Grillstream GCH65MG Manual

Classic 6 burner hybrid barbecue
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Classic 6 Burner Hybrid Barbecue
x 44
WARNING! FOR YOUR SAFETY, FOR OUTDOOR USE ONLY
Please read these instructions carefully and ensure that your barbecue is properly installed, assembled,
maintained and serviced in accordance with these instructions.
Failure to follow these instructions may result in serious injury and/or damage to property.
Necessary
Tools
Please check the pack contents before attempting to assemble this product.
A full checklist of components is given in this leaflet. If any components are
missing, please contact the retailer from whom you bought this product.
This product takes approximately 60 MINUTES
to assemble with 2 PEOPLE. The fittings pack
contains SMALL ITEMS which should be KEPT
AWAY FROM YOUNG CHILDREN. Read this
leaflet in full before commencing assembly.
GCH65MG
x 4
x 12
x 12
x 2
x 44
AA Battery (Not included)
Carbon Monoxide Hazard
Using a barbecue inside can kill you,
it gives off Carbon Monoxide, which has no odour.
Never use a barbecue in enclosed spaces such as
a tent, home/building, vehicle or garage.
Scan me for step by
step video instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GCH65MG and is the answer not in the manual?

Questions and answers

Related Manuals for Grillstream GCH65MG

Summary of Contents for Grillstream GCH65MG

  • Page 1 Classic 6 Burner Hybrid Barbecue GCH65MG x 44 x 12 x 44 x 12 WARNING! FOR YOUR SAFETY, FOR OUTDOOR USE ONLY Please read these instructions carefully and ensure that your barbecue is properly installed, assembled, maintained and serviced in accordance with these instructions.

  • Page 2: Table Of Contents

    How is it different from natural gas Page Lighting your BBQ Page Using your BBQ Page Hybrid System Page Maintenance of your BBQ Page Troubleshooting Page Exploded Diagram Page Parts list for GCH65MG Page Fittings list Page Assembly instructions Page 12-31 Leak Test Page Page 2...

  • Page 3: Warning Information

    GCH65MG CONNECTING THE GAS CYLINDER WARNING INFORMATION There are two different types of gas that can be used on your gas BBQ - Read this Operating Manual before use depending on where you live, that being either butane or propane gas.

  • Page 4: Testing For Leaks

    GCH65MG SECURING THE HOSE AND REGULATOR ASSEMBLY WHAT IS PROPANE Type A) Screw on hose connection (Fig. 4) It is a fuel gas compressed until it turns to liquid, then stored in a bottle - The BBQ’s manifold connection is 1/4” Male Thread BSP or cylinder under pressure for easy transport.

  • Page 5: Lighting Your Bbq

    - Your Side Burner is fitted with a separate electric ignition button and so the lighting procedure differs slightly from that of the main burners. Grillstream Grills fit directly on top of each other - do not offset them. - To light your side burner follow the instructions above but after...

  • Page 6: Hybrid System

    DIRECTIONS FOR USE - GAS: Your charcoal should now be lit and making the tell-tale popping and The beauty of the Grillstream Hybrid System is that there is no cracking sounds that indicate this. You should now turn off the burners additional assembly or conversion process required, whether you want completely and close your Barbecue Hood.

  • Page 7: Maintenance Of Your Bbq

    To clean the Grills effectively use the Grillstream cleaning brush which has been specially designed to quickly and effectively clean your Grillstream Grills. Rinse off with clean water and dry before returning to BBQ.

  • Page 8: Troubleshooting

    GCH65MG TROUBLESHOOTING A note on fire prevention: Most fires in outdoor BBQs are caused by a build up of greases and fat, IF BBQ FAILS TO OPERATE PROPERLY or gas connections which have not been secured properly. Remember - Stop, turn off gas at its source and turn all burner controls to • off to follow the manufacturer’s instructions on proper cleaning and...

  • Page 9: Exploded Diagram

    GCH65MG Page 9...

  • Page 10: Parts List For Gch65Mg

    Grill Lifter Cabinet Rear Panel Warming Rack Corner Support Bracket Circular Griddle Plate Front Support Bar Grillstream Gastro Grill - Left Side Shelf Grillstream Gastro Grill - Right Cabinet Door Grillstream Grill - 230mm Battery Pack Grillstream Grill - 190mm...

  • Page 11: Fittings List

    GCH65MG x 44 x 12 x 12 x 44 x 12 x 12 FITTINGS x 44 x 44 Part Part Part Part x 12 x 44 x 12 x 44 x 12 x 44 x 12 x 12 x 44...

  • Page 12: Assembly Instructions

    GCH65MG STEP 1 Push each of the Castors (5) into indicated holes in underside of Cabinet Base Panel (6) until you hear a click. Page 12...
  • Page 13 GCH65MG STEP 2 Part unscrew the bolts indicated from Cabinet Base Panel (6), slot the Cabinet Side Panels (7 & 8) into place and retighten bolts. Page 13...
  • Page 14 GCH65MG STEP 3 Insert and part tighten bolts (B) into Cabinet Side Panels (7 & 8). Slot Cabinet Rear Panel (9) into place and secure to Cabinet Base Panel (6) with Bolts (B). Now fully tighten bolts into Cabinet Side Panels (7 & 8).
  • Page 15 GCH65MG STEP 4 Part unscrew bolts indicated from Cabinet Side Panels (7 & 8) and Cabinet Base Panel (6). Slot Cabinet Corner Braces (10) in place and retighten bolts. Page 15...
  • Page 16 GCH65MG STEP 5 Insert Front Support Bar (11), ensuring magnet is positioned towards bottom of support bar, and secure with Bolts (A). x 44 Part x 12 x 44 x 12 M4x12 Bolt Page 16...
  • Page 17 GCH65MG STEP 6 Carefully lower cooking frame onto cabinet, ensuring fixing lugs are on the outside and that no wires or hoses are trapped between cooking frame and cabinet. Page 17...
  • Page 18 GCH65MG STEP 7 Secure cooking frame to side panels (7 & 8) using Bolts (B). Part x 44 x 12 M6x12 Bolt Page 18...
  • Page 19 GCH65MG STEP 8 Part unscrew bolts indicated, slot Side Shelf (12) in place and re-tighten bolts to secure. Page 19...
  • Page 20 GCH65MG STEP 9 Further secure Side Shelf (12) in place from inside the cooking frame using Bolts (B) and Washers (D). Note: Washers (D) are domed and bottom of dome should be facing the cooking frame. x 44 Part x 12...
  • Page 21 GCH65MG STEP 10 Unscrew Ignition Button and Securing Nut from Ignition Unit. Slide Ignition Wire over Gas Ignition Electrode. From within, Insert Ignition Unit through hole in Side Burner Shelf. Install 1 x AA battery (supplied) and screw Securing Nut and Ignition Button back onto Ignition Unit.
  • Page 22 GCH65MG STEP 11 Part unscrew bolts indicated, slot Side Burner Shelf (19) in place and retighten bolts to secure. Page 22...
  • Page 23 GCH65MG STEP 12 Further secure Side Burner Shelf (19) in place from inside the cooking frame using Bolts (B) and Washers (D). Note: Washers (D) are domed and bottom of dome should be facing the cooking frame. Part x 44...
  • Page 24 GCH65MG STEP 13 Part unscrew bolts indicated on end of Side Burner Hose. Slot into bracket on underneath of Side Burner Shelf (19) and retighten bolts to secure. Page 24...
  • Page 25 GCH65MG STEP 14 Attach Gas Connection Bracket to Side Panel (8) using Bolt (A). x 44 Part x 12 x 44 x 12 M4x12 Bolt Page 25...
  • Page 26 GCH65MG STEP 15 Insert Door Spindles (C) into Cabinet Base Panel (6). Part x 44 Door Spindle Page 26...
  • Page 27 GCH65MG STEP 16 To fit Cabinet Doors (13) in place, first slide the hole on bottom of door over Door Spindle (C), depress spring-loaded catch on underside of Cooking Frame and position top of door until spring-loaded catch slides into top hole.
  • Page 28 GCH65MG STEP 17 Attach Grease Cup Bracket (16) to underside of Grease Tray (15) using Bolts (A). Place Grease Cup (17) inside Grease Cup Bracket (16) and then slide underneath Cooking Frame ensuring it is level and on top of runners.
  • Page 29 GCH65MG STEP 18 Insert 4 x AA Batteries (not supplied) into Battery Pack (14). Connect Battery Box to LED Light Wire. Peel off plastic backing from sticky pad on the rear of the Battery Box and affix to inside of Side Panel (8).
  • Page 30 Place Hybrid Flame Tamers (18) on locating shelves. Flame Tamers should sit directly above Tube Burners. Place Grillstream Grills (28 & 29), Grillstream Gastro Grills (26 & 27) and Circular Griddle Plate (25) into Cooking Frame. Leg tabs from both types of Grill should rest on lip at back of Cooking Frame. Top Grills should sit directly on top of the bottom Grill.
  • Page 31 Attach Bottle Opener (22) to side of Control Panel using bolts supplied. Hook Grillstream Fat Cup (21) over holes in Side Panel (8). This should be located directly below the spout of Fat Channel (20) to catch fat and meat juices channelled from the Grillstream system.

  • Page 32: Leak Test

    GCH65MG STEP 21 Your Grillstream barbecue is now fully assembled and you are ready to connect the Gas Cylinder (see page 3 for more information). Please ensure you perform the gas leak check before operating. Page 32...
  • Page 33 GCH65MG TESTING YOUR BBQ TESTING FOR LEAKS - DO THIS BEFORE USING YOUR BBQ. Note - Do not test for gas leaks with an open flame. If you smell gas, turn off at the source. Before first use, at the beginning of each new season, or whenever a gas cylinder is changed, you must check for gas leaks.
  • Page 34 PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE Grillstream Barbecues Part of the LeisureGrow Group Dewmead Farm, New Inn Road, Hinxworth, Hertfordshire SG7 5HG, United Kingdom. Tel: +44 (0)1462 744500 E-mail:salessupport@leisuregrow.com...
