Vantron
| Embedded in your success, Embedded in your better life
World-leading provider of embedded/IoT products and solutions
M10 R1-RK35 10" Rugged Industrial Tablet
User Manual
Version: 1.3
© Vantron Technology, Inc. All rights reserved.
Vantron | Public
M10R1-RK35 User Manual
www.vantrontech.com
Advertisement
Table of Contents
Related Manuals for Vantron M10-R1-RK-35
Summary of Contents for Vantron M10-R1-RK-35
- Page 1 | Embedded in your success, Embedded in your better life World-leading provider of embedded/IoT products and solutions M10 R1-RK35 10” Rugged Industrial Tablet User Manual Version: 1.3 © Vantron Technology, Inc. All rights reserved. Vantron | Public M10R1-RK35 User Manual www.vantrontech.com...
-
Page 2: Revision History
Dec. 30, 2023 V1.1 Updated the LCD/Camera description Jan. 4, 2024 V1.2 Updated the use of barcode scanner in Debian system Mar. 8, 2024 V1.3 Updated the pinout of the pogo pin Nov. 15, 2024 Vantron | Public M10R1-RK35 User Manual www.vantrontech.com... -
Page 3: Table Of Contents
Unpacking ......................6 Specifications ......................7 Specifications (Cont’d) ................... 8 Product Layout ...................... 9 Product Outlines ....................12 Vantron VDS10 Docking Station ................12 CHAPTER 2 GETTING STARTED ...................... 13 Setting up the Device ................... 14 2.1.1 Battery ......................... 14 2.1.2 Installing and removing a SIM card/TF card ............ - Page 4 Image Flashing in Ubuntu System ............... 38 4.2.1 Prerequisites ......................38 4.2.2 Image flashing ...................... 38 CHAPTER 5 DISPOSAL AND WARRANTY ..................40 Disposal........................ 41 Warranty ......................42 Appendix Regulatory Compliance Statements ..............43 Vantron | Public M10R1-RK35 User Manual www.vantrontech.com...
-
Page 5: Foreword
• Copyright Vantron Technology, Inc. (“Vantron”) reserves all rights of this manual, including the right to change the content, form, product features, and specifications contained herein at any time without prior notice. An up-to-date version of this manual is available at www.vantrontech.com. -
Page 6: Technical Support And Assistance
• Product name and PO number; Complete description of the problem; • • Error message showing up on the device, if any. Vantron Technology, Inc. Address: 48434 Milmont Drive, Fremont, CA 94538 Tel: (650) 422-3128 Email: sales@vantrontech.com Regulatory Information The Product is designed to comply with: •... -
Page 7: General Safety Instructions
Be sure that nothing rests on the power cable and that the cable is located at a place without risk of trips. Cut off the power before inspection of the Product to avoid human injury or product damage. Vantron | Public M10R1-RK35 User Manual www.vantrontech.com... - Page 8 • Clean with a damp cloth Do not try to clean exposed electronic components unless with a dust collector • Power off and contact Vantron technical support engineer in case of the following faults: The Product is damaged • •...
-
Page 9: Chapter 1 Introduction
Vantron Embedded in your success, Embedded in your better life World-leading provider of embedded/IoT products and solutions CHAPTER 1 INTRODUCTION Vantron | Public M10R1-RK35 User Manual www.vantrontech.com... -
Page 10: Product Overview
World-leading provider of embedded/IoT products and solutions 1.1 Product Overview Vantron M10R1-RK35 is a 10-inch high-performance rugged tablet, designed to handle demanding tasks with ease. It is powered by Rockchip RK3588S octa-core processor, combined with ARM Mali-G610 MP4 GPU and a TOPS NPU for industrial applications such as healthcare, plant walk-down, law enforcement patrol, and prison automation. -
Page 11: Specifications
1 x Gyro-sensor G-Sensor 1 x G-sensor 1 x Power button 3 x Function button Button 1 x Volume +/- button System Control 1 x Battery level LED indicator 1 x Camera working indicator indicator Vantron | Public M10R1-RK35 User Manual www.vantrontech.com... -
Page 12: Specifications (Cont'd)
20%~80% RH (Non-condensing) Environment Condition MIL-STD-810H FCC (FCC Part 15 Class B) Certification ISED, CE ESD (Contact: ±4KV, Air: ±8KV) * Source: Test with 1080p video play at 50% volume and 200 nits brightness. Vantron | Public M10R1-RK35 User Manual www.vantrontech.com... -
Page 13: Product Layout
10-point G + G PCAP touchscreen Long press (about 3 seconds) to turn on/off the device Power button Short press to turn on/off the screen or turn on the device Function button User-defined function buttons Vantron | Public M10R1-RK35 User Manual www.vantrontech.com... - Page 14 Rear camera 8MP, auto focus Speaker 4Ω/2w speaker for audio output Top view ○ ○ Item Description Volume + button Increase the media playing volume Volume - button Decrease the media playing volume Vantron | Public M10R1-RK35 User Manual www.vantrontech.com...
-
Page 15: Bottom View
USB 2.0 Type-A Nano SIM slot Hold a Nano SIM card for cellular communication TF slot Store a TF card for expansion of the storage Audio jack Connect a headphone or external speaker, etc. Vantron | Public M10R1-RK35 User Manual www.vantrontech.com... -
Page 16: Product Outlines
World-leading provider of embedded/IoT products and solutions 1.5 Product Outlines 1.6 Vantron VDS10 Docking Station Vantron offers VDS10 docking station that is compatible with the M10R1-RK35 to provide power and user expansion. VDS10 weighs 800g, and operates at -20°C to +60°C. Description of the I/Os: Description Power jack (DC 12V ±... -
Page 17: Chapter 2 Getting Started
Vantron Embedded in your success, Embedded in your better life World-leading provider of embedded/IoT products and solutions CHAPTER 2 GETTING STARTED Vantron | Public M10R1-RK35 User Manual www.vantrontech.com... -
Page 18: Setting Up The Device
To charge M10R1-RK35, use the power adapter and cable provided or use a docking station with an appropriate power supply (e.g., Vantron VDS10 docking station). The battery is design to support at a minimum of 1,000 charge cycles. -
Page 19: Turning On/Off The Device
1. Tap on linaro from the taskbar of the screen to access the system options; Mon 11 Mar, 02:52 linaro 2. Tap on the Shut Down option; 3. Confirm if you really wish to shut down the device; 4. Wait for the device to completely power off. Vantron | Public M10R1-RK35 User Manual www.vantrontech.com... -
Page 20: Battery Level Indicator
There is an LED indicator on the front panel for indication of the battery condition and system status. Battery level indicator System status Battery level Charging status Indicator Not charging <15% Charging Amber Not charging Active 15%~100% (excl.) Charging Amber Not charging 100% Charging Green Vantron | Public M10R1-RK35 User Manual www.vantrontech.com... -
Page 21: I/O Description
2.2.4 USB Type-A The USB 2.0 Type-A port allows users to connect peripherals such as a digital camera, a keyboard, or a printer for extended use. Vantron | Public M10R1-RK35 User Manual www.vantrontech.com... -
Page 22: Audio Jack
USB3.0 Transmit differential positive Ground POGO_USB_3.0_RX_P_CON USB3.0 Receive differential positive Ground POGO_USB2.0_DP_CON USB2.0 Host data Ground POGO_Power_IN_CON Only supports power 12V input POGO_Power_IN_CON Only supports power 12V input POGO_USB_3.0_TX_N_CON USB3.0 Transmit differential negative Vantron | Public M10R1-RK35 User Manual www.vantrontech.com... -
Page 23: Buttons & Nfc
There are four buttons on the tablet, including one power button in orange and three user-defined buttons. The NFC induction area is among the user-defined buttons. Power button NFC induction area User-defined buttons Vantron | Public M10R1-RK35 User Manual www.vantrontech.com... -
Page 24: Chapter 3 Debian System Manual
Vantron Embedded in your success, Embedded in your better life World-leading provider of embedded/IoT products and solutions CHAPTER 3 DEBIAN SYSTEM MANUAL Vantron | Public M10R1-RK35 User Manual www.vantrontech.com... -
Page 25: Operating The Device
1. Tap on Applications on the top left corner of the screen; 2. Select the About Xface option to access the desktop environment; 3. You can then check the system information like device name, operating system, copyright statement, etc. Vantron | Public M10R1-RK35 User Manual www.vantrontech.com... -
Page 26: Default User (Linaro)
• Switch the user (password for the linaro user is “linaro”) • Store the device's current state and data in the system's RAM and suspend the device to a low-power state • Shut down the device • Log out the system Vantron | Public M10R1-RK35 User Manual www.vantrontech.com... -
Page 27: Time And Date
Note: This method only modifies the software system date and time, which may revert to the original settings upon device restart. To address this issue, refer to section 3.2.10 to adjust the RTC (hardware time). Vantron | Public M10R1-RK35 User Manual www.vantrontech.com... -
Page 28: Software Features
3. Select the target device from the device list and tap on OK; 4. If the two devices are connected, the file transfer will be initiated immediately. Otherwise, the transfer might fail; 5. Wait for the file to be transferred. Vantron | Public M10R1-RK35 User Manual www.vantrontech.com... -
Page 29: Cellular Network
3. Switch to the root user using sudo su command and input ifconfig to check the network interfaces on the device; 4. Use the “ping” command to test the connection of the cellular network. Vantron | Public M10R1-RK35 User Manual www.vantrontech.com... -
Page 30: Camera
3. Press “Ctrl + C” to exit the application. 3.2.6 Button The device offers three user-defined buttons. You can input the following commands using hexdump tool and press the corresponding keys to check the printed information. # hexdump /dev/input/by-path/platform-gpio-keys-event-joystick Vantron | Public M10R1-RK35 User Manual www.vantrontech.com... -
Page 31: Barcode Scanner
1. Use the following command to enable the NFC feature of the device; # nfcDemoApp poll 2. Place an NFC tag near the NFC induction area (between the user-defined buttons) for data reading; 3. Press the Enter button to exit the NFC feature. Vantron | Public M10R1-RK35 User Manual www.vantrontech.com... -
Page 32: Sensors
• # echo > /sys/devices/virtual/input/input1/op_mode # echo 1 > /sys/devices/virtual/input/input1/enable • Read sensor value # cat /sys/devices/virtual/input/input1/value Make sure the screen rotation is off when you need switch the mode of the sensor. Vantron | Public M10R1-RK35 User Manual www.vantrontech.com... - Page 33 # echo 1 > /sys/devices/virtual/input/input2/enable Read sensor value • # cat /sys/devices/virtual/input/input2/value 3. Accelerometer sensor • Enable sensor # echo > /sys/devices/virtual/input/input3/op_mode # echo 1 > /sys/devices/virtual/input/input3/enable Read sensor value • # cat /sys/devices/virtual/input/input3/value Vantron | Public M10R1-RK35 User Manual www.vantrontech.com...
-
Page 34: Rtc
# echo > /dev/watchdog // time unit: minute 2. Feed the dog before the device reboot; # echo V > /dev/watchdog 3. Enable the watchdog. # echo A > /dev/watchdog Vantron | Public M10R1-RK35 User Manual www.vantrontech.com... -
Page 35: Audio
4. Randomly play an audio file that is saved on the device. # gst-play-1.0 test_audio.wav // replace test_audio.wav with your file name You can tap on Application and navigate to Multimedia > PulseAudio Volume Control to change the audio settings. Vantron | Public M10R1-RK35 User Manual www.vantrontech.com... -
Page 36: Chapter 4 Debian System Upgrade
Vantron Embedded in your success, Embedded in your better life World-leading provider of embedded/IoT products and solutions CHAPTER 4 DEBIAN SYSTEM UPGRADE Vantron | Public M10R1-RK35 User Manual www.vantrontech.com... -
Page 37: Image Flashing In Windows System
Embedded in your success, Embedded in your better life World-leading provider of embedded/IoT products and solutions Whenever a new image is available, Vantron will provide a release package consisting of all the tools/files necessary so that you can flash the image either in Windows or Ubuntu system. - Page 38 6. Paste the path of the platform-tools folder, and click OK one by one to confirm and exit; 7. Press “Win + R” and input cmd in the dialogue box; 8. Input adb version in the command prompt to check if the ADB tool is installed. Vantron | Public M10R1-RK35 User Manual www.vantrontech.com...
-
Page 39: Upgrade Driver Installation
1. Unzip the software release package and navigate to the following directory: \SW\downloadetools\windows\DriverAssitant_xxx\DriverInstall; 2. Right click the mouse and run the program as administrator; 3. Click Install the Driver and wait; A pop-up will appear in a second suggesting the driver is installed. Vantron | Public M10R1-RK35 User Manual www.vantrontech.com... -
Page 40: Image Flashing
5. Input adb devices in the command prompt to check if the device is connected to the Windows host; 6. Once the device is identified by the Windows host computer, input adb reboot loader to reboot the device into the bootloader mode; Vantron | Public M10R1-RK35 User Manual www.vantrontech.com... - Page 41 10. Click the Upgrade button and the system will start to download the image and upgrade the firmware automatically; 11. When the upgrade finishes, the system will reboot automatically. Vantron | Public M10R1-RK35 User Manual www.vantrontech.com...
-
Page 42: Image Flashing In Ubuntu System
$ adb devices -l 4. Execute adb shell to access the device’s shell; 5. Execute reboot loader to reboot the device into bootloader mode; 6. Copy the release package provided by Vantron to the Ubuntu host computer; Vantron | Public M10R1-RK35 User Manual... - Page 43 // path of the image file Replace ”xxx” with the full name of the release package. 10. The upgrade will commence once the download is complete. The system will automatically reboot upon completion of the upgrade process. Vantron | Public M10R1-RK35 User Manual www.vantrontech.com...
-
Page 44: Chapter 5 Disposal And Warranty
Vantron Embedded in your success, Embedded in your better life World-leading provider of embedded/IoT products and solutions CHAPTER 5 DISPOSAL AND WARRANTY Vantron | Public M10R1-RK35 User Manual www.vantrontech.com... -
Page 45: Disposal
& electronic waste recycling/disposal center. Proper disposal of this sort of waste helps avoid harm and adverse effect upon surroundings and people’s health. Please contact local organizations or recycling/disposal center for more recycling/disposal methods of related products. Vantron | Public M10R1-RK35 User Manual www.vantrontech.com... -
Page 46: Warranty
CUSTOMER’s location and no Product so inspected shall be returned to VANTRON unless the cause for the rejection or defect is determined to be the responsibility of VANTRON. VANTRON shall in turn provide the CUSTOMER turnaround shipment on defective Product within fourteen (14) working days upon its receipt at VANTRON. -
Page 47: Appendix Regulatory Compliance Statements
- Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Vantron | Public M10R1-RK35 User Manual www.vantrontech.com... - Page 48 La puissance de sortie rayonné de cet appareil est conforme aux limites de la ISDE Canada limites d’exposition aux fréquences radio. Cet appareil doit être utilisé avec une distance minimale de séparation de 20cm entre (8 pouces) l’appareil et le corps d’une personne. Vantron | Public M10R1-RK35 User Manual www.vantrontech.com...
-
Page 49: Esd Precautions
° Never place your device or the adapter on furniture or any other surface that might be marred by exposure to heat since the base of your device and the surface of the adaptor may increase in temperature during normal use. Vantron | Public M10R1-RK35 User Manual www.vantrontech.com...
