- Page 1 Small Kids Locker ADI629-02-SERIES USER GUIDE...
- Page 2 Thank you for your purchase. AdirOffice has a commitment to deliver quality and stylish office furniture and equipment. We understand starting and maintaining a business is expensive enough. We can help you make it cost effective and beautiful. Plus, our expert team...
-
Page 3: Table Of Contents
Table of Contents Parts List Assembly Instructions Mounting Instructions 10 Notes 11 Limited Warranty 12 Disclaimer... - Page 4 Parts Included PARTS Check your package and your carton should contain all items shown in the parts list below - if not, consult the retailer who sold you the product. Front Leg (5) Door (1) Left Side Back Right Side Back Leg (6) Panel (2) Panel (3)
-
Page 5: Assembly Instructions
Assembly Instructions STEP 1: Turn the Left Side Panel (2) and the Right-Side Panel (4) upside-down. Insert the Back Leg (6) into the shorter holes of both side panels, apply pressure. Insert the Front Leg (5) into the deeper slots and apply pressure. - Page 6 Assembly Instructions STEP 2: Flip the locker to the upright position and align the Back Panel (3) between Left Side Panel (2) and the Right-Side Panel (4).
- Page 7 Assembly Instructions STEP 3: Insert the Top Panel (7) onto the locker. Ensure that the locker’s edges are aligned with the lips found underneath the Top Panel (7). Push the top portion into place by applying some pressure. Make sure all edges snap in firmly.
- Page 8 Assembly Instructions STEP 4: Insert the Plastic Hinge Bush (I) in the hole on the bottom right of the locker’s Front Leg (5). Insert the Small Hinge Pin (F) in the hole on top of the locker door (See Figure 1 on the next page). Insert the Small Hinge Pin (F) with the Door (1) in the hole located under the right side of the Top Panel (7).
- Page 9 Assembly Instructions...
- Page 10 Assembly Instructions STEP 5: Insert the Base (8) into the locker by pressing down with edges pointing down and the smooth side up. STEP 6: Attach the Double Hook (A) with the Small Screws (C).
- Page 11 Assembly Instructions STEP 7: Insert the two Rubber Buffer’s (H) in the top and bottom corners of the Door (1), as shown.
-
Page 12: Mounting Instructions
Mounting the locker unit(s) to the wall There are two holes near the top of the back panel of your Mounting Instructions locker. Place your locker where you want to install it. Using a pencil, mark the location of each of these holes on the wall. STEP 1: Remove the locker(s) from the wall. -
Page 13: Notes
Notes... -
Page 14: Limited Warranty
Limited Warranty 1. AdirCorp (the company) warrants to the purchaser that the product will be free from defects in workmanship and materials for a period of one (1) year from the date of purchase. 2. These warranties are not assignable or transferable to any other person. 3. -
Page 15: Disclaimer
Disclaimer By purchasing products from AdirCorp, user agrees as follows: TO THE MAXIMUM EXTENT PERMITTED BY LAW, THE PRODUCTS AND INFORMATION ON THIS SITE IS PROVIDED “AS IS” AND WITH ALL FAULTS AND ADIRCORP. MAKES NO PROMISES, REPRESENTATIONS, OR WARRANTIES, EITHER EXPRESS, IMPLIED, STATUTORY, OR OTHERWISE, WITH RESPECT TO THE PRODUCTS AND INFORMATION, INCLUDING ITS CONDITION, ITS CONFORMITY TO ANY REPRESENTATION OR DESCRIPTION, OR THE EXISTENCE OF ANY LATENT OR PATENT DEFECTS, AND ADIRCORP. - Page 16 Item Number: ADI629-02-SERIES 64 Mountainview Blvd. • Wayne, NJ • 07470 • ©2021 All Rights Reserved. adircorp.com...
