- Page 1 VT-TAB07-RK68H User Manual VT-TAB07-RK68H Hardware User Manual Product Version: 2.0 Date: 2020-10-15 For any question, please contact Chengdu Vantron Technology, Ltd. Copyright © Vantron Technology, Ltd. All rights reserved.
- Page 2 Change History This table describes the version and release date. Rev. Date Description Author 2020-01-17 Initial Version 2020-10-15 Second release...
- Page 3 Please contact our technical department for relevant operation solutions if there is any problem that cannot be solved according to this manual. Vantron reserves all rights of this manual, including the right to change the content, form, product features, and specifications contained herein at any time without prior written notice.
- Page 4 Limitation of Liability/Non-warranty For direct or indirect damage to this device or other devices of Vantron caused by failure of conforming to this manual or the safety instructions on device label, Vantron assumes neither warranty nor legal liability even if the device is still under warranty.
- Page 5 Use Proper power source only. Start only with power source that satisfies voltage label and the voltage necessary according to this manual. Please contact technical support personnel of Vantron for any uncertainty about the requirements of necessary power source. Use tested power source. This product still contains a button lithium battery as a real-time clock after its external power source is removed and therefore should not be short-circuited during transportation or placed under high temperature.
-
Page 6: Table Of Contents
Contents INTRODUCTION ..............................1 ..............................1 RODUCT ESCRIPTION ............................... 1 ONNECTOR ESCRIPTION OVERVIEW ................................3 .................................. 3 NTRODUCTION ....................................3 EATURE ............................... 4 RDER NFORMATION HARDWARE INSTRUCTIONS ......................... 5 ..................................5 PPEARANCE ..............................5 NTERFACE ESCRIPTION ..................................5 TRUCTURE HARDWARE FUNCTION DESCRIPTION ...................... 7 WIFI/BT ..................................... -
Page 7: Introduction
Introduction Product Description Vantron offers both ARM and ATOM based Single Boards Computer (SBC) platforms including Cirrus LogicEP9315, RockChip RK3128, RK3368, RK3288, RK3399, Freescale iMX6, iMX8, TI OMAP35xx CortexA8 series, and Intel Skylake and ApolloLake processor boards. In additional to offering the standard SBCs, we also provide professional customization board design services. - Page 8 3.3V 3.3V signal level 5V signal level 5V tolerant signal PCIe PCI Express signal, not 3.3V tolerant No Connection...
-
Page 9: Overview
Overview Introduction VT-TAB07-RK68H is a tablet computer designed for entertainment application. This product is based on RK3368Hwhich has Octacores and one of them is Cortex-A53with a maximum clock frequency of 1.5GHz, supporting10.1" LCD and capacity touch screen. Feature Specifications RK3368H, CPU:Octa-core Cortex-A53,up to Processor 1.5GHz... -
Page 10: Order Information
-20 ~ +60℃ (Recommended: 25℃) Environment Condition 10-85%RH (Non-Condensation), operating and Humidity storage Accessories Order Information Part Order Example RK3368H ARM Octa -core, Cortex-A53 1.5GHz VT-TAB07-RK68H WIFI 802.11 a/b/g/n/ac, BT 5.0. Note: Please contact Vantron for other order information. -
Page 11: Hardware Instructions
Hardware Instructions Appearance Figure 3-1 Views Interface Description Figure 3-2 Interfaces USB TYPE-C 3.5mm Headphone jack Structure Download the board structure document from Vantron technology or Vantron net site: www.vantrontech.com.cn... - Page 12 Figure 3-3 Structure Unit: mm...
-
Page 13: Hardware Function Description
WLAN receives Audio VT-TAB07-RK68H has a 3.5mm Headphone jack, a 1.0W Speaker and a MIC. The headphone jack supports drive-by-wire control and MIC function. If you want to use both of these features, your headphones must support them, too. Our headphone... -
Page 14: Display
Display VT-TAB07-RK68H has a 7.0" screen. The screen is made up of a display screen and a touch screen, which are fitted together by full-fit technology. More parameters are shown in the table. Item Specifications Unit Screen Size 7.0" Inch... -
Page 15: Hardware Operation Note
Do not use unauthorized or incompatible power adaptors to charge the device,otherwise fire, explosion or other danger may be caused. Antenna The design of the internal antenna position of VT-TAB07-RK68H WIFI and BT antenna frequency is 2.4G and 5G respectively. -
Page 16: Software Instructions
Software Instructions VT-TAB07-RK68H has been pre-loaded firmware. For more information, please refer to software user manual for software operation. -
Page 17: Tips
In the aim of avoiding accidents as far as possible, it is not allowed to replace the system or change components unless with permission and certification. Please contact the technical department of Vantron or local branches for help. Pay attention to caution signs. - Page 18 Vantron assumes no responsibility of possible missing contents and information, errors in contents, citations, examples, and source programs. Vantron reserves the right to make necessary changes to this manual without prior notice. No part of this manual may be reprinted or publicly released in forms of photocopy, tape, broadcast, e-document, etc.
-
Page 19: Appendix A: How To Contact Us
Address: 440 Boulder Court, Suite 300, Pleasanton, CA 94566, USA Tel: 925-621-8758 Email: sales@vantrontech.com China Office: Chengdu Vantron Technology, Ltd Address: 6th Floor, 1stBuilding, No.9, 3rd Wu KeEast Street, Wu Hou District, Chengdu 610045, China Tel: 86-28-8512-3930/3931, 8515-7572/6320 Email: sales@vantrontech.com.cn...
