WISE Adriatic d
Instructions for Use
Contents
Key to symbols............................................................ 1
Application area .................................................. 2
Dimensions and weights .................................... 3
Installation .......................................................... 4
Suspended installation ................................................ 4
Surface mounted installation ....................................... 5
Secure design module ................................................. 6
Fold down design module ........................................... 6
Water connection ....................................................... 7
Air connection ............................................................ 8
Commissioning .................................................... 9
Connection ........................................................ 10
Declaration of Conformity ............................... 13
Maintenance ...................................................... 14
Fold down design module ......................................... 14
Secure design module ............................................... 14
The document was originally written in Swedish
Key to symbols
Symbols on the machine
This product complies with applicable
EU directives
Symbols in these Instructions for Use
Warning/Caution!
23/03/2023
Art. 942428063
Advertisement
Table of Contents
Related Manuals for Swegon WISE Adriatic Prisma
Summary of Contents for Swegon WISE Adriatic Prisma
-
Page 1: Table Of Contents
WISE Adriatic d Instructions for Use 23/03/2023 Art. 942428063 Contents Key to symbols Symbols on the machine Key to symbols............1 Application area ..........2 This product complies with applicable EU directives Dimensions and weights ........3 Installation ............4 Suspended installation .......... -
Page 2: Application Area
The product must be handled with care. within Swegon’s ventilation system WISE. The product is used to ventilate, cool and heat premises exactly as needed. Installation The product may not be used for anything other than its •... -
Page 3: Dimensions And Weights
A/B: Cooling/ (kg) A: Cooling A/B: Cooling/ Heating Heating 20.3 21.3 21.5 20.6 21.6 21.9 28.9 30.4 30.8 29.3 30.8 31.2 37.2 39.3 39.8 37.3 39.4 39.9 44.9 47.5 48.2 45.9 48.5 49.2 23/03/2023 Swegon reserves the right to alter specifications. -
Page 4: Installation
Prisma and design module Ellips. The example shows Prisma. c - c 392 ADRIATIC Suspended installation Length c-c (mm) c-c (mm) Short side Long side 1173 1773 2373 2973 Swegon reserves the right to alter specifications. 23/03/2023... -
Page 5: Surface Mounted Installation
280 7. Repeat this procedure for all the brackets. X=280 Y= < 250 Y= < 250 X=280 23/03/2023 Swegon reserves the right to alter specifications. -
Page 6: Secure Design Module
When lowering, one long side is opened and the design section is suspended from the opposite long side. C l i c k ! C l i c k ! Swegon reserves the right to alter specifications. 23/03/2023... -
Page 7: Water Connection
To avoid corrosion in the water circuit, the water quality in the system water must be checked regularly. Water quality Dimensions WISE Adriatic Prisma, end view, water connection Swegon recommends water quality according to VDI 2035-2 for both the heating and cooling systems. In order to maintain the oxygen content in the water below the levels (<0.1 mg/l) prescribed in VDI 2035-2, it is recommended... -
Page 8: Air Connection
WISE Adriatic comes with air connection on one short 1.2 1.8 2.4 3.0 side. The sleeve is connected to the primary air duct. Dimensions WISE Adriatic Prisma, end view, air connection 256,5 256,5 Dimensions WISE Adriatic Ellips, end view, air connection Swegon reserves the right to alter specifications. -
Page 9: Commissioning
[Pa] q = k · √p [l/s] pi [Pa] q [l/s] k = [k-factor] - 4 0 ° 0° + 4 0 ° 0° X-shape -40° 40° 0 ° 23/03/2023 Swegon reserves the right to alter specifications. -
Page 10: Connection
Type There are different types of actuators Energized White Permanent • For connection of the thermal actuator such as Swegon’s actuator ACTUATORc, see figure a. Selected in TuneWISE White Flashing, fast • When connecting the relay for connection of three or more... - Page 11 (1) The product is repaired, modified or changed, unless such repair, modification or change has been approved by Swegon AB; or (2) the serial number on the product has been made illegible or is missing.
- Page 12 Actuator for cooling and heating as well as WISE SMA, gives a total power consumption of 4.3 + 6 + 0.8 = 11.1 VA *Valid for products with CU ver. 2, delivered from 01/10/2019 Swegon reserves the right to alter specifications. 23/03/2023...
-
Page 13: Declaration Of Conformity
Date: Arvika 23/03/2023 This declaration is applicable only if the product has been installed according to the instructions in this document and if no modifications or changes have been made on this product. 23/03/2023 Swegon reserves the right to alter specifications. -
Page 14: Maintenance
C l i c k ! C l i c k ! Swegon reserves the right to alter specifications. 23/03/2023...
