- Page 1 | Embedded in your success, Embedded in your better life World-leading provider of embedded/IoT products and solutions M10 R1 10” Rugged Industrial Tablet User Manual Version: 1.3 © Vantron Technology, Inc. All rights reserved. Vantron | Public M10R1 User Manual www.vantrontech.com...
-
Page 2: Revision History
Apr. 10, 2023 Updated the description of the I/Os as per the design change V1.2 Jul. 11, 2023 for GEN 2 V1.3 Updated the description on the use of the sensors Jan. 14, 2024 Vantron | Public M10R1 User Manual www.vantrontech.com... -
Page 3: Table Of Contents
Unpacking ........................6 Specifications ......................... 7 Specifications (Cont’d) ....................8 Product Layout ....................... 9 Product Outlines ......................12 Vantron VDS10 Docking Station ................... 12 CHAPTER 2 GETTING STARTED ...................... 13 Setting up the Device ....................14 2.1.1 Battery ........................14 2.1.2... - Page 4 Prerequisites ........................ 31 Make a Bootable USB Drive ..................31 System Installation ....................... 32 CHAPTER 5 DISPOSAL AND WARRANTY ..................34 Disposal ........................35 Warranty ........................36 Appendix Regulatory Compliance Statements .................. 37 Vantron | Public M10R1 User Manual www.vantrontech.com...
-
Page 5: Foreword
World-leading provider of embedded/IoT products and solutions Foreword Thank you for purchasing Vantron M10R1 10” rugged industrial tablet (“the tablet” or “the Product”). This manual intends to provide guidance and assistance necessary on setting up, operating, or maintaining the Product. Please read this manual and make sure you understand the structure and functionality of the Product before putting it into use. -
Page 6: Technical Support And Assistance
Symbology This manual uses the following signs to prompt users to pay special attention to relevant information. Caution for latent damage to system or harm to personnel Attention to important information or regulations Vantron | Public M10R1 User Manual www.vantrontech.com... -
Page 7: General Safety Instructions
Be sure that nothing rests on the power cable and that the cable is located at a place without risk of trips. Cut off the power before inspection of the Product to avoid human injury or product damage. Vantron | Public M10R1 User Manual www.vantrontech.com... - Page 8 • Clean with a damp cloth • Do not try to clean exposed electronic components unless with a dust collector Power off and contact Vantron technical support engineer in case of the following faults: • The Product is damaged •...
-
Page 9: Chapter 1 Introduction
Vantron Embedded in your success, Embedded in your better life World-leading provider of embedded/IoT products and solutions CHAPTER 1 INTRODUCTION Vantron | Public M10R1 User Manual www.vantrontech.com... -
Page 10: Product Overview
World-leading provider of embedded/IoT products and solutions Product Overview Vantron M10R1 high-performance rugged industrial tablet was designed for industrial applications, especially in healthcare, plant walk-down, law enforcement patrol, and prison automation. The device is powered by Intel® ATOM multi-core processor with a 10-inch full HD capacitive touch screen with a resolution of 1920 x 1200 to offer excellent human- machine interaction experience. -
Page 11: Specifications
1 x Light sensor Sensor Gyro-sensor 1 x Gyro-sensor G-Sensor 1 x G-sensor 1 x Power button Button System Control 3 x Function button LED indicator 1 x System status / Battery condition Vantron | Public M10R1 User Manual www.vantrontech.com... -
Page 12: Specifications (Cont'd)
Humidity RH 5%-95% (Non-condensing) Condition MIL-STD-810H FCC (FCC Part 15 Class B) Certification ISED ESD (Contact: ±4KV, Air: ±8KV) * Source: Test with 1080p video play at 50% volume and 200 nits brightness. Vantron | Public M10R1 User Manual www.vantrontech.com... -
Page 13: Product Layout
Long press (about 3 seconds) to turn off the device Power button Short press to turn on/off the screen or turn on the device Airplane mode Function button LCD backlight up User definable LCD backlight down Vantron | Public M10R1 User Manual www.vantrontech.com... - Page 14 Rear camera 8MP, auto focus Speaker 4Ω/2w speaker for audio output Top view ○ ○ Item Description Volume + button Increase the media playing volume Volume - button Decrease the media playing volume Vantron | Public M10R1 User Manual www.vantrontech.com...
-
Page 15: Bottom View
USB 2.0 Type-A Nano SIM slot Hold a Nano SIM card for cellular communication TF slot Store a TF card for expansion of the storage Audio jack Connect a headphone or external speaker, etc. Vantron | Public M10R1 User Manual www.vantrontech.com... -
Page 16: Product Outlines
World-leading provider of embedded/IoT products and solutions Product Outlines Vantron VDS10 Docking Station Vantron offers VDS10 docking station that is compatible with the M10R1 to provide power and user expansion. VDS10 weighs 800g and operates at -20°C to +60°C. Description of the I/Os: Description Power jack (DC 12V ±... -
Page 17: Chapter 2 Getting Started
Vantron Embedded in your success, Embedded in your better life World-leading provider of embedded/IoT products and solutions CHAPTER 2 GETTING STARTED Vantron | Public M10R1 User Manual www.vantrontech.com... -
Page 18: Setting Up The Device
To charge M10R1, use the power adapter and cable provided or use a docking station with an appropriate power supply (e.g., Vantron VDS10 docking station). -
Page 19: Turning On/Off The Device
Using the power button A long press of the power button located on the right side of M10R1 about 3 seconds will turn off the device, while a brief press of the power button will turn it on. There will be an audio prompt when the system is starting up. -
Page 20: Battery Level Indicator
Viewing Angle Horizontal: 170° / Vertical: 170° Display Screen Resolution 1920 x 1200 Contrast Ratio 1000:1 LCM Luminance 600 nits Touch Points 10-point Touch Screen Touchscreen Technology PCAP technology Structure G + G Vantron | Public M10R1 User Manual www.vantrontech.com... -
Page 21: Mini Hdmi
20V output at 3A. Additionally, it features USB On-The-Go (OTG) functionality, allowing you to debug the device through this port. To connect a host computer, simply plug the USB Type-A to USB Type-C cable into the USB Type-C port of the tablet. Vantron | Public M10R1 User Manual www.vantrontech.com... -
Page 22: Usb Type-A
Type-A port of the tablet. 2.2.5 Audio jack The device offers a 3.5 mm combo audio jack that is compatible with four-section headphones for audio input/output. 2.2.6 Speaker The device offers a 4Ω/2W speaker for audio output. Vantron | Public M10R1 User Manual www.vantrontech.com... -
Page 23: Buttons
Round Square identifier identifier Pinout description: Name Type Description POGO_Power_IN_CON Only supports 12V power input POGO_USB_3.0_TX_P_CON USB3.0 Transmit differential positive Ground POGO_USB_3.0_RX_P_CON USB3.0 Receive differential positive Ground POGO_USB2.0_DP_CON USB2.0 Host data Ground Vantron | Public M10R1 User Manual www.vantrontech.com... - Page 24 Only supports power 12V input POGO_Power_IN_CON Only supports power 12V input POGO_USB_3.0_TX_N_CON USB3.0 Transmit differential Negative Ground POGO_USB_3.0_RX_N_CON USB3.0 Receive differential negative Ground POGO_USB2.0_DN_CON USB2.0 Host data Ground POGO_Power_IN_CON Only supports power 12V input Vantron | Public M10R1 User Manual www.vantrontech.com...
-
Page 25: Chapter 3 Windows System Manual
Vantron Embedded in your success, Embedded in your better life World-leading provider of embedded/IoT products and solutions CHAPTER 3 WINDOWS SYSTEM MANUAL Vantron | Public M10R1 User Manual www.vantrontech.com... -
Page 26: Operating The Device
Vantron Embedded in your success, Embedded in your better life World-leading provider of embedded/IoT products and solutions Operating the Device This section describes how to operate M10R1, including the device information, device settings, and network connection. 3.1.1 Device information To access the device information: 1. -
Page 27: Turning On The Tablet Mode
• Swipe in from the right edge of the screen to open the action center, then enable Tablet mode. • Press the Window key + A on the external keyboard connected to M10R1 to open the action center, then enable Tablet mode. 3.1.3 Connecting to a wireless network 1. -
Page 28: Featured Functions
This section introduces the featured functions that M10R1 offers, including the camera, barcode scanner, sensors and buttons. Vantron provides simple applications for using the features mentioned. To properly use M10R1, please copy the \4 SW Guide folder from the software package, which includes the applications, to the device first. 3.2.1 Camera Open the camera application CameraDemo.exe that is included in the path: \4 SW... -
Page 29: Barcode Scanner
GNSS navigation. To test the sensors, open the application VtSensorsTool.exe located in the \4 SW Guide\Sensor folder. The proximity sensor will prompt “Person Approaching” when someone approaches the tablet and “Person Away” when they leave. Vantron | Public M10R1 User Manual www.vantrontech.com... -
Page 30: Function Buttons
1. Turn on the tablet and it will enter the boot process; 2. Press ESC, if you have connected a keyboard, or press the volume + key, during the system bootup to enter the BIOS configuration page; Vantron | Public M10R1 User Manual www.vantrontech.com... - Page 31 3. You can check the BIOS version of the device after accessing the BIOS configuration page by navigating to the Setup Utility > Main menu; 4. Other information such as the EC version is also available on the same page. Vantron | Public M10R1 User Manual www.vantrontech.com...
-
Page 32: Setup Utility - Main
• S5 state. OEM Configuration: LVDS configurations are available to change. • SIO SCH 3222: Serial ports are configured here. • H2OUVE Configuration: You can enable/disable the configuration interface of • H2OUVE tool. Vantron | Public M10R1 User Manual www.vantrontech.com... -
Page 33: Setup Utility - Security
3.3.7 Setup Utility – Exit • Options for users to load or exit BIOS Setup include loading system optimal defaults or loading custom settings, exiting with custom changes save or not saved. Vantron | Public M10R1 User Manual www.vantrontech.com... -
Page 34: Chapter 4 Image Flashing
Vantron Embedded in your success, Embedded in your better life World-leading provider of embedded/IoT products and solutions CHAPTER 4 IMAGE FLASHING Vantron | Public M10R1 User Manual www.vantrontech.com... -
Page 35: Prerequisites
Embedded in your success, Embedded in your better life World-leading provider of embedded/IoT products and solutions Whenever a new image is available, Vantron will provide a release package consisting of all the tools/files necessary so that you can flash the image in a Windows host. -
Page 36: System Installation
System Installation 1. Plug the bootable USB drive into M10R1; 2. Power on the device and it will enter the boot process; 3. Press ESC, if you have connected a keyboard, or press the volume + key, during the system bootup to enter the BIOS configuration page;... - Page 37 6. Wait until the “Where do you want to install Windows” page appears on the Windows Setup window; 7. Tap on Delete to remove all partitions from the target disk on the M10R1 device to ensure clean installation; Make sure you have backed up the data in the disk before deleting the partitions because system installation will format the disk.
-
Page 38: Chapter 5 Disposal And Warranty
Vantron Embedded in your success, Embedded in your better life World-leading provider of embedded/IoT products and solutions CHAPTER 5 DISPOSAL AND WARRANTY Vantron | Public M10R1 User Manual www.vantrontech.com... -
Page 39: Disposal
& electronic waste recycling/disposal center. Proper disposal of this sort of waste helps avoid harm and adverse effect upon surroundings and people’s health. Please contact local organizations or recycling/disposal center for more recycling/disposal methods of related products. Vantron | Public M10R1 User Manual www.vantrontech.com... -
Page 40: Warranty
Any Product found to be defective and covered under warranty pursuant to Clause above, shall be returned to VANTRON only upon the CUSTOMER’s receipt of and with reference to a VANTRON supplied Returned Materials Authorization (RMA) number. VANTRON shall supply a RMA, when required within three (3) working days of request by the CUSTOMER. -
Page 41: Appendix Regulatory Compliance Statements
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the radiator and your body. The device has been evaluated to meet general RF exposure requirement. Vantron | Public M10R1 User Manual www.vantrontech.com... -
Page 42: Esd Precautions
° Never place your device or the adapter on furniture or any other surface that might be marred by exposure to heat since the base of your device and the surface of the adaptor may increase in temperature during normal use. Vantron | Public M10R1 User Manual www.vantrontech.com...
