ADRIATIC AWC
Installation - Commissioning - Maintenance
Content
Application area .................................................. 2
General....................................................................... 2
Contents ..................................................................... 2
Protective equipment .................................................. 2
Electrical safety ........................................................... 2
Handling ..................................................................... 2
Installation .................................................................. 2
Cleaning ..................................................................... 2
Cleaning of electrical components ............................. 2
Service/maintenance ................................................... 2
Environment and waste disposal ................................. 2
Product warranty ........................................................ 2
Dimensions ......................................................... 3
Weight ................................................................. 3
Installation .......................................................... 4
Suspended installation ................................................ 4
Secure design module ................................................. 6
Fold down design module ........................................... 6
Water connection ....................................................... 7
Variant TH .................................................................. 7
Water quality .............................................................. 7
Air connection ............................................................ 8
Wiring diagram ........................................................... 9
Description of problem: ............................................ 12
Commissioning .................................................. 13
ADC ......................................................................... 13
Lock one side ............................................................ 13
Installation of casing (accessory) ..................... 14
Connection to wall ................................................... 14
Connection to ceiling ................................................ 15
Maintenance ...................................................... 16
The document was originally written in Swedish
The document refers to version "d"
23/12/2024
Art. 942428080
Advertisement
Table of Contents
Related Manuals for Swegon ADRIATIC AWC
Summary of Contents for Swegon ADRIATIC AWC
-
Page 1: Table Of Contents
ADRIATIC AWC Installation - Commissioning - Maintenance 23/12/2024 Art. 942428080 Content The document refers to version ”d” Application area ..........2 General............... 2 Contents ..............2 Protective equipment ..........2 Electrical safety ............2 Handling ..............2 Installation ..............2 Cleaning .............. -
Page 2: Application Area
(1) The product is repaired, modified or changed, unless such repair, modification or change has been approved by Swegon AB; or (2) the serial number on the product has been made illegible or is missing. -
Page 3: Dimensions
31.1 37.7 39.8 40.3 45.8 48.4 49.1 * excl. controller (VAV = 0.723 kg, WISE = 0.598 kg), valves, ADRIATIC AWC Ellips actuators and sensors. 5 1 3 1 9 4 23/12/2024 Swegon reserves the right to make design changes. -
Page 4: Installation
The product is mounted on the ceiling using standard suspension bracket SYST MS-M8. c-c dimensions The c-c dimensions are the same for ADRIATIC AWC with both design module Prisma and design module Ellips. The examples to the right show Prisma. -
Page 5: Surface Mounted Installation
ADRIATIC AWC Surface mounted installation Installation The c-c dimensions are the same for ADRIATIC AWC with Surface-mounting the product on the ceiling using both design module Prisma and design module Ellips. The suspension bracket SYST MD-ADRIATIC. examples to the right show Prisma. -
Page 6: Secure Design Module
When lowering, one long side is opened and the design section is suspended from the opposite long side. l i c l i c Swegon reserves the right to make design changes. 23/12/2024... -
Page 7: Water Connection
Connecting water The water pipes are placed as standard on the same side Dimensions ADRIATIC AWC Prisma, end view, water connection as the air connection on one of the product’s short sides. If you want water and air connections on different short sides, Variant TH is available (see Variant TH). -
Page 8: Air Connection
Air connection, diameter Ø To connect the air 1.2 1.8 2.4 3.0 ADRIATIC AWC comes with open air connection on one short side. The sleeve is connected to the primary air duct. Dimensions ADRIATIC AWC Prisma, end view, air connection 256,5... -
Page 9: Wiring Diagram
Cable adapter 24 V AC / DC Pressure sensor (Modbus) A. Connection when a VOC sensor is used Adapter 3xRJ12 B. Connection on slave product Sensor module LOCUS Room controller LOCUS Room controller 23/12/2024 Swegon reserves the right to make design changes. - Page 10 2006/42/EEC EMC Directive: 2014/30/EU For more detailed information about LOCUS room controller. See documentation at www.swegon.com RoHS Directive: 2002/95/EC Vibrations: EN-60721-3-3 • LOCUS Product datasheet • LOCUS Instructions for Use (IOM) Swegon reserves the right to make design changes. 23/12/2024...
-
Page 11: Sensor Module
PC with the help of Cable Switch for termination resistance. On the last sensor converter USB-RJ12 module in the circuit switch 1 is set to On. 23/12/2024 Swegon reserves the right to make design changes. -
Page 12: Recommendation For Electrical Installations
Resistance (R) = (Resistivity (p) x Length (L)) / Area (a). • Swegon recommends that a 24 V power supply is con- Voltage drop in wire (UL) = Resistance (R) x current (I) nected with a 1.5 mm² copper cable to minimise the risk of voltage drops in the case of long cable runs. -
Page 13: Commissioning
ADRIATIC AWC Commissioning Fan-shape 0° - 4 0 ° 0° + 4 0 ° -40° V-shape 40° Lock one side Straight 0 ° + 4 0 ° 23/12/2024 Swegon reserves the right to make design changes. -
Page 14: Installation Of Casing (Accessory)
5. Cover the remaining opening with the cover by first anchoring the safety cord in the intended hole. 6. Lock the casing in place by folding down the ceiling bracket’s locking hooks on both sides. Use a screwdriver. Swegon reserves the right to make design changes. 23/12/2024... -
Page 15: Connection To Ceiling
3. Anchor the casing in the safety cord in the intended hole. 4. Lock the casing in place by folding down the ceiling bracket’s locking hooks on both sides. Use a screwdriver. 5. Install the end connection panel 23/12/2024 Swegon reserves the right to make design changes. -
Page 16: Maintenance
ADRIATIC AWC Maintenance l i c l i c Swegon reserves the right to make design changes. 23/12/2024...
