43" Digital Podium with LCD
Screen - Android 11 OS
U S E R M A N U A L
SKU: DE043NLB2
FCC ID: 2ASCB- DE043NLB2
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Any changes/modifications to this equipment not approved by the party responsible for compliance could void the user's
authority to operate the equipment.
V1.02
Advertisement
Table of Contents
Related Manuals for Displays2go DE043NLB2
Summary of Contents for Displays2go DE043NLB2
- Page 1 U S E R M A N U A L SKU: DE043NLB2 V1.02 FCC ID: 2ASCB- DE043NLB2 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 2 Thank you for purchasing this product from Displays2go. It’s our mission to help you connect with the world and build your brand with products that are personalized to your needs. Your product has been manufactured with great care using only the finest quality materials and expert workmanship.
-
Page 3: Before Use
B E F O R E U S E Safety Warnings and Precautions Thank you for purchasing the high-performance digital signage from Displays2go. We have considered the factors to ensure personal safety in product design and have tested rigorously at the factory. However, improper installation and use may result in electric shock and fire. - Page 4 WARNING • Cut off the power supply before connecting or disconnecting any cables. • Do not place the Digital Signage on any instable positions, or else it may be damaged or cause fire. • Do not place the Digital Signage in the positions such as: •...
-
Page 5: Packing List
Manual may be slightly different from actual operation, and the latter is applicable. Packing List Name Quantity Digital Podium Remote Control Power Cord User Manual If you have any questions regarding our products, please visit us at www.displays2go.com or contact Displays2go customer service at 844-221-3388. -
Page 6: Parts Description
Parts Description Description Description LCD Screen XLR Inputs Remote Sensor Interface Panel Rubber Pad Speakers, Heat Vent On/Off Switch Dual XLR Outputs Power Outlet INTERFACE DIAGRAM AC OUTLET HDMI INPUT USB 2.0 AUDIO OUTPUT TF PORT / SIM TYPE-C USB 3.0... -
Page 7: Operation
O P E R AT I O N Power On/Off • Start up by inserting the power cord into unit and connecting to outlet. Flip power switch to ON. • Power on or off, press the power button on the remote control. •... -
Page 8: Hdmi Connection
HDMI Connection 1. Connect PC or media player via HDMI port. 2. Open the HDMI In app (see next page for instructions on navigating applications). The HDMI IN HDMI input appears on screen. NOTE: Some media players may not be supported. To automatically display HDMI input upon device startup, open the HDMI Auto-boot app and use the toggle to enable auto-boot. -
Page 9: Bluetooth Connection
Settings Once turned on, the unit automatically displays the home screen, which includes the navigation bar and the App Drawer. NOTE: The navigation bar can be minimized. To restore the navigation Display Navigation. bar, go into Display settings and enable App Drawer Background Applications Back... - Page 10 DiViEX The DiViEX Slideshow App comes pre-installed on this digital product for convenient content management. There are 2 methods for uploading media: saving media files to internal storage, or creating a specific folder on a USB, then inserting into unit. After, open the app to launch a slideshow or adjust picture settings, add filters and stickers, queue music and more! UPLOAD MEDIA Supported File Formats...
-
Page 11: Playlist Settings
PLAYLIST SETTINGS Edit the overall playlist settings in the Settings tab. Once settings are adjusted, click PLAY or adjust further in the Edit or Music tab. Enable or disable automatic settings. A. AUTOMATIC SETTINGS Auto-Boot: Automatically launch DiViEX when unit is powered on Auto-Play: Automatically play slideshow when DiViEX opens B. -
Page 12: Edit Tools
EDIT Tweak each photo individually in the Edit tab. A. PHOTOS Images/Video thumbnails in sequential order. Drag to rearrange. B. EDIT TOOLS Crop, Add Text, Add Filter, Add Sticker, Add Frame This white bar shows tool options for each of the Edit tools. Choose aspect ratios C. -
Page 13: Technical Specifications
R E F E R E N C E Technical Specifications LCD Size 43” Light Source LED backlight Resolution 1920 x 1080 (pixels) Brightness 400 nits (Typ) Contrast 1200: 1 Response PANEL Pixel Pitch 163 (H) x 490 (V) mm Refresh Rate 50/60Hz Viewing Angle... -
Page 14: Cleaning And Maintenance
Bluetooth Frequency 2.402GHz~2.480GHz FUNCTIONS Wi-Fi Generation Wi-Fi 6 (Compatiable with Wi-Fi 5) Wi-Fi Frequency 5G, 2.4G Dual Band Wi-Fi Ethernet (RJ45) HDMI IN INTERFACES Headset 1x Audio Output Port 1x USB 2.0, 1x USB 3.0, 1x Type-C Net Weight 108 lbs (49kg) Gross Weight 138 lbs (63kg) Unit Dimensions... -
Page 15: Troubleshooting Guide
Troubleshooting Guide ISSUE PROBABLE CAUSE SOLUTION • Check that the unit is plugged into wall outlet. • Unit not plugged into wall • Confirm that the power cord is connected to outlet the terminal on the back of the unit. •... - Page 16 APPS NOT is functioning. WORKING • Android board is defective • Contact Displays2go support. NOTE: Do not attempt to replace or repair circuitry yourself. Contact customer service to schedule a professional maintenance appointment. If all the potential solutions have been tested for a particular issue and problems have not been resolved, contact a customer service representative for guidance.
-
Page 17: Toxic And Hazardous Substances Or Elements
Names and Contents of Toxic and Hazardous Substances or Elements in the Product The table shows that the machine contains harmful substances inside. The data is provided by material suppliers and verified by the company according to the material type. Some materials contain harmful substances that can’t be replaced in present technology. -
Page 18: Fcc Compliance Notice
FCC Compliance Notice Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
