Configuring a New Controller Starting from Factory Defaults

Connecting to the Controller Via a Browser

24
1. Initial provisioning of the controller is done via the command line
interface (CLI). Connect a null modem serial cable between the
console port of the controller and the serial port of a PC.
2. Open a terminal program, such as Hyper Terminal, and configure the
port settings to 9600 baud, no parity, 8 data bits and 1 stop bit.
3. Power-on the controller. Status of the controller's boot process will
appear as the controller is powering up. Once the controller is
running, it will prompt you to run the Startup Wizard.
4. The Startup Wizard provides for an easy means to perform initial
controller setup and provisioning. Refer to the Installation and Startup
Guide for the Cisco 4400 Series WLC, or other appropriate controller,
found at Cisco's website. This document contains a detailed
explanation of using the Startup Wizard for the 4400:
http://www.cisco.com/en/US/docs/wireless/controller/4400/quic
k/guide/ctrlv32.html#wp34023
5. Once the controller has been configured via the Startup Wizard, the
remaining configuration can be configured through the switch-web
interface using a Web browser (Cisco recommends using MS IE 6.0+).
6. If necessary, the controller can be reset to factory defaults. To reset
the WLC to factory default, you must reboot, then type
at the CLI. This only works before the first time a user logs in
config
via the console.
1. Connect to the WLC by pointing your internet browser to the URL:
https<IP_Addr> (where <IP_Addr> is the IP address of the
management interface of the WLC).
2. Click the prompt. The default
Login
.
admin
3. Once logged in properly, a page similar to the one below displays.
VIEW Certified Configuration Guide
Recover-
and
User Name Password
PN: 1725-36192-001_H
