Fuente de alimentación, otros elementos

Potencia de funcionamiento: adaptador de CA (AD-A12200L)

4 pilas alcalinas de tamaño AA (disponible

separadamente)

Consumo de energía:

9 W

Apagado automático:

aproximadamente 6 minutos cuando se utiliza el

adaptador de CA.

aproximadamente 30 segundos cuando se utilizan las

pilas.

Precisión del reloj:

±3 segundos por día

(temperatura normal: 15°C a 35°C)

Vida útil de la pila incorporada al reloj:

aproximadamente 8 años

• Las indicaciones incorrectas del año, mes, día y/u

hora indican por lo general que la pila incorporada

al reloj está baja. Solicite el reemplazo de la pila a su

vendedor o al centro de servicio CASIO local. (Se le

cobrará por el reemplazo.)

Dimensiones:

119 mm (An) × 146 mm (Pr) × 67 mm (Al)

(incluida la pata de caucho)

Peso:

aproximadamente 375 g

(incluyendo el lápiz, excluyendo las pilas)

Temperatura de funcionamiento:

10°C a 35°C

Lista de accesorios opcionales

● Cinta

Ancho de la

cinta

18 mm

Color de la cinta

Blanco

XA-18WE1

XA-12WE1

Amarillo

XA-18YW1

XA-12YW1

Rosa

XA-18PK1

XA-12PK1

• Algunos elementos pueden estar agotados.

• Los accesorios opcionales están sujetos a cambios sin previo aviso.

Be sure to read the User's Guide that comes with this printer before using it, and ensure

that you handle it properly.

Read this ﬁ rst!

■ This manual covers the MEP-T10 printer only.

For information about using the software that comes with it, refer to the software user

documentation, which is provided as a PDF ﬁ le on the CD-ROM.

■ The contents of this manual have been checked at each step of the production process.

Feel free to contact us if you notice anything that is questionable, erroneous, etc.

■ CASIO COMPUTER CO., LTD. shall not be held liable for any damages or losses

suffered by you or any third party due to the use or malfunction of this product.

■ CASIO COMPUTER CO., LTD. shall not be held liable for any damages or losses

caused by loss of memory contents due to malfunction, repair, or any other reason.

■ The contents of this manual are subject to change without notice.

■ Note that the example printouts and the screen shots shown in this manual may differ

somewhat from the printing and screen images actually produced by the printer.

■ All of the screen shows in this manual use the "English" language setting. Screen

contents will be different when another language setting is used.

Safety Precautions

Thank you for purchasing this product. Before using it, be sure to read the Safety

Precautions contained in this User's Guide. Keep this manual handy in a safe place for

future reference when required.

Danger

This symbol indicates information that, if ignored or applied incorrectly, creates the

danger of death or serious personal injury.

Warning

This symbol indicates information that, if ignored or applied incorrectly, creates the

possibility of death or serious personal injury.

Caution

This symbol indicates information that, if ignored or applied incorrectly, creates the risk of

personal injury or material damage.

Examples of other markings

Indicates something you should not do. The symbol shown here indicates you

should not try to take something apart.

Indicates something you must do.

12 mm

9 mm

XA-9WE1

XA-9YW1

XA-9PK1

Important!

The copyright of this manual and rights related to the

software all revert to CASIO COMPUTER CO., LTD.

The following terms are registered trademarks or trademarks of their respective owners.

• Microsoft, Windows, and Windows Vista are registered trademarks or trademarks of

Microsoft Corporation in the United States and other countries.

• Adobe, Reader, and Acrobat are trademarks of Adobe Systems Incorporated.

Other company or product names used herein are trademarks or registered trademarks

of their respective companies. Note that TM and ® marks are not used within the text of

this manual.

Except as required for proper use or for creating backup copy, any reproduction of this

manual and/or the program, either in part or in their entirety, is strictly prohibited without

the express written permission of CASIO COMPUTER CO., LTD.

Danger

Batteries

Should liquid from a battery ever get into your eyes, take the following steps.

1. Immediately rinse your eyes with clean water, without rubbing.

2. Contact a physician as soon as possible.

Failure to clean alkaline battery ﬂ uid from the eyes creates the risk of loss of sight.

Warning

Smoke, abnormal odor, overheating, and other abnormalities

Do not continue to use the printer while it is emitting smoke or strange odor, or

generating heat.

Continued use of the printer creates the risk of ﬁ re and electric shock. Immediately

perform the following steps whenever any of the above symptoms are present.

1. Disconnect the USB cable.

2. Unplug the AC adaptor from the wall outlet.

3. If there are batteries loaded in the printer, remove them.

4. Contact your original retailer.

AC Adaptor

Misuse of the optional AC adaptor creates the risk of ﬁ re and electric shock.

Make sure you observe the following.

• Use only the speciﬁ ed AC adaptor.

• Use only a power source that is within the input voltage range indicated by INPUT

on the AC adaptor's rating plate.

• Never plug the power cord into a wall outlet that is shared by other devices, or into

a shared extension cord.

AC Adaptor/USB Cable

Misuse of the AC adaptor/USB cable can cause it to become damaged, creating the

risk of ﬁ re and electric shock.

Make sure you observe the following.

• Never place heavy objects on the AC adaptor/USB cable or subject it to direct heat.

• Never try to modify the AC adaptor/USB cable or subject it to bending.

• Do not twist or pull on the AC adaptor/USB cable cord.

• Do not wrap the cord around the adaptor.

• Should the AC adaptor/USB cable or its plug ever become damaged, contact your

original retailer.

• Never touch the AC adaptor/USB cable or plug while your hands are wet. Doing so

creates the risk of electric shock.

• Do not use the AC adapter/USB cable in areas where liquids might spill on them.

Water creates the risk of ﬁ re and electric shock.

• Do not place a ﬂ ower vase or any other liquid container on top of the AC adapter/

USB cable or power cord. Water creates the risk of ﬁ re and electric shock.

• Do not cover the AC adaptor/USB cable with a newspaper, tablecloth, curtain,

futon, blanket, or other similar object. Doing so creates the risk of ﬁ re.

MEP-T10_ES
