- Page 1 CHAIR & TABLE COMBO CART ASSEMBLY INSTRUCTIONS www.adiroffice.com cs@adiroffice.com © 2020...
-
Page 2: Getting Started
GETTING STARTED Thank you for selecting the Chair & Table Combo Cart! We are confident the quality and construction of this product will provide years of secure, maintenance-free service for your organization. This prod uct is made of strong, powder-coated, steel tubing. The cart can safely-carry up 42 folding chairs and 12 folding tables and comes with swivel caster wheels. - Page 3 UPPER RAIL MID RAIL � � UPRIGHT BASE RAIL CHAIR HANGER (llt/J � � � � TABLE SUPPORT CASTER WHEELS LOCK CASTER WHEELS nnnnn ''''''' ''''''' iiiiiii nnnnn ''''''' iiiiiii ''''''' iiiiiii LONG SCREW MEDIUM SCREW SMALL SCREW (MB X 50) (MB X 25) (MB X 20) ©©...
- Page 4 COMPONENTS 1. Upright 2. Chair Hanger 3. Handle 4. Upper Rail 5. Mid Rail 6. Base Rail 7. Handle 8. Table Support 9 .Caster Wheel 10. Locking Caster Wheel 11. Bungees UPPER RAIL CHAIR HANGERS UPRIGHT Bungees MID RAIL HANDLE MID RAIL CASTOR WHEEL...
- Page 5 ASSEMBLING THE CART Tools Needed: Screw driver Wrench STEP ONE Insert each chair hanger onto the upper rail by aligning the holes. Insert large screws with nuts and washers into the holes to lock down the chair hangers. CHAIR HANGER �...
- Page 6 STEP TWO Align mid rail holes on each end with four holes on each upright. Align base rails between upright and mid rails. Insert medium screws into mid rail with base rail connection. Insert small screws with nuts and washers into the holes to lock down the other mid rail. UPRIGHT UPRIGHT SMALL...
- Page 7 STEP THREE Align upper rail holes on each end with two holes on each upright. Insert small screws with nuts and washers into the holes to lock down the upper rail.Ok SMALL SCREW u, STEP FOUR Align hole in table support with base rails and castor wheels. Insert nuts and washers on castor wheels to lock wheels onto base rails.
- Page 8 STEP FIVE Align mid rail holes with Brace hole Insert small screws with nuts and washers into the holes to lock down the Brace...
-
Page 9: Using The Cart
USING THE CART • Install tables onto the cart first. Be sure to stack them between the upright and the table supports. • Secure the tables onto the cart by hooking the bungees into the table supports and stretching over the tables. -
Page 10: Care And Maintenance
• Occasionally check castor wheels and replace and oil if necessary. LIMITED WARRANTY 1. ADIRoffice (the "Company") warrants to the original consumer (the "Purchaser') of any safe it sells against any damage caused by attempted burglary for a period of five (5) years from the date of pur... - Page 11 God. Our products are only a DETERRENT to such acts. ADIRoffice will always do its utmost to stay current on the prevention of theft and burglary and will continue to offer the best products possible to help in the prevention of such crimes.
