FL IL 24 BK ETH/IP-PAC
Inline Ethernet/IP Bus Coupler
AUTOMATIONWORX
Data Sheet
Description
ETHERNET/IP bus coupler for Inline, 24 V DC, complete
Ethernet 10/100TX capability with accessories (connector
and labeling field).
Inline Features
–
Up to 63 additional Inline modules can be connected
(process data channel)
–
Up to 8 PCP modules
–
Local LEDs and two digit diagnostics display
–
Local indication of network communications loss
–
Field installable with no software required for automatic
station configuration
–
COS and Latching inputs functions
–
Status History Diagnostic Log
–
Reservation of I/O memory for future expansion (No
hardware needed)
–
I/O and Station Status via XML polling
For additional information, please refer to the UM EN FL IL 24 BK ETH/IP-PAC,
Ord.-No. 28 88 02 6 User Manual.
Ensure that you are always working with the most recently published documentation.
It can be downloaded at www.download.phoenixcontact.com.
A conversion table is available on the Internet at
www.download.phoenixcontact.com/general/7000_en_00.pdf.
This data sheet is valid for all products listed on the following page:
PHOENIX CONTACT GmbH & Co. KG • Flachsmarktstraße 8 • 32825 Blomberg • Germany
7201_en_00
Phone: +49-(0) 5235-3-00 • Fax: +49-(0) 5235-3-4 12 00 • www.phoenixcontact.com
DOWNLOADED FROM WWW.SCATTS.CO.UK
© PHOENIX CONTACT - 06/2005
Ethernet & CIP Features
–
Device Profile Type: 0x0C Communications Adapter
–
Total CIP connections supported: 128 (eight typical)
–
Explicit Messaging: Target Max# of connections 128
(eight typical)
–
I/O Messaging: Target Max# of connections 128 (eight
typical)
–
Device configuration options: EDS, Custom Software
–
MAC Parameter Configuration:
Speed: 10Mbps, 100Mbps, Auto
Duplex: Half, Full, Auto
–
IP Address Configuration: BootP, Custom Software,
and SNMP.
–
IP Address Configuration: BootP, Custom Software,
and SNMP.
www.phoenixcontact.com/salesnetwork
DOWNLOADED FROM WWW.SCATTS.CO.UK
U S
U M
U L
A C
t
s e
d
P - P
e
t
R e
s
H / I
e
t
e
c
- E T
n
a
8 6
m
r
B K
3 9
o
f
n
D
2 4
8 6
o
C
M O
. : 2
I L
N o
F L
d . -
O r
T
N E
0
1 0
. 7 6
. A 1
. 5 0
T
. 4 5
X M
A 0
0 0 .
V
R C
K
L N
0
/ 1 0
1 0
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Phoenix Contact FL IL 24 BK ETH/IP-PAC
Summary of Contents for Phoenix Contact FL IL 24 BK ETH/IP-PAC
- Page 1 – I/O and Station Status via XML polling For additional information, please refer to the UM EN FL IL 24 BK ETH/IP-PAC, Ord.-No. 28 88 02 6 User Manual. Ensure that you are always working with the most recently published documentation.
- Page 2 DOWNLOADED FROM WWW.SCATTS.CO.UK FL IL 24 BK ETH/IP-PAC Structure of the FL IL 24 BK ETH/IP-PAC Bus Coupler P - P H / I - E T te st an ce fo rm co n . : 2 d . - .
- Page 3 DOWNLOADED FROM WWW.SCATTS.CO.UK FL IL 24 BK ETH/IP-PAC Connecting the Supply Voltage The module is operated using a +24 V DC SELV. Typical Connection of the Supply Voltage FL IL 24 BK-ETH/IP-PAC RESET Ord.-No.: 2863986 Internal jumper conformance tested (in the module)
- Page 4 DOWNLOADED FROM WWW.SCATTS.CO.UK FL IL 24 BK ETH/IP-PAC Connector Assignment Terminal Assignment/Power Connector Wire Color/Remark Point/ Connector 24 V DC 24 V segment supply The supplied voltage is directly led to the potential jumper. 24 V DC 24 V supply The communications power for the bus coupler and the connected local bus devices is generated from this power.
- Page 5 End Clamp/CLIPFIX Mount end clamps on both sides of the Inline station. The Phoenix Contact recommends using the CLIPFIX 35 (Or- end clamps ensure that the Inline station is correctly as- der No. 30 22 21 8) or E/UK end clamps (Order No. 12 01 sembled.
- Page 6 DOWNLOADED FROM WWW.SCATTS.CO.UK FL IL 24 BK ETH/IP-PAC Mounting When mounting a module, proceed as follows (Figure 3): • First snap on the electronics base, which is required for mounting the station, perpendicular to the DIN rail (de- tail A).
- Page 7 DOWNLOADED FROM WWW.SCATTS.CO.UK FL IL 24 BK ETH/IP-PAC 6138A015 Figure 3 Snapping on a module Replacing a Module If you want to replace a module within the Inline station, fol- First, insert the base of the new module. Then reconnect all low the removal procedure described above.
-
Page 8: Ethernet/Ip Object Classes
Interface, Inline Module, Inline Special Function, PCP Spe- Analog Input Points (AIP) and Analog Output Points (AOP). cial Function and Serial Communication objects. CIP Class Services The FL IL 24 BK ETH/IP-PAC supports the following class services and instance services: Service Code Service Name... - Page 9 DOWNLOADED FROM WWW.SCATTS.CO.UK FL IL 24 BK ETH/IP-PAC CIP Object Classes The FL IL 24 BK ETH/IP-PAC supports the following CIP object classes: Class Code Object Type 01 (0x01) Identity 02 (0x02) Router 04 (0x04) Assembly 05 (0x05) Connection Object...
-
Page 10: Technical Data
DOWNLOADED FROM WWW.SCATTS.CO.UK FL IL 24 BK ETH/IP-PAC Technical Data General Data Function Ethernet/IP bus coupler Housing dimensions (width x height x depth) 90 mm x 116 mm x 72 mm Permissible operating temperature (EN 60204-1) 0°C to 55°C Permissible storage temperature (EN 60204-1) -25°C to 85°C... - Page 11 DOWNLOADED FROM WWW.SCATTS.CO.UK FL IL 24 BK ETH/IP-PAC 24 V Main Supply/24 V Segment Supply Connection method Spring-cage terminals Recommended cable lengths 30 m, maximum; do not route cable through outdoor areas Voltage continuation Through potential routing Special demands on the voltage supply...
- Page 12 DOWNLOADED FROM WWW.SCATTS.CO.UK FL IL 24 BK ETH/IP-PAC 24 V Bus Coupler Supply (Continued) Observe the current consumption of the modules Observe the logic current consumption of each device when configuring an Inline station. This information is given in every module-specific data sheet. The current consumption can differ depending on the individ- ual module.
- Page 13 DOWNLOADED FROM WWW.SCATTS.CO.UK FL IL 24 BK ETH/IP-PAC Derating of the Communications Power and the Analog Terminal Supply P [%] Loading capacity of the power supply unit for communications power and analog supply in % [°C] Ambient temperature in °C...
- Page 14 DOWNLOADED FROM WWW.SCATTS.CO.UK FL IL 24 BK ETH/IP-PAC Power Dissipation/Derating Using the maximum currents 2 A (logic current) and 0.5 A (current for analog terminals) in the formula to calculate the power dissipation when the I/O is connected gives the following result: = 2.2 W + 0.35 W = 2.55 W...
- Page 15 DOWNLOADED FROM WWW.SCATTS.CO.UK FL IL 24 BK ETH/IP-PAC Bus Interface of the Lower-Level System Bus Interface Inline local bus Electrical isolation Number of Inline terminals that can be connected Limited by software 63, maximum Limited by power supply unit Maximum logic current consumption of the connected local ≤...
-
Page 16: Ordering Data
DOWNLOADED FROM WWW.SCATTS.CO.UK FL IL 24 BK ETH/IP-PAC Conformance With EMC Directives Developed according to IEC 61000-6.2 IEC 61000-4-2 (ESD) Criterion B 6 kV contact discharge 6 kV air discharge (without labeling field) 8 kV air discharge (with labeling field in place) - Page 17 28 31 04 4 Documentation Description Type Order No. User Manual FL IL 24 BK ETH/IP-PAC UM EN FL IL 24 BK ETH/IP-PAC 28 88 02 6 "Configuring and Installing the INTERBUS Inline Product Range" user IB IL SYS PRO UM E...
