Resolute™ RT
Special Attention Flags
Please pay particular attention to the following flags when you see them throughout this manual.
DANGER:
Notifies you of hazards that WILL cause severe personal injury, death or substantial property
damage.
WARNING:
Notifies you of hazards that CAN cause severe personal injury, death or substantial property
damage.
CAUTION:
Notifies you of hazards that WILL or CAN cause minor personal injury or property damage.
NOTICE:
Notifies you of special instructions on installation, operation, or maintenance that are important, but
not normally related to injury or property damage hazards.
BEST PRACTICE:
Notifies you of recommendations made by Energy Kinetics for the installers, which will help ensure
optimum operation and longevity of the equipment.
WARNING:
Energy Kinetics Inc. ● 51 Molasses Hill Road ● Lebanon, NJ 08833 ● 800-323-2066 ● www.energykinetics.com ● June 2023
&
Boilers Gas & Oil
Please Read This First
If you do not follow these instructions exactly, a fire or explosion
may result causing property damage, personal injury or loss of life.
Smart Vent with Dilution Air
Installation Instructions
Ascent™ Plus Combi
Page 1 of 18
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ENERGY KINETICS Resolute RT
Summary of Contents for ENERGY KINETICS Resolute RT
- Page 1 If you do not follow these instructions exactly, a fire or explosion WARNING: may result causing property damage, personal injury or loss of life. Energy Kinetics Inc. ● 51 Molasses Hill Road ● Lebanon, NJ 08833 ● 800-323-2066 ● www.energykinetics.com ● June 2023 Page 1 of 18...
- Page 2 Energy Kinetics does not allow the use of PVC pipe for flue gas venting due to the fact that PVC pipe starts to soften and lose its shape at about 150°F. Energy Kinetics boiler supply temperatures can reach up to 210°F, which can allow flue gas temperatures to exceed this temperature limit of PVC.
- Page 3 SEE PAGE 5 OF THIS MANUAL FOR INSTRUCTIONS Dilution Air Exhaust Fan (Inducer) Blocked Vent Safety Switch Sealed Air Box Energy Kinetics Inc. ● 51 Molasses Hill Road ● Lebanon, NJ 08833 ● 800-323-2066 ● www.energykinetics.com ● June 2023 Page 3 of 18...
- Page 4 Resolute RT and Ascent Plus Gas and Oil Boiler Smart Vent Guidelines Installation of the Resolute RT and Ascent Plus boiler Smart Vent with dilution air system must follow these important guidelines: ...
- Page 5 Do not install in longer runs. Install the restrictor in the outlet of the first elbow downstream from the inducer fan (A). Energy Kinetics Inc. ● 51 Molasses Hill Road ● Lebanon, NJ 08833 ● 800-323-2066 ● www.energykinetics.com ● June 2023 Page 5 of 18...
- Page 6 SEE PAGE 5 OF THIS MANUAL FOR INSTRUCTIONS PP TEE PP CAP HYDRAULIC TRAP CONDENSATE COLLECTOR (GAS ONLY) Energy Kinetics Inc. ● 51 Molasses Hill Road ● Lebanon, NJ 08833 ● 800-323-2066 ● www.energykinetics.com ● June 2023 Page 6 of 18...
- Page 7 Note that the Energy Kinetics Smart Vent with Dilution Air System, when properly installed on an Energy Kinetics Resolute RT or Ascent Plus Combi boiler meets the definition of a ‘direct vent appliance’ as used in NFPA 31 & NFPA 54.
- Page 8 Energy Kinetics Inc. ● 51 Molasses Hill Road ● Lebanon, NJ 08833 ● 800-323-2066 ● www.energykinetics.com ● June 2023 Page 8 of 18...
- Page 9 50 equivalent feet, for a maximum of 50 ft. – 25 ft. = 25 feet of straight pipe allowed. Energy Kinetics Inc. ● 51 Molasses Hill Road ● Lebanon, NJ 08833 ● 800-323-2066 ● www.energykinetics.com ● June 2023 Page 9 of 18...
- Page 10 50 equivalent feet, for a maximum of 50 ft. – 25 ft. = 25 feet of straight pipe allowed. Energy Kinetics Inc. ● 51 Molasses Hill Road ● Lebanon, NJ 08833 ● 800-323-2066 ● www.energykinetics.com ● June 2023 Page 10 of 18...
- Page 11 Do not install in longer runs. SEE PAGE 5 OF THIS MANUAL FOR INSTRUCTIONS Energy Kinetics Inc. ● 51 Molasses Hill Road ● Lebanon, NJ 08833 ● 800-323-2066 ● www.energykinetics.com ● June 2023 Page 11 of 18...
- Page 12 Centrotherm Polypropylene venting can be terminated using a” low profile wall termination” kit. The 3” kit is required for the Resolute RT or Ascent Plus boiler. The vent must use 3” polypropylene. The air inlet can use either polypropylene or 3”...
- Page 13 It may additionally cause air flow in the chimney chase which could cause condensation or freezing conditions in the vent flex line. Energy Kinetics Inc. ● 51 Molasses Hill Road ● Lebanon, NJ 08833 ● 800-323-2066 ● www.energykinetics.com ● June 2023 Page 13 of 18...
- Page 14 Do not install in longer runs. SEE PAGE 5 OF THIS MANUAL FOR INSTRUCTIONS Energy Kinetics Inc. ● 51 Molasses Hill Road ● Lebanon, NJ 08833 ● 800-323-2066 ● www.energykinetics.com ● June 2023 Page 14 of 18...
- Page 15 Unblock the air inlet piping and verify that the burner operates normally. Energy Kinetics Inc. ● 51 Molasses Hill Road ● Lebanon, NJ 08833 ● 800-323-2066 ● www.energykinetics.com ● June 2023 Page 15 of 18...
- Page 16 Remove all foreign material before operating. Installed By: Company: Date: Installed For: Address: Energy Kinetics Inc. ● 51 Molasses Hill Road ● Lebanon, NJ 08833 ● 800-323-2066 ● www.energykinetics.com ● June 2023 Page 16 of 18...
- Page 17 Remove all foreign material before operating. Installed By: Company: Date: Installed For: Address: Energy Kinetics Inc. ● 51 Molasses Hill Road ● Lebanon, NJ 08833 ● 800-323-2066 ● www.energykinetics.com ● June 2023 Page 17 of 18...
- Page 18 Have any questions? Call 1-800-323-2066 And ask for Technical Support Or check out the website: WWW.ENERGYKINETICS.COM Energy Kinetics Inc. ● 51 Molasses Hill Road ● Lebanon, NJ 08833 ● 800-323-2066 ● www.energykinetics.com ● June 2023 Page 18 of 18...
