conjunto de la manija auxiliar 34116884-5 Bouton...
Page 50
Greenworks Tools PO Box 1238 Mooresville, NC 28115 LÍNEA DE AYUDA GRATUITA: 1(855)345-3934 Rev: 00 (07-04-17) Impreso en China...
