OUTDOOR PROPANE FIREPIT
OWNER'S MANUAL
Item
#: FP10408 / FP10409
Model #: KLD4004B
DANGER
If you smell gas:
1. Shut off gas to the appliance
2. Extinguish any open flame
3. If odor continues, immediately
call gas supplier.
DANGER
Do not store or use gasoline or
other flammable vapors or liquids
in the vicinity of this or any other
appliance.
®
Heat Max output: 60,000BTU
5 0 0 0 1 9 9
WARN
For outdoor use only.
WARN
PLEASE retain this manual for
future reference.
WARN
Do not handle firepit until fully
cooled (allow 30 minutes).
Do not put lid on firepit until fully
cooled (allow 30 minutes).
Do not use in heavy winds.
Conforms to ANSI
STD Z21.97-2017
Certified to CSA
STD 2.41-2017
Advertisement
Table of Contents
Related Manuals for Paramount Fitness KLD4004B
Summary of Contents for Paramount Fitness KLD4004B
- Page 1 ® OUTDOOR PROPANE FIREPIT OWNER’S MANUAL Heat Max output: 60,000BTU Item #: FP10408 / FP10409 Model #: KLD4004B Conforms to ANSI STD Z21.97-2017 Certified to CSA STD 2.41-2017 5 0 0 0 1 9 9 DANGER WARN If you smell gas: For outdoor use only.
-
Page 2: Safety Information
SAFETY INFORMATION ® DANGER DANGER DANGER WARN DANGER... -
Page 3: Burn Hazard
® SAFETY INFORMATION WARNING WARNING California Proposition 65 Combustion by-products produced when using is invisible, odorless, and flammable. An odorant is this product contain chemicals known to the State normally added to help detect leaks and can be of California to cause cancer, birth defects, and described as a rotten egg smell. -
Page 4: Package Contents
PACKAGE CONTENTS ® Part No. Description Quantity Lava Rock Fire pit Foot pad Cylinder holder Strap... - Page 5 ASSEMB LY INSTRUCTIONS ® 1. Assemble foot pads(D). 2. Place lava rocks carefully around burner ring to avoid dust. Do not completely cover the fire ring or igniter guard. Do not place fire beads or Guard lava rocks in this area. Keep this area clear.
- Page 6 ASSEMB LY INSTRUCTIONS ® 3. Connect the hose and regulator to the cylinder. Put cylinder on the cylinder stand.Use a standard 20 lb. propane cylinder only. Use this fire pit only with a propane vapor withdrawal supply system. See Chapter 5 of the standard for storage and handling of liquefied petroleum gas, ANSI/NFPA 58.
- Page 7 ASSEMBLY INSTRUCTIONS ® A dented , rusted or damaged propane cylinder may be hazardous and should be checked by your cylinder supplier. Never use a p ropane cylinder with a damaged valve connection. The propane cylinder must be constructed and ma rked in accordance with the specifications for LP gas cylinders of the U.S.
- Page 8 OPRATION INSTRUCTIONS ® Leak Test WARNING ·Perform all leak tests outdoors. ·Extinguish all open flames. ·NEVER perform a leak test when smoking. ·Do not use the fire pit until all connections have beenleak tested and do not leak. Hose /Regulator Regulator/Cylinder connection connection...
- Page 9 OPERATION INSTRUCTIONS ® DANGER WARNING Very hot while in a operation! ·CARBON MONOXIDE HAZARD Never lean over the fire pit while in use. ·For outdoor use only.Never use inside house,or Do not touch surfaces while the fire pit is in othe runventilated or enclosed areas.This fire pit operation, wait until the fire pit has cooled down consumes air(oxygen).
-
Page 10: Shutdown Instructions
OPERATION INSTRUCTIONS ® SHUTDOWN INSTRUCTIONS 1. Turn valve on propane cylinder to “CLOSE” position. 2. Wait for flame to visibly extinguish. 3. Turn valve on unit to “OFF” position Do not use this appliance under overhead combustible surfaces. WARNING FOR YOUR SAFETY Be careful when attempting to manually ignite this fire pit. -
Page 11: After Operation
OPERATION INSTRUCTIONS ® 9. Firepit is away from gasoline or other flammable liquids or vapors. 10. Firepit is away from windows, air intake openings, sprinklers and other water sources. 11. Firepit is at least 24 in. on rear and at least 24 in. on sides from combustible materials. 12. -
Page 12: During Periods Of Extended Inactivity Or When Transporting
CARE AND MAINTENANCE ® Gas odor with extreme yellow tipping of flame. ・ Fire pit does NOT reach the desired temperature. ・ Fire pit glow is excessively uneven. ・ Fire pit makes popping noises. ・ Spiders and insects can nest in burner or orifices.This dangerous condition can damage fire pit ・... -
Page 13: Troubleshooting
TROUBLESHOOTING ® PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Wait until the propane cylinder comes Propane cylinder is frosted over unfrosted Burner not light Clear blockage Control knob is not in ON position Turn control knob to ON Gas pressure is lo Turn cylinder valve OFF and replace cylinder Outdoor temperature is less than Use a full cylinder... -
Page 14: Warranty
IMPORTANT For questions, concerns or problems with our product please Si vous éprouvez si vous avez des questions ou des email our customer service department: préoccupations, prière de faire parvenir un courriel à notre service à la clientèle customercare@jrhome.com customercare@jrhome.com DATED PROOF OF PURCHASE REQUIRED FOR WARRANTY SERVICE UNE PREUVE D’ACHAT DATÉE EST REQUISE POUR SE PRÉVALOIR DE LA GARANTIE.
