- Page 1 EXPANDABLE MOBILE PLAN CENTER FOR BLUEPRINTS USER G UIDE ADI615-SERIES...
- Page 2 Thank you for your purchase. AdirOffice maintains a strong practice of ongoing development of products and commercial research. We understand starting and maintaining a business is expensive enough. We can help you make it cost effective and beautiful. Plus, our expert team makes sure everything you need works as...
-
Page 3: Table Of Contents
Table of Contents Parts List Hardware List Assembly Instructions Warranty Notes... -
Page 4: Parts List
Parts List Side Bar (x2) Sliding Bars (x2) (Preinstalled) L Bars (x2) -
Page 5: Hardware List
Hardware List Locking Caster (x2) Caster (x2) Long Screw (x6) Acorn Nut (x4) Knob Bolt (x2) Wing Nut (x2) Tools Required: • Wrench... -
Page 6: Assembly Instructions
Assembly Instructions Step 1: A. Insert the two Locking Casters (1) and Casters (2) into the bottom of both Side Bars (A). a. Ensure you insert the casters into the side of the Side Bars (A) with larger, threaded holes. - Page 7 Step 2: A. Attach both L-Bars (C) together, as shown below, by inserting two Knob Bolts (5) through both bars. a. Note: Adjust the L-Bars (C) according to the size of your files before inserting the Knob Bolts (5). B. Secure two Wing Nuts (6) to both Knob Bolts (5).
- Page 8 Step 3: A. Attach the Side Bars (A) to L Bars (C), according to the picture. a. Ensure the upper holes of Side Bars (A) face inwards. B. Insert four Long Screws (3) into the upper two holes on the Side Bars (A) through the L Bars (C).
- Page 9 Step 4: A. Your Expandable Mobile Plan Center is now ready to be used.
-
Page 10: Warranty
Warranty Adir Corp (the “Company” or “Tiger Companies”) warrants to the purchaser that the product will be free from defects in workmanship and materials for a period of 1 year from the date of purchase. The warranty period is not extended if we repair, replace, exchange, or provide a refund for the product (as determined in our sole discretion). -
Page 11: Notes
Notes... - Page 12 ADI615-SERIES © 2023 Adir Corp adircorp.com...
