INSTALLATION INSTRUCTIONS FOR INSTALLING A FORCED AIR KIT (BISFWK-1) AND THERMOSTAT KIT (HCTW)
FOR USE WITH WOOD-BURNING FIREPLACES LISTED IN TABLES 1 AND 2
BISFWK-1 KIT CONTENTS
1 ea. Blower (BISZY)
1 ea. Flex Adaptor (BISAF)
2 ea. Clamps
1 ea. Variable Speed Control (VRUW),
1 ea. Thermo-disc (VTU)
1 ea. Blower Flex Adaptor (BISAVF)
1 ea, Aluminum tape
1 ea. Instruction Sheet
HCTW KIT CONTENTS
1 ea. Thermostat
1 ea. Instruction Sheet
FORCED AIR STARTER KIT
Cat. No.
Model
Brentwood™ LV, Brentwood SP, Ladera™,
Villa Vista™, Montecito™, Montecito Estate™,
BISFWK-1
BISFWK-1
WRT4820WS, WCT4820WS, WRT3820WS,
WRT4826WH, WCT6820WS, WCT6840WS,
®
BIS
Ultima CF, BIS Ultima-1, BIS Nova,
BIS Panorama, BIS Tradition CE and BIS Tradition
Table 1
HEATING/COOLING THERMOSTAT - 120 V AC
Cat. No.
Model
Brentwood™ LV, Brentwood SP, Ladera™,
Villa Vista™, Montecito™, Montecito Estate™,
WRT4820WS, WCT4820WS, WRT3820WS,
HCTW
HCTW
WRT4826WH, WCT6820WS, WCT6840WS,
BIS
®
Ultima CF, BIS Ultima-1, BIS Nova,
BIS Panorama, BIS Tradition CE and BIS Tradition
Table 2
Where Used
Where Used
F123 REV. 5 12/2013
https://manual-hub.com/
P/N 506019-77
Rev. E, 12/2013
GENERAL INFORMATION
The forced air kit provides warm air distribution to another room. The
thermostat kit provides control of heating and cooling.
If you encounter any problems, need clarification of these instructions or
are not qualified to properly install this kit, contact your local distributor
or dealer.
Read this instruction sheet in its entirety before beginning the installation.
ALL WARNINGS AND PRECAUTIONS IN THE INSTALLATION AND
OPERATION MANUAL PROVIDED WITH THE APPLIANCE APPLY TO
THESE INSTRUCTIONS.
SHUT DOWN THE APPLIANCE AND ALLOW IT TO COMPLETELY COOL
BEFORE PROCEEDING.
Features of the forced air system
Installation in Another Room
• Allows for warm air distribution to another room.
• Can install up to 50 feet (15.2 m) of flexible pipe.
• Can provide warm air distribution to a basement, garage or attic.
• Possibility of controlling via a wall thermostat.
Components for the Connection Kit for Forced Air System
The starter kit is comprised of a variable speed blower (BISZY), an adap-
tor for flexible pipe (BISAF), blower to flexible pipe adaptor (BISAVF), a
variable speed control for the blower (VRUW) and a thermostatic control
(VTU). The following optional parts are also available: wall thermostat
with control box (HCTW) and a back draft damper (BISBD).
HEARTH PRODUCTS
KITS AND ACCESSORIES
FORCED AIR KIT
AND THERMOSTAT KIT
1
