- Page 1 M082 User Manual M082 Hardware User Manual Product Version: 1.0 Date: 2023-9-21 For any question, please contact Chengdu Vantron Technology, Ltd. Copyright © Vantron Technology, Ltd. All rights reserved.
-
Page 2: Change History
Change History This table describes the version and release date. Rev. Date Description Author 2023-9-21 First release. Shun Zhang... -
Page 3: Symbol Conventions
Please contact our technical department for relevant operation solutions if there is any problem that cannot be solved according to this manual. Vantron reserves all rights of this manual, including the right to change the content, form, product features, and specifications contained herein at any time without prior written notice. -
Page 4: Limitation Of Liability/Non-Warranty
Limitation of Liability/Non-warranty For direct or indirect damage to this device or other devices of Vantron caused by failure of conforming to this manual or the safety instructions on device label, Vantron assumes neither warranty nor legal liability even if the device is still under warranty. -
Page 5: Safety Instructions For Power Cables And Accessories
Use Proper power source only. Start only with power source that satisfies voltage label and the voltage necessary according to this manual. Please contact technical support personnel of Vantron for any uncertainty about the requirements of necessary power source. Use tested power source. This product still contains a button lithium battery as a real-time clock after its external power source is removed and therefore should not be short-circuited during transportation or placed under high temperature. -
Page 6: Table Of Contents
Contents INTRODUCTION ..............................1 ..............................1 RODUCT ESCRIPTION ............................... 1 ONNECTOR ESCRIPTION OVERVIEW ................................3 ...................................3 NTRODUCTION ....................................3 EATURE ............................... 4 RDER NFORMATION HARDWARE INSTRUCTIONS ......................... 5 ..................................5 PPEARANCE ..................................5 TRUCTURE HARDWARE FUNCTION DESCRIPTION ...................... 6 WIFI/BT ....................................6 ....................................7 UDIO ....................................7 ISPLAY ....................................7 AMERA... - Page 7 6.1.4 Hardware Instructions............................ 12 SOFTWARE INSTRUCTIONS ........................13 TIPS ..................................14 APPENDIX A: HOW TO CONTACT US ......................... 17...
-
Page 9: Introduction
So it is easy to be used by adding your application software only. It can speed Time to Market of your products, and save more cost. Connector Description This table respectively describes the valid signal of connectors on the Vantron board. Not connect Ground... - Page 10 3.3V 3.3 V signal level 5 V signal level 5 V tolerant signal PCIe PCI Express signal, not 3.3 V tolerant No Connection...
-
Page 11: Overview
Overview Introduction M082 is a Ruggedized Tablet computer designed for industrial application. This product is based on RK3566 which has Quad-cores and one of them is Cortex-A55 with a maximum clock frequency of 1.8GHz, supporting 8" LCD and capacity touch screen. -
Page 12: Order Information
Type-C USB power input, support Power input 5V/3A..Support 9V/2A PD Fast Charge. Wireless charge, support 9V/15W by SY65153 Adapter Adapter Type-C 5V/3A or 9V/2A. Power Yellow: Charging Power indicator Red: Low power Green: Charged Battery Single Li-ion battery: 8000mAh/3.8V Mechanical Dimensions 235x153x21mm Operating: -10℃~+60℃... -
Page 13: Hardware Instructions
Hardware Instructions Appearance Figure 3-1 Views BACK Structure Download the board structure document from Vantron technology or Vantron net site: www.vantrontech.com.cn Figure 3-4 Structure Unit: mm... -
Page 14: Hardware Function Description
Hardware Function Description This chapter mainly describes the main hardware functions of this product, including WIFI/BT, Audio, Display, Camera,Battery and Charging and NFC. WIFI/BT The wireless module inside the tablet complies with IEEE 802.11 a/b/g/n/ac standard and it can achieve up to a speed of 433.3 Mbps with single stream in 802.11ac conn-ect to the wireless LAN. -
Page 15: Audio
It also support FM. Display M082 has a 8" screen. The screen is made up of a display screen and a touch screen. More parameters are shown in the table. Item... -
Page 16: Battery And Charging
VGA(640x480):90 fps Battery and Charging M082 has a powerful 8000 mAh battery. The time to play the video, listen to the music and standby is not confirmed. It theoretically supports 5V/3A charging and 9V/2A fast charging.It also supports maximum 15W wireless charging. -
Page 17: Hardware Operation Note
Please confirm the wireless power transfer support QI standard. In order to achieve maximum 15W charging, the wireless power transfer must supports 15W power transfer. Antenna The design of the internal antenna position of M082 will be shown as follows: Figure 5-1 Internal antenna... - Page 18 In order to ensure that the tablet functions can work properly, please do not cover the antenna area with metal shielding devices. Note: WIFI and BT antenna frequency is 2.4G and 5G respectively.
-
Page 19: Parts Description
Parts Description USB Power Adapter 6.1.1 Appearance Figure 6-1 View 6.1.2 Interfaces Figure 6-2 Interfaces US 2 pins plug USB TYPE-A 6.1.3 Structure Figure 6-3 Structure (1) Unit: mm... -
Page 20: Hardware Instructions
Figure 6-4 Structure (2) Unit: mm 6.1.4 Hardware Instructions Specifications Product Name AC/DC ADAPTER MODEL No. MX15U-0503000UU Interface Type USB Type-A ( Female ) Input Parameter 100-240V ~ 50-60 Hz 0.5A Output Parameter 5 VDC 3A Product Dimensions 40 x 24 x 55 mm (Pins are not included ) Operating Temperature 0℃-40℃... -
Page 21: Software Instructions
Software Instructions M082 has been pre-loaded firmware. For more information, please refer to software user manual for software operation. -
Page 22: Tips
In the aim of avoiding accidents as far as possible, it is not allowed to replace the system or change components unless with permission and certification. Please contact the technical department of Vantron or local branches for help. Pay attention to caution signs. - Page 23 Vantron assumes no responsibility of possible missing contents and information, errors in contents, citations, examples, and source programs. Vantron reserves the right to make necessary changes to this manual without prior notice. No part of this manual may be reprinted or publicly released in forms of photocopy, tape, broadcast, e-document, etc.
- Page 24 Operation in the band 5150–5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems. RF exposure information and statement: this device meets government requirements for exposure to radio waves. The guidelines are based on standards that were developed by independent scientific organizations through evaluation of scientific studies.
-
Page 25: Appendix A: How To Contact Us
Address: 440 Boulder Court, Suite 300, Pleasanton, CA 94566, USA Tel: 925-621-8758 Email: sales@vantrontech.com China Office: Chengdu Vantron Technology, Ltd Address: 6th Floor, 1st Building, No.9, 3rd Wu Ke East Street, Wu Hou District, Chengdu 610045, China Tel: 86-28-8512-3930/3931, 8515-7572/6320 Email:...
