- Page 1 FX-400 and FX-401 Fire Alarm Control Panel LT-6710 Rev. 1 Configuration Guide August 2023...
-
Page 3: Table Of Contents
Table of Contents Installation Install the Configurator ....................Insert the Wibu key ......................Connect the Computer to the Panel through the Micro-B USB Port on the Core Board Connect the Computer to the Panel through the Main Board ........Start the Configurator ..................... User Preferences Overview Configurator Window ..................... - Page 4 Add Device ........................Add Display Adder ......................Add IPS-2424DS and IPS-4848DS ................Configure IPS-2424DS and IPS-4848DS to Operate a Bypass Group ......Delete Correlations ......................Manage the Database Backup Database ......................Restore Database ......................Compact Database ......................Manage Jobs Create a New Job ......................Open Job ........................
- Page 5 10.9 Trace ..........................10.10 Display Structure ......................10.11 External Bus ........................10.12 About MGC-400 Series Configuration Utility ..............10.13 Paste Special - Circuits, Adders or Entire Loops ............10.14 Paste Special - Display Items, Display Adders or Annunciators ........11.0 Correlations Pane 11.1 Input Circuit Correlations ....................
- Page 6 List of Figures Figure 1 Setup - MGC-400 Configurator ..................Figure 2 Select Destination Location .................... Figure 3 Select Start Menu Folder ....................Figure 4 Ready to Install ......................Figure 5 FTDI CDM Drivers ......................Figure 6 Welcome to the Device Drive Installation Wizard ............Figure 7 Device Drive License Agreement ...................
- Page 7 Figure 85 Upgrade Firmware Wizard: Click Finish to complete the process ......... Figure 86 Select the COM port in User Preferences ..............Figure 87 Firmware Upgrade Wizard ..................... Figure 88 Jumpers on the FX-400 and FX-401 core board ............Figure 89 Paste Special .........................
- Page 8 Figure 90 Paste Special ......................... Figure 91 Correlations window ....................... Figure 92 Differences ........................Figure 93 Print ..........................Figure 94 Print Setup ........................
-
Page 9: List Of Tables
List of Tables Table 1 User Preferences ......................Table 2 File Menu ........................Table 3 Job Menu ........................Table 4 Insert Menu ........................Table 5 Edit Menu ........................Table 6 Panel Menu ........................Table 7 Tools Menus ........................Table 8 Quick Bar Icons ...................... -
Page 10: Installation
Installation To connect the Configurator to the Fire Alarm Control Panel you must: • Install the Configurator. • Insert the Wibu key. • Connect the cable. • Start the Configurator. Follow the instructions below to complete these steps. Install the Configurator You need the following items in order to install the Configurator: •... -
Page 11: Figure 2 Select Destination Location
The Select Destination Location window appears. Figure 2 Select Destination Location 3. Click Browse and select a location for the Configurator to be installed, and then click Next. The Select Start Menu Folder window appears. Figure 3 Select Start Menu Folder 4. -
Page 12: Figure 4 Ready To Install
The Ready to Install window appears. Figure 4 Ready to Install 5. Click Install. The MGC-400 Configurator software is installed. 6. The FTDI CDM Drivers window appears. These drivers are necessary for connecting to the panel with a USB cable. Figure 5 FTDI CDM Drivers 7. -
Page 13: Figure 6 Welcome To The Device Drive Installation Wizard
The Welcome window appears. Figure 6 Welcome to the Device Drive Installation Wizard 8. Click Next. The License Agreement window appears. Figure 7 Device Drive License Agreement 9. Click I accept the agreement to accept the agreement, and then click Next. -
Page 14: Figure 8 Completing The Device Drive Installation Wizard
The Completing the Device Driver Installation Wizard window appears. Figure 8 Completing the Device Drive Installation Wizard 10. Click Finish. The WibuKey Setup window appears. The Wibu key is a USB flash drive that provides security by controlling access to the Fire Alarm Control Panel. Figure 9 WibuKey Setup 11. -
Page 15: Figure 10 Wibukey Language Selection
The language selection window appears. Figure 10 WibuKey Language Selection 12. Click Next. The destination folder window appears. Figure 11 WibuKey Destination Folder 13. Click Next. 14. On the next window, click Yes to create the folder. Figure 12 The specified folder does not exist... -
Page 16: Figure 13 Wibukey Components
The components window appears. Figure 13 WibuKey Components 15. Click Next. The summary window appears. Figure 14 WibuKey Summary 16. Click Next. -
Page 17: Figure 15 Wibukey Second Summary
The second summary window appears. Figure 15 WibuKey Second Summary 17. Click Next. The Finish window appears. Figure 16 WibuKey Finish 18. Click Finish. 19. Click OK on the WibuKey driver successfully installed window. Figure 17 WibuKey driver successfully installed... -
Page 18: Figure 18 Completing The Mgc-400 Configurator Setup Wizard
After the WibuKey drivers have been installed, the last screen of the MGC-400 Setup Wizard appears. Figure 18 Completing the MGC-400 Configurator Setup Wizard 20. Click Finish. 21. Close the Welcome to the WibuKey User Help window. Figure 19 Welcome to the WibuKey User Help... -
Page 19: Insert The Wibu Key
If a Security Key Logon window appears that says that your security key is an older version, you must contact your ESD Administrator or Mircom technical support to upgrade your key. Otherwise, you might not be able to connect to the FX-400/401. Connect the Computer to the Panel through the Micro-B USB Port on the Core Board Attention: Follow the instructions in this section only if the panel’s plug-in core... -
Page 20: Connect The Computer To The Panel Through The Main Board
Connect the Computer to the Panel through the Main Board Attention: These instructions describe how to connect to the panel if the panel’s plug-in core board does NOT have a sticker showing “SO-289 v3.0.1” or “SO-479 v3.0.1” (or a number higher than 3.0.1). If the sticker on the core board DOES show “SO-289 v3.0.1”... -
Page 21: Figure 25 Device Manager
1.4.3 Configure the Device Manager for USB Attention: If you connect more than one FX-400/401 panel to the same computer over USB, always use the same physical USB port on the computer. Otherwise, every time that you connect a panel to a different port, you must complete the steps in this section. -
Page 22: Figure 26 Microsoft Serial Ballpoint
2. Right-click Microsoft Serial Ballpoint, and then click Disable device in the pulldown menu. A window appears warning that disabling this device will cause it to stop functioning. 3. Click Yes. Figure 26 Microsoft Serial Ballpoint An X (a downward pointing arrow in Windows 8) appears over the Microsoft Serial Ballpoint, showing that is it disabled. -
Page 23: Figure 30 Usb Serial Port Properties
If there is more than one USB Serial Port, click the one that you are using to connect to the FX-400/401. The USB Serial Port Properties window appears. Figure 30 USB Serial Port Properties 6. Click the Port Settings tab. -
Page 24: Figure 32 Advanced Settings
7. Click Advanced. The Advanced Settings window appears. Figure 32 Advanced Settings 8. Click the pulldown menu beside Receive (Bytes), and then click 64. 9. Click the pulldown menu beside Transmit (Bytes), and then click 64. 10. Click the pulldown menu beside Latency Timer (msec), and then click 1. 11. -
Page 25: Figure 34 Communications Port Properties
It is usually labeled Communications Port (COM1). If there is more than one COM communications port, click the one that you are using to connect to the FX-400/401. The Communications Port Properties window appears. Figure 34 Communications Port Properties 3. -
Page 26: Start The Configurator
4. Click Advanced. The Advanced Settings window appears. Figure 36 Advanced Settings 5. Drag the slider beside Receive Buffer to the far left. 6. Drag the slider beside Transmit Buffer to the far left. 7. Click OK to close the Advanced Settings window. 8. -
Page 27: Figure 38 Connection
4. Click OK to close the User Preferences window. 5. Click Panel, then click Connect. The Connection window appears. Figure 38 Connection 6. Click Connect. 7. You are now connected to the panel. Go to section 2.0 on page 28. -
Page 28: User Preferences
User Preferences The first time the Configurator starts, the User Preferences window appears. Figure 39 User Preferences window Table 1 User Preferences Name Description User Name Used for the author of all new jobs and job versions. Serial Port Designates which COM port (or USB virtual COM port) the Configurator uses to connect to the panel. -
Page 29: Overview
Overview In order to operate as a fire alarm, a fire alarm panel must be loaded with firmware and configuration data. A set of configuration data, used to uniquely describe and control a given set of hardware, is called a Job. The Configurator allows you to create and manage jobs. It also allows you to send firmware to a panel and all its related CPUs. - Page 30 3.1.2 Details The top right pane is used to display the details of the currently selected tree node. 3.1.3 Correlations Programming a Fire Alarm Control Panel consists of correlating inputs to outputs. For example, you might correlate all the smoke detectors on the first floor to the speakers on the first and second floors, and smoke detectors on the second floor to the speakers on the first, second, and third floors, and so on.
-
Page 31: Menus
Menus File Menu The File Menu contains the following commands: Table 2 File Menu Name Shortcut Description Backup Makes a copy of the Master Database in the file folder Database specified in the User Preferences. The backup file has a name of the form YYYY-MM-DD.mdb. -
Page 32: Insert Menu
Table 3 Job Menu (Continued) Name Shortcut Description Open Job Opens an existing job from your database. Ctrl+O Import Job Imports a selected job version from an external database or serialized job archive and converts the job to the current version if necessary. -
Page 33: Edit Menu
Edit Menu The Edit Menu contains the following commands. Some commands may be disabled (greyed) depending on what items are selected. Table 5 Edit Menu Name Short cut Description Delete Item Deletes the currently selected item. Modify Item If the currently selected item is a row in an editable list, then Ctrl+M the first changeable cell is selected and prepared for editing. -
Page 34: Tools Menu
Tools Menu The items under the Tools Menu are used mainly for troubleshooting and diagnostic purposes by the factory. Table 7 Tools Menus Name Short cut Description Extract All Db Extracts the latest version of every job to individual database files. - Page 35 Table 8 Quick Bar Icons (Continued) Name Copy Paste Paste Special Delete Print Compare Jobs Connect Send Job Get Job Panel Info Security Key About Help On...
-
Page 36: Job Tree And Details Pane
Job Tree and Details Pane This section covers the following components of the Configurator: • Job Details • Details Pane • Bypass Groups • Output Zone • Main Display • Display Adder • Dialer • Common System Status • Input Summary and Output Summary Job Details Figure 41 Job Details 5.1.1... -
Page 37: Table 9 Job Options
5.1.3 Options Table 9 Job Options Name Description Manual Signal Silence Check this option to enable the panel's Signal Silence switch. Fire Drill Check this option to enable the panel's Fire Drill switch. Waterflow Retard Operation Check this option to perform a retard operation for initiating circuits configured as waterflow. - Page 38 System Reset Strobes Type Specify the Strobe Type that should be used on the panel. • Gentex • System Sensor • Mircom • Wheelock Evacuation Code Specify the Evacuation Code that should be used on the panel. • Continuous •...
-
Page 39: Table 10 Timers
5.1.4 Timers Table 10 Timers Timer Type Possible Settings Signal Silence Inhibit Use this function to inhibit the Signal Silence button for a desired length of time. The time period should expire before the signals may be silenced. Disabled, 10, 20, 30 seconds, 1 minute. Auto Signal Silence Use this function to set the time period for which the indicating circuits sound before they are automatically... -
Page 40: Figure 42 Holidays Window
5.1.5 Date and Time Table 11 Date and Time Name Description Enable Daylight Savings Check this box to enable automatic change to and from daylight saving time. Clock Daily Compensation Specify the number of seconds (signed) to be applied daily to the panel clock. -
Page 41: Details Pane
To add a new holiday 1. Compose a new holiday definition in the YYYY MM DD edit boxes. 2. If the holiday lasts longer then one day change the value in the Duration edit box to the desired length. 3. Click Add Holiday. The holiday appears in the Holidays defined list. -
Page 42: Table 13 Loop Details
To show a hidden column, move the cursor between the column headings until it turns into a vertical line with two horizontal arrows, like this: Then click and drag the edge of the column to the left. Table 13 Loop Details Column Visible Description... -
Page 43: Figure 43 Double-Click In The Loop Details To Change Device Information
5.2.1 Change Device Information in the Loop Details 1. Double-click in the column of the option you want to change (Figure 43). 2. Enter the new value or select it from the menu that appears. Note: Not all the options are editable. The editable options depend on the type of device. -
Page 44: Figure 44 Add Output Zone
Table 15 Output Zones (Continued) Column Description Type The process type of the output zone. NS: Non Silenceable - used on Signal or Strobe type. AR: Auxiliary Reset required - used on Relay type. The text of the tag, in a 20 character field. Note: Output devices that are configured as the Signal or Strobe types are correlated to Fire Drill and Total Evacuation automatically. -
Page 45: Main Display
4. Click Close. 5. Select the new output zone. 6. Click Insert in the menu bar, then click Add Correlations. The Select items to add window appears. Figure 45 Select items to add to output zone 7. Select the output devices that you want to add. To select more than one device, hold down the Ctrl key and click the devices. -
Page 46: Display Adder
Table 17 Main Display (Continued) Name Description Access Levels Specify the level of access for various front panel actions. Items assigned level 0 do not require a passcode. The level 1 passcode has the lowest permission, and the level 3 passcode has the highest permission. -
Page 47: Dialer
Table 18 Display Adder Info (Continued) Name Visible Description Not used. Not used. Not used. Except for System Led and Bypass Zone, a 20 character tag Tag 1 can be entered. This tag identifies the control in messages. Tag 2 Conditional Not used. -
Page 48: Table 22 Dialer Line 2
5.7.4 Line 2 Table 22 Dialer Line 2 Name Description Dial Using Tone or Pulse. Wait Check to wait for dial tone before dialling. 5.7.5 Report Priority Table 23 Dialer Report Priority Name Description Alarm Choose one of the two accounts to use to report Alarms. Supv Choose one of the two accounts to use to report Supervisory alerts. -
Page 49: Common System Status
performed on Line 1 except on the day of the Line 2 cellular test, when it is performed on Line 2. See examples in Table 25. Table 25 Lines 1 and 2 Test Times Line 2 cellular Auto test at Line 1 Tested Line 2 Tested test... - Page 50 The Input Summary gives an Input UDACT reference number and tag required for programming by the Central Monitoring Station. On products that support them, this list may include Correlatable Switches. These do not have a value in the Loop and Address columns. The Output Summary gives an output UDACT reference number and tag required for programming by the Central Monitoring Station.
-
Page 51: Add Items To The Job
Add Items to the Job Add a Loop Controller (FX-401 Only) To add an ALC-480 Dual Loop Adder 1. Click Insert, then click Add Loop Controllers. Loop 2 and Loop 3 appear in the Job Tree under Base I/O. Add Annunciator To add an annunciator 1. -
Page 52: Add Device
To add correlations 1. From the Details Pane right click an item and select Add Correlations. The Add Correlations window appears. Figure 46 Add Correlations Window 2. Select the items to be correlated, then click the Add button. You can hold down the Ctrl key to select multiple rows. 3. -
Page 53: Table 28 Add Device
3. Enter the following information: Table 28 Add Device Name Description Type The major device type. Options The available options depend on the device. Process As Choose the type of alarm that you want to associate with this device. Address Specify the address for the new device. -
Page 54: Figure 49 Photoh 135 (4020) With The Address 1
Figure 49 PhotoH 135 (4020) with the address 1 A class B Dual Input (4040/1) with the address 1 has the following entries: • Dual Input (4040/1): 1.1 (first input) • Input: 1.2 (second input) Figure 50 Class B Dual Input (4040/1) with the address 1 A class B 12-Input (4040-M) with the address 1 has the following entries: •... -
Page 55: Figure 52 Base Selection
• ARB (Addr. Relay Base): addressable relay base • ALB (Addr. Low-Freq Base): not used Figure 52 Base selection When you add a device with an addressable base, the base is assigned a subaddress. For example, a Photo (4010) at address 1.1 has an addressable sounder base at 1.2. Figure 53 Photo (4010) with addressable sounder base 6.4.3 Add a Class A or Class B Device... -
Page 56: Figure 56 Convert A Device To Class A
6.4.4 Convert a Device to Class A or Class B To convert a class B device to class A, follow these steps: 1. Double-click Class B in the Options column for the device. 2. Select Class A in the menu that appears. Figure 56 Convert a device to class A The Configurator deletes subaddresses as necessary. -
Page 57: Add Display Adder
Add Display Adder Figure 59 Add Display Adder window To add a display adder 1. In the Job Tree, right-click one of the listed annunciators and select Add Display Adder. The Add Display Adder window appears. 2. From the drop down menu select the desired Display Adder. 3. -
Page 58: Figure 60 Bypass Switch
Create a bypass switch 1. Select the 24 Sw Adder or 48 Sw Adder. By default, all the switches are unassigned. 2. Double-click <unassigned> in the Type column for a switch, and select Byp Zone. In Figure 60, switch 0 on the 24 Sw Adder is a bypass switch. Figure 60 Bypass switch Create a bypass group 1. -
Page 59: Delete Correlations
5. Select the devices that you want to add. To select more than one device, hold down the Ctrl key and click the devices. 6. Click Add. 7. In the Select items to add window, click the Display tab and select the adder switch to assign to this bypass group, then click Add. -
Page 60: Manage The Database
Manage the Database The database stores all jobs and their information. You can back up, restore or compact databases. Backup Database The Backup Database command makes a copy of the Master Database. Note: If the Keep Only Latest Versions After Backup option is enabled in User Preferences, old versions of each job in your main database will be deleted when you back up the database. -
Page 61: Figure 65 Restore Database
by an older version of the configuration tool, all necessary conversion is performed. Conversion is sometimes necessary when a new version of the configuration tool is released. The install program makes a backup and instructs you to run Restore Database to convert all of your jobs. -
Page 62: Compact Database
2. Click Yes to continue. 3. The file location specified in the User Preferences appears and the file name is in the form YYYY-MM-DD.mdb. 4. Select the desired database and click Open. A popup window appears notifying you of a successful restore. Compact Database A database that has been the subject of many deletions and additions can become fragmented and occupy more space than required. -
Page 63: Manage Jobs
Manage Jobs Create a New Job Figure 67 Create Job window To create a new job 1. Click Job, then click New Job. The Create Job window appears. 2. Enter the information in Table 29, then click OK. Table 29 New Job Name Description Enter description for new... -
Page 64: Open Job
Open Job Figure 68 Select Job and Version window The Open Job command lets you select a job and version in the database and open it. The Select Job list shows all of the jobs in the database. Click the column heading to sort the jobs •... -
Page 65: Import Job
Import Job Figure 69 Import Job window The Import Job command imports a selected job version from an external database or serialized job archive as created by the Export Job or Backup Database commands. and converts the job to the current version if necessary. Choose the type (MDB or Serialized Archive) and location of the file to read. -
Page 66: Export Job
Export Job Figure 70 Export Job window Use the Export Job command to share a job, for example between technicians. The fx2job format results in a very small file, suitable for electronic transmission. By default, the file is given a name Jobnn-vv where nn is the job number and vv is the version. -
Page 67: New Version
New Version To create a new job version 1. Click Job > New Version. The New Job Version window appears. 2. Enter the name of the technician making the change, any related comments and click Delete Job Version Deleting the Job Version deletes the currently open Job from the Database. When a job is deleted, it will no longer be accessible from the Version History window. -
Page 68: Compare Job Versions
Table 31 Version History (Continued) Name Description Type Uploaded: the new job version was a result of a Get Job. New Job: the user created a new version manually. Status Locked: the job has been sent to the panel and cannot be edited. Editable: the job is editable. -
Page 69: Figure 73 Advanced Compare Options Window
Table 32 Select Job to Compare (Continued) Name Description Advanced Options Click Advanced Options to open the Advanced Options window. Here you can change some of the more advanced filtering options. They are checked by default and in most situations do not need to be changed. See section 8.8.1. -
Page 70: Validate Job
Notes: Filtering of Present only in Secondary and Present only in Primary do not apply when presenting the tree. The tree is shown in its entirety, regardless of these settings. The filtering is only applied to the Device, Display Item and similar lists. -
Page 71: Figure 75 This Job Version Has Already Been Built Or Downloaded To The Panel
If you try to edit a job that has been sent to a panel, a message appears saying that you should create a new version. See section 8.5 on page 67. Figure 75 This job version has already been built or downloaded to the panel... -
Page 72: Work With The Panel
Work with the Panel Connect Figure 76 Connection window To connect to the panel 1. Select a connection type. Table 34 Connection Name Description Direct Serial Select this option if you have connected a serial cable directly from the serial port (or USB or UIMA4) of your computer to the fire alarm panel. -
Page 73: Send Job
Send Job To send a job to the panel 1. Click Panel > Send Job. 2. Click Yes. Once the job has been successfully sent a confirmation window appears. 3. Click OK. Get Job To get a job from the panel 1. -
Page 74: Figure 77 Panel Information
Click the Update button to update the panel time with the time from the Configurator for those products that support the feature. Figure 77 Panel Information 9.4.1 Advanced Panel Information Click the Advanced button to see more information. This information may not appear for all annunciators. -
Page 75: Event Log
“SO-289 v3.0.1” or “SO-479 v3.0.1” (or a number higher than 3.0.1), follow the instructions in section 9.7 on page 79. You need the following items in order to upgrade the firmware on the FX-400 and FX-401: • Windows 10 computer with a USB port. -
Page 76: Figure 79 Micro-B Usb Port On The Core Board
Upgrade the firmware 1. Connect the USB cable to a USB port on the computer, and to the USB port on the FX- 400/401 plug-in core board. This port is labeled P5. Micro-B USB Port Core Board Figure 79 Micro-B USB Port on the core board 2. -
Page 77: Figure 81 Upgrade Firmware Wizard
4. Click OK to close the User Preferences window. 5. Click Panel > Upgrade Firmware. The Upgrade Firmware Wizard appears: Figure 81 Upgrade Firmware Wizard 6. Click Browse and select the firmware file. 7. Click Next. 8. Follow the instructions in the next window: a. -
Page 78: Figure 83 Upgrade Firmware Wizard: Sending File
9. Click Next. A window appears showing the firmware upgrade status. Figure 83 Upgrade Firmware Wizard: Sending file 10. After the file is sent successfully, click Next. Figure 84 Upgrade Firmware Wizard: The panel is upgraded successfully... -
Page 79: Upgrade Firmware Through The Main Board
“SO-479 v3.0.1” (or a number higher than 3.0.1), follow the instructions in section 9.6 on page 75 above. You need the following items in order to upgrade the firmware on the FX-400 and FX-401 by connecting to the main board: •... -
Page 80: Figure 86 Select The Com Port In User Preferences
1. Connect the laptop to the panel using one of the methods shown in section 1.4.1 on page 20. 2. In the MGC-400 Configurator, click File - User Preferences. 3. In the Serial Port menu, select the COM port that the cable is using. Figure 86 Select the COM port in User Preferences 4. -
Page 81: Figure 88 Jumpers On The Fx-400 And Fx-401 Core Board
8. Follow the instructions on the screen to upgrade the firmware. Attention: The instructions in the Upgrade Firmware Wizard include moving the jumpers on the core board. The FX-400 and FX-401 core board is shown below. Figure 88 Jumpers on the FX-400 and FX-401 core board... -
Page 82: Tools Menu
10.0 Tools Menu 10.1 Extract All DB This command extracts every job on the database and produces an individual database file for each. It has the same effect as running Export Job for every job. Unlike Export Job, you do not have the choice of making a compact serial archive (FX2Job). -
Page 83: Trace
10.9 Trace Toggles the current state of the trace option. When turned on this causes debug information to be written to a trace file 10.10 Display Structure This utility allows you to view the contents of a panel data structure. You have the option of continually retrieving and displaying the same structure at a refresh rate you specify. -
Page 84: Paste Special - Circuits, Adders Or Entire Loops
10.13 Paste Special - Circuits, Adders or Entire Loops This window appears in response to a Paste Special when pasting circuits, conventional adders or entire loops. Figure 89 Paste Special The text summarizes what is being pasted and its destination, for example pasting three devices to loop 2. -
Page 85: Paste Special - Display Items, Display Adders Or Annunciators
10.14 Paste Special - Display Items, Display Adders or Annunciators This window appears in response to a Paste Special when pasting display items, display adders or entire annunciators. Figure 90 Paste Special The text summarizes what is being pasted and its destination, for example pasting three display items to frame 0. - Page 86 If any 3 POSITION SLIDE SWITCH is encountered while attempting a "Reference Copy" of individual items, a complete adder or an entire annunciator, an error message is displayed and a roll back of the operation occurs. Both the new copy and the source (and any subsequent reference copies) are marked with an asterisk to warn you that the items are 'linked"...
-
Page 87: Correlations Pane
11.0 Correlations Pane Programming a Fire Alarm Control Panel consists of correlating inputs to outputs. For example, you might correlate all the smoke detectors on the first floor to the speakers on the first and second floors, and smoke detectors on the second floor to the speakers on the first, second, and third floors, and so on. -
Page 88: Differences Mode And Differences Report
12.0 Differences Mode and Differences Report 12.1 Introduction The Configurator can compare two jobs. The differences mode shows which elements have been added, removed or changed. The lists show in more detail which items have been modified or whether correlations have been added or removed. In differences mode a report can be printed. -
Page 89: Figure 92 Differences
Figure 92 Differences The magnifying glass icon represents an item that has been modified, symbolizing that it warrants a closer look: some lower level attributes have changed. Items that have not changed have the green check mark icon, which means that there were no reportable changes on this item or any of its lower levels. -
Page 90: Printing
13.0 Printing The print and print preview operations function just as in regular mode. In addition to choosing how much of the job to print, you can also decide whether to print Outputs with Input Correlations, Inputs with Output Correlations or Display Correlations. If you chose to suppress identical items when you entered differences mode, then any node in the tree that is marked with a green check mark is not printed. - Page 91 Table 37 Print (Continued) Name Description Complete Job Regardless of what item in the Job Tree you currently have selected, the complete job is printed. The print program prints all of the details of the Base Panel, followed by all of its loops, main display, etc. Then it goes to the next major node of the tree (e.g Loop Adder, CPU 1), printing its details and all of its contained loops.
-
Page 92: Print Setup
Table 37 Print (Continued) Name Description Pages this check box is only available when performing a print. It is disabled for print preview. During preparation of a print preview or a print, the program makes one first pass through the tree nodes and loops that are in scope. - Page 93 CANADA - Main Office U.S.A © Mircom 2023 25 Interchange Way 4575 Witmer Industrial Estates Printed in Canada Vaughan, ON L4K 5W3 Subject to change without prior notice Niagara Falls, NY 14305 Tel: (905) 660-4655 Tel: (905) 660-4655 www.mircom.com (888) 660-4655...
