- Page 1 Large 6 Door LOCKER ADI629-206-SERIES U S ER G UI DE...
- Page 2 Thank you for your purchase. AdirOffice maintains a strong practice of ongoing development of products and commercial research. We understand starting and maintaining a business is expensive enough. We can help make it cost effective and beautiful. Plus, our expert team makes sure...
- Page 3 Table of Contents Introduction Parts Hardware Assembly Instructions Installation Instructions Warranty...
- Page 4 Introduction The AdirOffice Large 6 Door Locker is designed to provide storage and security for your home or office. The lockers are conveniently designed so that they can be installed with multiple units if desired. Single unit Multiple units Use a single, standalone unit.
- Page 5 Parts A. Left Panel E. Top Panel B. Back Panel F. Middle Panel C. Right Panel G. Bottom Panel D. Door Panel NOTE: • When installing the Top Panel, you will only need to screw in the two corner screw holes.
- Page 6 Hardware The AdirOffice Large 6 Door Locker is designed to provide storage and security for your home or office. The lockers are conveniently designed so that they can be installed with multiple units if desired. Round Head Bolts (x4) Washers (x4)
- Page 7 Assembly Instructions Step 1: A. Starting on a flat surface, place the Left Panel (A) onto the left side of the Back Panel (B). a. You can build this standing up, but, it is easier and safer to begin this process by building the locker lying down.
- Page 8 Step 2: A. Place the Right Panel (C) onto the right side of the Back Panel (B). B. Line it up so the “C” shape of the Right Panel (C) hooks under the “L” shape of the Back Panel (B), as described in Step 1. C.
- Page 9 Step 3: A. To attach the Door Panel (D), move the panel into the locker at an angle so that it is completely inside of the enclosure. B. There is a pocket located at the top and bottom of each side panels into which the Door Panel (D) should insert.
- Page 10 Step 4: A. Once the Door Panel (D) is attached, it is time to secure it by attaching the Top Panel (E), the Middle Panels (F) and the Bottom Panel (G). B. First, stand the structure up if it is laying on the ground. C.
- Page 11 Step 5: A. To install the Middle Panels (F), make sure the sideway ‘H’s” on the edge of the panels are facing forward before installing. B. Place them inside of the cubbies, starting with the first, on an angle. C. Push down firmly so that the sides catch on the tracks located on each of the side panels.
- Page 12 Step 6: A. Attach the Double Hooks (6) to the Back Panel (B) of each cubby. B. Insert two Round Head Screws (4) into each Double Hook (6) and secure using a Philips head screwdriver.
- Page 13 Installation Instructions Multiple Locker Units A. If you are using multiple locker units, secure them to each other for safety and security. B. Set the lockers next to each other. Ensure the mounting holes towards the top of the Right Panel (C) of the left locker line up with the corresponding mounting holes on the Left Panel (A) of the right locker.
- Page 14 Mounting Locker Units A. There are two holes near the top of the Back Panel (B) of your locker. B. Place your locker where you want to install it. Using a pencil, mark the location of each of these holes on the wall. C.
- Page 15 Warranty Adir Corp (the “Company” or “Tiger Companies”) warrants to the purchaser that the product will be free from defects in workmanship and materials for a period of 1 year from the date of purchase. The warranty period is not extended if we repair, replace, exchange, or provide a refund for the product (as determined in our sole discretion).
